095.51
Finder Plc
METAL RETAINING CLIP 40 SERIES RELAYS; Product Range:095 Series; Relay Clip Type:Hold Down; For Use With:-; Accessory Type:Retaining Clip
20.21.9.024.0000
Finder Plc
RELAY SPST-NO 400VAC 16A; Contact Configuration:SPST-NO; Coil Voltage:24VDC; Contact Current:16A; Product Range:20 Series; Relay Mounting:DIN Rail Panel; Coil Type:DC; Contact Voltage VAC:400VAC; Relay Terminals:Screw
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 20.21.9.024.0000 | 14 | $29.11 | $25.93 | $23.91 | $23.09 | $22.04 | $22.04 | |
| element14 APAC | 20.21.9.024.0000 | 5 | 1 | $48.43 | $46.98 | $45.56 | $45.56 | $45.56 | $45.56 |
| Farnell | 20.21.9.024.0000 | 5 | 1 | $38.83 | $35.53 | $32.82 | $32.82 | $32.82 | $32.82 |
| Newark | 20.21.9.024.0000 | 2 | 1 | $31.70 | $30.12 | $26.95 | $25.36 | $25.36 | $25.36 |
| RS Components | 20.21.9.024.0000 | 0 | $26.42 |
20.23.9.012.0000
Finder Plc
RELAY 1NO 1NC 250VAC 16A; Contact Configuration:SPST-NO SPST-NC; Coil Voltage:12VDC; Contact Current:16A; Product Range:20 Series; Relay Mounting:DIN Rail Panel; Coil Type:DC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:27ohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:440mA; Coil Voltage Max:13.2VDC; Coil Voltage Min:10.8VDC; Coil Voltage VDC Nom:12V; Contact Current Max:30A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Current Rating:16A; DC Coil Power:5W; Dielectric Voltage Coil to Contact:3500VAC; Dielectric Voltage Contact to Contact:2000VAC; External Depth:58.4mm; External Height:84mm; External Length / Height:84mm; External Width:17.4mm; IP / NEMA Rating:IP20; No. of Electrical Operations:100000; No. of Mechanical Operations:300000; Nom Operating Power:5W; Operating Temperature Max:40°C; Operating Temperature Min:-40°C; Relay Type:Power - General Purpose
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 20.23.9.012.0000 | 22 | $36.51 | $32.52 | $29.98 | $28.95 | $27.64 | $27.64 | |
| element14 APAC | 20.23.9.012.0000 | 34 | 1 | * $41.68 | * $37.81 | * $37.06 | * $37.06 | * $37.06 | * $37.06 |
| Farnell | 20.23.9.012.0000 | 4 | 1 | * $41.87 | * $38.82 | * $38.05 | * $38.05 | * $38.05 | * $38.05 |
| Newark | 20.23.9.012.0000 | 16 | 1 | $36.88 | $35.03 | $31.34 | $29.50 | $29.50 | $29.50 |
| RS Components | 20.23.9.012.0000 | 0 | $31.55 |
066.07
Finder Plc
RELAY ACCESSORIES; Accessory Type:Top 35 mm rail mount; For Use With:-; Product Range:66 Series
20.21.9.012.4000
Finder Plc
RELAY SPST-NO 250VAC 16A; Contact Configuration:SPST-NO; Coil Voltage:12VDC; Contact Current:16A; Product Range:20 Series; Relay Mounting:DIN Rail; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:-; Contact Material:Silver Tin Oxide; Coil Resistance:27ohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:440mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VDC Nom:12V; Contact Current AC Max:16A; Contact Current Max:30A; Contact Voltage AC Max:240V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:30V; Current Rating:16A; Dielectric Strength VDC:3.5kV; External Depth:84mm; External Height:58.4mm; External Length / Height:58.4mm; External Width:17.4mm; Nom Operating Power:5W; Operating Temperature Max:40°C; Operating Temperature Min:-40°C; Relay Type:Power; Switched Current Max:16A; Switched Voltage Max:400V; Voltage Rating VAC:250V
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 20.21.9.012.4000 | 3 | |||||||
| element14 APAC | 20.21.9.012.4000 | 8 | $49.35 | ||||||
| Farnell | 20.21.9.012.4000 | 9 | $27.10 | ||||||
| Newark | 20.21.9.012.4000 | 9 | $42.26 | ||||||
| TME | 20.21.9.012.4000 | 36 | $28.25 |
22.21.9.012.4000
Finder Plc
RELAY SPST 250VAC 20A; Contact Configuration:SPST; Coil Voltage:12VDC; Contact Current:20A; Product Range:22 Series; Relay Mounting:DIN Rail; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:-; Contact Material:Silver Tin Oxide; Coil Resistance:460ohm; Approvals & Standards:CE; SVHC:No SVHC (12-Jan-2017); Approval Category:IP20; Coil Current:104mA; Coil Operating Lower Percent Limit:85%; Coil Operating Upper Percent Limit:110%; Coil Voltage VDC Nom:12V; Contact Current AC Max:30A; Contact Current Max:20A; Contact Voltage AC Nom:250V; Contact Voltage DC Max:12V; Current Rating:20A; Dielectric Strength VDC:3.5kV; External Depth:84mm; External Height:58.4mm; External Length / Height:58.4mm; External Width:17.4mm; Nom Operating Power:1.25W; Operating Temperature Max:40°C; Operating Temperature Min:-40°C; Relay Type:Power; Switched Current Max:20A; Switched Voltage Max:400V; Voltage Rating VAC:250V
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 22.21.9.012.4000 | 0 | |||||||
| element14 APAC | 22.21.9.012.4000 | 44 | $48.24 | ||||||
| Farnell | 22.21.9.012.4000 | 26 | $27.14 | ||||||
| Newark | 22.21.9.012.4000 | 34 | $38.01 | ||||||
| Rutronik | 22.21.9.012.4000 | 0 | $16.91 | ||||||
| TME | 22.21.9.012.4000 | 16 | $27.23 |
34.51.7.048.0010
Finder Plc
RELAY SPDT 250VAC 6A; Contact Configuration:SPDT; Coil Voltage:48VDC; Contact Current:6A; Product Range:34 Series; Relay Mounting:Through Hole; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Contact Voltage VDC:-; Contact Material:Silver Nickel; Coil Resistance:12.3kohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:3.9mA; Coil Voltage VDC Nom:48V; Contact Current AC Max:6A; Contact Current Max:10A; Contact Current Rating:6A; Contact Voltage AC Max:400V; Contact Voltage AC Nom:250V; DC Coil Power:0.17W; External Depth:5mm; External Height:15mm; External Length / Height:15mm; External Width:28mm; No. of Mechanical Operations:10000000; Nom Operating Power:170mW; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Power Rating:1.5kVA; Relay Type:General Purpose; Switching Voltage AC / DC Min:250VAC
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 34.51.7.048.0010 | 0 | |||||||
| element14 APAC | 34.51.7.048.0010 | 7 | $11.05 | ||||||
| Farnell | 34.51.7.048.0010 | 8 | $10.82 | ||||||
| Newark | 34.51.7.048.0010 | 8 | $8.51 | ||||||
| RS Components | 34.51.7.048.0010 | 0 | $9.61 | ||||||
| Rutronik | 34.51.7.048.0010 | 0 | $5.67 | ||||||
| TE Connectivity | 34.51.7.048.0010 | 0 | |||||||
| TME | 34.51.7.048.0010 | 46 | $9.61 |
50.12.9.005.1000
Finder Plc
RELAY SAFETY DPDT 250VAC 8A; Contact Configuration:DPDT; Coil Voltage:5VDC; Contact Current:8A; Product Range:50.12 Series; Relay Mounting:Through Hole; Relay Terminals:Solder; Contact Voltage AC Nom:250V; Contact Voltage DC Nom:-; Contact Material:Silver Nickel; IP Rating:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CE IMQ; Approval Category:UL Recognised; Coil Current:143mA; Coil Resistance:35ohm; Coil Voltage VDC Nom:5V; Contact Current AC Max:15A; Contact Current Max:15A; Contact Voltage AC Max:250V; Current Rating:8A; DC Coil Power:700mW; Dielectric Voltage Contact to Contact:1500VAC; External Depth:12.4mm; External Height:25mm; External Length / Height:25mm; External Width:29mm; No. of Electrical Operations:100000; No. of Mechanical Operations:10000000; No. of Pins:8Pins; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Operating Time:10ms; Release Time:4ms
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 50.12.9.005.1000 | 0 | $18.73 | $18.73 | $18.73 | $18.73 | $18.73 | $18.73 | |
| element14 APAC | 50.12.9.005.1000 | 41 | 1 | * $19.73 | * $19.45 | * $18.73 | * $18.73 | * $18.73 | * $18.73 |
| Farnell | 50.12.9.005.1000 | 213 | 1 | * $19.21 | * $17.87 | * $17.15 | * $17.15 | * $17.15 | * $17.15 |
| Newark | 50.12.9.005.1000 | 24 | 1 | $18.25 | $17.43 | $14.80 | $12.94 | $12.94 | $12.94 |
| RS Components | 50.12.9.005.1000 | 0 | $10.81 | ||||||
| TE Connectivity | 50.12.9.005.1000 | 0 | |||||||
| Verical Marketplace | 50.12.9.005.1000 | 24 | 11 | $7.78 | $7.78 | $7.78 | $7.78 |
46.52.8.230.0040
Finder Plc
RELAY DPDT 250VAC 8A; Contact Configuration:DPDT; Coil Voltage:230VAC; Contact Current:8A; Product Range:46 Series; Relay Mounting:Socket; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:-; Contact Material:Silver Nickel; Coil Resistance:28kohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA GOST RINA VDE; Approval Category:UL Recognised; Coil Current:45mA; Coil Voltage VAC Nom:230V; Contact Current AC Max:15A; Contact Current Max:15A; Contact Current Rating:8A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Dielectric Voltage Contact to Contact:1000VAC; External Depth:12.4mm; External Height:32.8mm; External Length / Height:32.8mm; External Width:29mm; No. of Electrical Operations:100000; No. of Mechanical Operations:10000000; No. of Pins:8Pins; Nom Operating Power:1.2VA; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Operating Time:10ms; Relay Type:Power; Release Time:3ms
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 2066-46.52.8.230.0040-ND | 8 | 1 | $15.67 | $13.96 | $12.87 | $12.43 | $11.46 | $11.46 |
| element14 APAC | 46.52.8.230.0040 | 34 | 1 | * $17.54 | * $15.62 | * $14.40 | * $14.40 | * $14.40 | * $14.40 |
| Farnell | 46.52.8.230.0040 | 14 | 1 | * $18.82 | * $17.47 | * $16.77 | * $16.77 | * $16.77 | * $16.77 |
| Newark | 46.52.8.230.0040 | 18 | 1 | $18.66 | $17.81 | $16.10 | $15.24 | $15.24 | $15.24 |
| RS Components | 46.52.8.230.0040 | 0 | $15.23 | ||||||
| TME | 46.52.8.230.0040 | 495 | $12.07 | ||||||
| Verical Marketplace | 46.52.8.230.0040 | 107 | 1 | $284.29 | $249.24 | $232.50 | $232.50 | $232.50 | $232.50 |
40.61.7.012.0000
Finder Plc
RELAY SPDT 12VDC 16A; Contact Configuration:SPDT; Coil Voltage:12VDC; Contact Current:16A; Product Range:40 Series; Relay Mounting:Through Hole; Coil Type:DC Sensitive; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Contact Voltage VDC:30V; Contact Material:Silver Cadmium Oxide; Coil Resistance:300ohm; Approvals & Standards:CSA UL VDE; SVHC:No SVHC (12-Jan-2017); Coil Current:42mA; Coil Voltage VDC Nom:12V; Contact Current Max:30A; Contact Voltage AC Nom:230V; Current Rating:16A; External Depth:25mm; External Height:29mm; External Width:12.4mm; Nom Operating Power:500mW; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Relay Type:Power - General Purpose
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 40.61.7.012.0000 | 0 | $5.32 | $5.32 | $5.32 | $5.32 | $5.32 | ||
| element14 APAC | 40.61.7.012.0000 | 38 | 1 | * $6.09 | * $5.97 | * $5.85 | * $5.85 | * $5.85 | * $5.85 |
| Farnell | 40.61.7.012.0000 | 985 | 1 | * $7.33 | * $6.74 | * $5.69 | * $5.69 | * $5.69 | * $5.69 |
| Newark | 40.61.7.012.0000 | 3331 | 1 | $7.12 | $6.84 | $6.16 | $5.64 | $5.64 | $5.64 |
| RS Components | 40.61.7.012.0000 | 0 | $4.62 | ||||||
| Rutronik | 40.61.7.012.0000 | 0 | 200 | $3.34 | |||||
| TME | 40.61.7.012.0000 | 1 | $4.62 |
