K6-54.
Bergquist
THERMALLY CONDUCTIVE INSULATOR; Insulator Body Material:Silicone Elastomer; Thermal Conductivity:1.1W/m.K; Breakdown Voltage Vbr:6kV; Thickness:0.152mm; Volume Resistivity:10ohm-m; Thermal Impedance:0.82 C/W; Dielectric Strength:- ;RoHS Compliant: Yes
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| Newark | K6-54. | 387 | 1 | $0.18 | $0.18 | $0.18 | $0.18 | $0.18 | $0.18 |
BG405798
Bergquist
$1.00
HI-FLOW 625 .005" 4"X4" SHEET; Thickness:0.127mm; Conductive Material:-; Thermal Conductivity:0.8W/m.K; Thermal Impedance:0.79°C/W; Volume Resistivity:10000Mohm-m; External Length:-; External Width:100mm; Product Range:-; SVHC:No SVHC (07-Jul-2017); Breakdown Voltage Vbr:4kV; Electrical Property Ins / Con:Insulative; Isolation Voltage:4kV; Operating Temperature Max:150°C; Packages Cooled:TO-3P TO-220; Thermal Resistance:1.6°C/W; Type:Insulating Pad
BG405792
Bergquist
$1.00
GAP PAD VO SOFT .060" 4"X4" SHEET; Thermal Conductivity:0.8W/m.K; Conductive Material:-; Thickness:1.5mm; Thermal Impedance:-; Dielectric Strength:-; External Length:-; External Width:100mm; Product Range:-; SVHC:No SVHC (07-Jul-2017); Breakdown Voltage Vbr:6kV; Dielectric Constant:5.5; External Depth:1.5mm; External Length / Height:100mm; Insulator Body Material:Gap Pad VO Soft; Length:100mm; Material:Gap Pad VO Soft; Operating Temperature Max:200°C; Operating Temperature Min:-60°C; Operating Temperature Range:-60°C to +200°C; Overall Width:100mm; Thermal Conductivity (Cal/cm³/K):0.8Cal/cm³/K; Volume Resistivity:100000Mohm-m
BP100-0.008-00-0606
Bergquist
BOND-PLY 100 .008" 6" X 6" SHEET; Insulator Body Material:-; Thermal Conductivity:0.8W/m.K; Breakdown Voltage Vbr:6kV; Thickness:0.203mm; Volume Resistivity:-; Thermal Impedance:-; Dielectric Strength:-; Product Range:-; SVHC:No SVHC (07-Jul-2017); Length:6"; Operating Temperature Max:120°C; Operating Temperature Min:-30°C; Operating Temperature Range:-30°C to +120°C; Overall Width:152.4mm; Packages Cooled:BGA TO-220
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | BP100-0.008-00-0606 | 0 | 1 | * $21.66 | * $20.26 | * $19.02 | * $18.27 | * $17.25 | * $17.25 |
| Farnell | BP100-0.008-00-0606 | 0 | 1 | * $32.52 | * $23.39 | * $23.39 | * $23.39 | * $23.39 | * $23.39 |
SIL-PADK10 304X304 SHEET
Bergquist
THERMALLY CONDUCTIVE INSULATOR; Insulator Body Material:PI (Polyimide) Film; Thermal Conductivity:1.3W/m.K; Breakdown Voltage Vbr:6kV; Thickness:0.152mm; Volume Resistivity:10ohm-m; Thermal Impedance:0.86 C/W; Dielectric Strength:- ;RoHS Compliant: Yes
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | SIL-PADK10 304X304 SHEET | 29 | 1 | * $81.74 | * $78.47 | * $78.47 | * $78.47 | * $78.47 | * $78.47 |
| Farnell | SIL-PADK10 304X304 SHEET | 29 | 1 | * $139.28 | * $108.58 | * $108.58 | * $108.58 | * $108.58 | * $108.58 |
| Newark | SIL-PADK10 304X304 SHEET | 10 | 1 | $107.21 | $97.45 | $93.58 | $87.16 | $87.16 | $87.16 |
GP2000S40-0.040-02-4/4
Bergquist
GAP PAD 2000S40 .040" 4"X4" SHEET; Insulator Body Material:Gap Pad 2000 S40; Thermal Conductivity:2W/m.K; Breakdown Voltage Vbr:2.5kV; Thickness:1.016mm; Volume Resistivity:10ohm-m; Thermal Impedance:0.97°C/W; Dielectric Strength:-; Product Range:-; SVHC:No SVHC (17-Dec-2015); Colour:Grey; Dielectric Constant:6.0; External Depth:1mm; External Width:100mm; Flammability Rating:UL94V-0; Isolation Voltage:2.5kV; Length:100mm; Material:Gap Pad 2000 S40; Operating Temperature Max:200°C; Operating Temperature Min:-60°C; Operating Temperature Range:-60°C to +200°C; Overall Width:100mm; Resistivity:10ohm/sq; Rockwell Hardness:35; Specific Gravity:0.6; Type:Thermal Pad
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | GP2000S40-0.040-02-4/4 | 35 | 1 | * $16.68 | * $15.57 | * $14.47 | * $14.47 | * $14.47 | * $14.47 |
| Farnell | GP2000S40-0.040-02-4/4 | 40 | 1 | * $26.39 | * $20.82 | * $17.64 | * $17.64 | * $17.64 | * $17.64 |
| Newark | GP2000S40-0.040-02-4/4 | 35 | 1 | $21.57 | $20.55 | $17.31 | $15.00 | $15.00 | $15.00 |
GP2000S40-0.080-02-4/4
Bergquist
GAP PAD 2000S40 .080" 4"X4" SHEET; Insulator Body Material:Fibreglass; Thermal Conductivity:2W/m.K; Breakdown Voltage Vbr:2.5kV; Thickness:2.032mm; Volume Resistivity:10ohm-m; Thermal Impedance:0.97°C/W; Dielectric Strength:-; Product Range:-; SVHC:No SVHC (17-Dec-2015); Colour:Grey; Dielectric Constant:6.0; External Depth:2mm; External Width:100mm; Flammability Rating:UL94V-0; Isolation Voltage:2.5kV; Length:100mm; Material:Gap Pad 2000 S40; Operating Temperature Max:200°C; Operating Temperature Min:-60°C; Operating Temperature Range:-60°C to +200°C; Overall Width:100mm; Resistivity:10ohm/sq; Rockwell Hardness:35; Specific Gravity:0.6; Type:Thermal Pad
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | GP2000S40-0.080-02-4/4 | 1 | 1 | * $24.99 | * $24.00 | * $23.00 | * $23.00 | * $23.00 | * $23.00 |
| Farnell | GP2000S40-0.080-02-4/4 | 3 | 1 | * $45.19 | * $32.87 | * $32.22 | * $32.22 | * $32.22 | * $32.22 |
| Newark | GP2000S40-0.080-02-4/4 | 1 | 1 | $35.08 | $31.27 | $28.60 | $26.63 | $26.63 | $26.63 |
GP2500-0.125-02-0404
Bergquist
GAP PAD 2500 .125" 4"X4" SHEET; Insulator Body Material:Gap Pad 2500 S80; Thermal Conductivity:2.7W/m.K; Breakdown Voltage Vbr:6000V; Thickness:3.18mm; Volume Resistivity:100000Mohm-m; Thermal Impedance:0.74°C/W; Dielectric Strength:-; Product Range:-; SVHC:No SVHC (17-Dec-2015); Colour:Brown; Dielectric Constant:6.8; External Depth:3.175mm; External Width:100mm; Flammability Rating:UL94V-0; Length:100mm; Material:Gap Pad 2500 S80; Operating Temperature Max:200°C; Operating Temperature Min:-60°C; Operating Temperature Range:-60°C to +200°C; Overall Width:100mm; Resistivity:10ohm/sq; Rockwell Hardness:80; Specific Gravity:3.1; Type:Thermal Pad
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | GP2500-0.125-02-0404 | 48 | 1 | * $60.83 | * $60.07 | * $59.30 | * $58.54 | * $58.54 | * $58.54 |
| Farnell | GP2500-0.125-02-0404 | 4 | 1 | * $55.97 | * $41.37 | * $40.54 | * $40.54 | * $40.54 | * $40.54 |
| Newark | GP2500-0.125-02-0404 | 20 | 1 | $41.25 | $36.76 | $33.62 | $31.32 | $31.32 | $31.32 |
HF300P-0.0015-00-4/4
Bergquist
HI-FLOW 300P .0015" 4"X4" SHEET; Thickness:0.102mm; Conductive Material:-; SVHC:No SVHC (17-Dec-2015); Thermal Conductivity:0.9W/m.K; Thermal Impedance:0.13°C/W; Volume Resistivity:10ohm-m; External Length:100mm; External Width:100mm; Product Range:-; Breakdown Voltage Vbr:300VAC; Colour:Green; Dielectric Constant:3.2; Flammability Rating:UL94V-0; Operating Temperature Max:130°C; Operating Temperature Min:-30°C; Packages Cooled:TO-220; Type:Adhesive Sheet
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | HF300P-0.0015-00-4/4 | 3 | 1 | * $8.22 | * $7.08 | * $6.30 | * $6.30 | * $6.30 | * $6.30 |
| Farnell | HF300P-0.0015-00-4/4 | 3 | 1 | * $18.96 | * $11.91 | * $9.48 | * $9.48 | * $9.48 | * $9.48 |
| Newark | HF300P-0.0015-00-4/4 | 23 | 1 | $5.68 | $5.68 | $5.68 | $5.68 | $5.68 | $5.68 |
BP100-0.005-00-1/1
Bergquist
BOND-PLY 100 .005" 1"X1" PK10; Thermal Conductivity:0.8W/m.K; Conductive Material:-; Thickness:0.005"; Thermal Impedance:-; Dielectric Strength:-; External Length:-; External Width:25mm; Product Range:-; SVHC:No SVHC (17-Dec-2015); Breakdown Voltage Vbr:3000V; Colour:White; External Depth:0.127mm; External Length / Height:25mm; Height:25mm; Insulator Body Material:Carbon; Operating Temperature Max:120°C; Operating Temperature Min:-30°C; Operating Temperature Range:-30°C to +120°C; Pack Quantity:10; Packages Cooled:TO-220; Resistivity:200ohm/sq; Tensile Strength N/m²:6N/mm²; Thermal Conductivity (Cal/cm³/K):0.8W/m.K; Type:Adhesive Tape; Volume Resistivity:100000000000ohm-m
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | BP100-0.005-00-1/1 | 704 | 1 | * $6.70 | * $6.70 | * $6.70 | * $6.70 | * $6.70 | * $6.70 |
| Farnell | BP100-0.005-00-1/1 | 704 | 1 | * $12.70 | * $8.58 | * $6.89 | * $6.89 | * $6.89 | * $6.89 |
| Newark | BP100-0.005-00-1/1 | 754 | 1 | $4.87 | $4.64 | $4.10 | $3.93 | $3.93 | $3.93 |
