5502-25PA-01-F1
Multicomp
PLUG D PCB STRAIGHT 25WAY; No. of Contacts:25Contacts; Gender:Plug; D Sub Shell Size:DB; Product Range:D Sub; Connector Body Material:Metal Body; Contact Termination Type:Solder; Contact Material:Brass; Contact Plating:Gold Plated Contacts; SVHC:No SVHC (07-Jul-2017); Body Plating:Nickel; Contact Resistance:5mohm; Contact Termination:Solder; Current Rating:5A; DC Current Max:3A; Insulation Resistance:1000Mohm; Material:Steel; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Termination Method:Through Hole; Voltage Rating VAC:350V; Withstand Voltage:500V; Working Voltage:250V
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | 5502-25PA-01-F1 | 7279 | 5 | * $0.92 | * $0.73 | * $0.67 | * $0.67 | * $0.67 | |
| Farnell | 5502-25PA-01-F1 | 6300 | 5 | * $0.89 | * $0.71 | * $0.65 | * $0.65 | * $0.65 | |
| Newark | 5502-25PA-01-F1 | 5931 | 1 | $0.75 | $0.69 | $0.65 | $0.65 | $0.65 | $0.65 |
5504F1-09P-02-03-F1
Multicomp
CONNECTOR D SUB PLUG THT R/A 9WAY; No. of Contacts:9Contacts; Gender:Plug; D Sub Shell Size:DE; Product Range:D Sub Formed Pin Series; Connector Body Material:Metal Body; Contact Termination Type:Solder; Contact Material:Brass; Contact Plating:-; SVHC:No SVHC (07-Jul-2017); Body Plating:Nickel; Contact Resistance:30mohm; Contact Termination:Solder; Current Rating:5A; Insulation Resistance:1000Mohm; Material:Plastic; Operating Temperature Max:105°C; Operating Temperature Min:-55°C; Termination Method:Through Hole; Withstand Voltage:1000V; Working Voltage:250V
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | 5504F1-09P-02-03-F1 | 11848 | 5 | * $0.63 | * $0.50 | * $0.46 | * $0.46 | * $0.46 | |
| Farnell | 5504F1-09P-02-03-F1 | 10623 | 5 | * $0.61 | * $0.48 | * $0.44 | * $0.44 | * $0.44 | |
| Newark | 5504F1-09P-02-03-F1 | 10367 | 1 | $0.51 | $0.47 | $0.44 | $0.44 | $0.44 | $0.44 |
55H12T944(250/200)
Multicomp
THERMAL SWITCH NC 250°C; Switching Temperature:250°C; Reset Temperature:200°C; Contact Operation:Normally Closed; Sensor Terminals:Quick Connect; Sensor Housing:Flange Mount; Contact Rating:250VAC/7A; Product Range:-; SVHC:No SVHC (17-Dec-2015); Actuating Temperature Max:250°C; Actuating Temperature Min:200°C; Contact Configuration:SPST-NC; No. of Pins:2Pins; No. of Pins:2 Pin
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | 55H12T944(250/200) | 434 | 1 | * $16.87 | * $15.34 | * $12.97 | * $12.06 | * $12.06 | * $12.06 |
| Farnell | 55H12T944(250/200) | 289 | 1 | * $16.59 | * $15.09 | * $12.76 | * $11.86 | * $11.86 | * $11.86 |
| Newark | 55H12T944(250/200) | 567 | 1 | $9.38 | $9.38 | $9.38 | $9.38 | $9.38 | $9.38 |
60-03L TGG
Multicomp
RF COAXIAL SMA JACK 50OHM; Connector Type:SMA Coaxial; Coaxial Termination:Crimp; Impedance:50ohm; Coaxial Cable Types:-; Contact Material:Beryllium Copper; Contact Plating:Gold Plated Contacts; Frequency Max:3GHz; Connector Mounting:PCB Mount; Product Range:-; SVHC:No SVHC (17-Dec-2015); Working Voltage:335V
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | 60-03L TGG | 28 | 1 | * $12.81 | * $6.19 | * $5.81 | * $5.81 | * $5.81 | * $5.81 |
| Farnell | 60-03L TGG | 28 | 1 | * $12.60 | * $6.09 | * $4.90 | * $4.90 | * $4.90 | * $4.90 |
64S020P-321N-B
Multicomp
PLUG MINI-DISPLAYPORT SOLDER; No. of Contacts:20Contacts; Gender:Plug; Connector Mounting:Cable Mount; Contact Plating:Gold Plated Contacts; Connector Body Material:Plastic Body; Product Range:-; Contact Termination:Solder
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | 64S020P-321N-B | 0 | 1 | * $0.80 | * $0.70 | * $0.58 | * $0.52 | * $0.51 | * $0.51 |
| Farnell | 64S020P-321N-B | 0 | 1 | * $0.39 | * $0.35 | * $0.34 | * $0.32 | * $0.31 | * $0.31 |
65U019S-340N-B-FEC
Multicomp
RECEPTACLE HDMI-D SMT; No. of Contacts:19Contacts; Gender:Jack; Connector Mounting:PCB Mount; Contact Plating:Gold Plated Contacts; Connector Body Material:Plastic Body; Product Range:-; Contact Termination:Surface Mount Right Angle
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | 65U019S-340N-B-FEC | 0 | 1 | * $1.45 | * $1.28 | * $1.06 | * $0.95 | * $0.95 | * $0.93 |
| Farnell | 65U019S-340N-B-FEC | 0 | 1 | * $0.46 | * $0.41 | * $0.39 | * $0.35 | * $0.35 | * $0.34 |
6MD1S2M2RE
Multicomp
SWITCH SLIDE DPDT ON-ON; Contact Configuration:DPDT; Switch Operation:On-On; Switch Mounting:Through Hole; Product Range:6MD1 Series; Contact Current Max:100mA; Contact Voltage AC Max:20V; Contact Voltage DC Max:20V; Orientation:Vertical; SVHC:No SVHC (07-Jul-2017); Actuation Type:Raised; Actuator Type:Raised Slide; Contact Current AC Max:20mA; Contact Current DC Max:20mA; Contact Voltage AC Min:20mV; Contact Voltage DC Min:20mV; External Depth:12.8mm; External Length / Height:7.7mm; External Width:14mm; Insulation Resistance:1000Mohm; Lever Length:2.8mm; Switching Current AC Min:10mA; Switching Current DC Min:10mA; Termination Method:Through Hole
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | 6MD1S2M2RE | 40 | 1 | * $2.56 | * $2.56 | * $2.24 | * $2.04 | * $1.65 | * $1.65 |
| Farnell | 6MD1S2M2RE | 50 | 1 | * $2.52 | * $2.52 | * $2.20 | * $2.01 | * $1.62 | * $1.62 |
| Newark | 6MD1S2M2RE | 1 | 1 | $3.50 | $3.12 | $2.83 | $2.83 | $2.83 | $2.83 |
6MS1S2M1RE
Multicomp
SWITCH SLIDE SPDT ON-ON; Contact Configuration:SPDT; Switch Operation:On-On; Switch Mounting:Through Hole; Product Range:Top Actuator Series; Contact Current Max:100mA; Contact Voltage AC Max:20V; Contact Voltage DC Max:20V; Orientation:Vertical; SVHC:No SVHC (07-Jul-2017); Actuation Type:Raised; Actuator Type:Raised Slide; Contact Current AC Max:20mA; Contact Current DC Max:20mA; Contact Voltage AC Min:20mV; Contact Voltage DC Min:20mV; External Depth:7.8mm; External Length / Height:7.7mm; External Width:14mm; Insulation Resistance:1000Mohm; Lever Length:2.8mm; Switching Current AC Min:10mA; Switching Current DC Min:10mA; Termination Method:Through Hole
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | 6MS1S2M1RE | 9949 | 1 | * $1.59 | * $1.59 | * $1.39 | * $1.26 | * $1.03 | * $1.03 |
| Farnell | 6MS1S2M1RE | 10824 | 1 | * $1.56 | * $1.56 | * $1.37 | * $1.24 | * $1.01 | * $1.01 |
| Newark | 6MS1S2M1RE | 10494 | 1 | $2.41 | $2.41 | $1.91 | $1.79 | $1.79 | $1.79 |
6S6DC(120V)-10PK
Multicomp
LAMP INCANDESCENT 120V 6W; Supply Voltage:120V; Lamp Base Type:D.C. Bayonet; Bulb Size:S-6; MSCP:3.1; Average Bulb Life:1500h; Product Range:-; Lead Style:Bayonet; Length:46.2mm; Lens Style:Straight Side S-6 19mm
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | 6S6DC(120V)-10PK | 28 | 1 | $10.19 | $10.19 | $8.16 | $7.18 | $6.54 | $6.54 |
| Farnell | 6S6DC(120V)-10PK | 26 | 1 | $6.61 | $6.61 | $5.22 | $4.53 | $4.53 | $4.53 |
| Newark | 6S6DC(120V)-10PK | 3 | 1 | $0.00 | $0.00 | $0.00 | $0.00 | $0.00 | $0.00 |
6S6DC/130V-10PK
Multicomp
LAMP INCANDESCENT BA15D 130V 6W; Supply Voltage:130V; Lamp Base Type:BA15d; Bulb Size:S-6; MSCP:3.1; Average Bulb Life:1500h; Product Range:-; Bulb Diameter:19.685mm; Lead Style:Bayonet; Length:1.82"; Power Rating:6W
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | 6S6DC/130V-10PK | 43 | 1 | * $7.80 | * $7.80 | * $7.63 | * $7.63 | * $7.63 | * $7.63 |
| Farnell | 6S6DC/130V-10PK | 43 | 1 | * $14.90 | * $14.90 | * $11.73 | * $10.22 | * $10.22 | * $10.22 |
| Newark | 6S6DC/130V-10PK | 2 | 10 | $0.00 | $0.00 | $0.00 | $0.00 | $0.00 | $0.00 |
