| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| AVNET Europe | LD 36 S-24 | 0 | 100 | * $5.40 | * $4.47 | * $4.47 |
MTW106E
knitter-switch
KNITTER-SWITCH Single Pole Double Throw (SPDT) Toggle Switch, On-Off-On, Panel Mount. Contact Current Rating: 4 A @ 30 V dc. Terminal Type: Solder. Actuator Length: 17mm. Contact Resistance: 10mΩ. Minimum Operating Temperature: -45°C. Mechanical Life: 100000Operations. Operating Temperature Range: -45 → +140°C. Contact Material: Silver Plated Copper Alloy. Maximum Operating Temperature: +140°C. MPN: MTW106E
DPWL1CGRG
knitter-switch
1-pole on-off switch Momentary Miniature Push Button Switch, IP67, Panel Mount Green LED. Contact Current Rating: 400 mA @ 32 V ac. Illuminated: Yes. Actuator Colour: Red. Case Colour: Black. Maximum Operating Temperature: +85°C. Terminal Type: Solder. Contact Material: Gold Plated Silver. Operating Temperature Range: -30 → +85°C. Minimum Operating Temperature: -30°C. MPN: DPWL1CGRG, KNITTER-SWITCH
MMSP 132
knitter-switch
PCB Slide Switch On-On-On 500 mA @ 4 V dc Slide. Terminal Type: Pc Pin. Length: 12mm. Width: 10.6mm. Depth: 2mm. Dimensions: 12 x 10.6 x 2mm. Contact Resistance: 70mΩ. Operating Temperature Range: -40 → +85°C. Contact Material: Phosphor Bronze. Actuator Material: Liquid Crystal Polymer. Maximum Operating Temperature: +85°C. Voltage Rating: 4V dc. MPN: MMSP 132, KNITTER-SWITCH
SMR5010
knitter-switch
10 Way Surface Mount DIP Switch, Rotary Flush Actuator. Contact Current Rating: 30 mA@ 15 V dc. Contact Material: Gold Plated Phosphor Bronze. Mechanical Life: 20000Operations. Maximum Operating Temperature: +75°C. Minimum Operating Temperature: -25°C. Operating Temperature Range: -25 → +75°C. Dielectric Strength: 250V ac. MPN: SMR5010, KNITTER-SWITCH
DPWL1CGKG
knitter-switch
1-pole on-off switch Momentary Miniature Push Button Switch, IP67, Panel Mount Green LED. Contact Current Rating: 400 mA @ 32 V ac. Illuminated: Yes. Actuator Colour: Black. Maximum Operating Temperature: +85°C. Minimum Operating Temperature: -30°C. Case Colour: Black. Terminal Type: Solder. Operating Temperature Range: -30 → +85°C. Contact Material: Gold Plated Silver. MPN: DPWL1CGKG, KNITTER-SWITCH
DBS 61004
knitter-switch
4 Way PCB DIP Switch 4PST, Raised Actuator. Contact Current Rating: 100 (Non-Switching) mA, 25 (Switching) mA. Contact Material: Gold over Nickel Plated. Mechanical Life: 5000Operations. Maximum Operating Temperature: +85°C. Minimum Operating Temperature: -40°C. Operating Temperature Range: -40 → +85°C. Voltage Rating: 24 V dc, 50 V dc. Dielectric Strength: 500V dc. MPN: DBS 61004, KNITTER-SWITCH
DBS 6108
knitter-switch
8 Way PCB DIP Switch 8PST, Raised Actuator. Contact Current Rating: 100 (Non-Switching) mA, 25 (Switching) mA. Contact Material: Gold over Nickel Plated. Mechanical Life: 5000Operations. Maximum Operating Temperature: +85°C. Minimum Operating Temperature: -40°C. Operating Temperature Range: -40 → +85°C. Voltage Rating: 24 V dc, 50 V dc. Dielectric Strength: 500V dc. MPN: DBS 6108, KNITTER-SWITCH
