MKS2PIDC24
Omron Automation and Safety
RELAY DPDT 250VAC 30VDC 10A; Contact Configuration:DPDT; Coil Voltage:24VDC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30VDC; Contact Material:Silver Tin Indium; Coil Resistance:430ohm; Approvals & Standards:-; Coil Current:55.8mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VDC Nom:24V; Contact Current AC Max:10A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:250V; Contact Voltage DC Nom:30V; Dielectric Strength VDC:2500V; External Depth:34.5mm; External Height:52.5mm; External Length / Height:52.5mm; External Width:34.5mm; Nom Operating Power:1.4W; Operating Temperature Max:60°C; Operating Temperature Min:-40°C; Relay Type:Power
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | Z3215-ND | 90 | 1 | $19.29 | $17.18 | $15.84 | $15.30 | $14.11 | $14.11 |
| element14 APAC | MKS2PIDC24 | 4 | 1 | * $10.11 | * $10.11 | * $9.70 | * $9.70 | * $9.70 | * $9.70 |
| Farnell | MKS2PIDC24 | 4 | 1 | * $28.25 | * $25.46 | * $23.30 | * $23.30 | * $23.30 | * $23.30 |
MKS3PI5AC24
Omron Automation and Safety
RELAY 3PDT 250VAC 30VDC 10A; Contact Configuration:3PDT; Coil Voltage:24VAC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30VDC; Contact Material:Silver Tin Indium; Coil Resistance:62ohm; Approvals & Standards:-; Coil Current:110mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:24V; Contact Current AC Max:10A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:250V; Contact Voltage DC Nom:30V; Dielectric Strength VDC:2500V; External Depth:34.5mm; External Height:52.5mm; External Length / Height:52.5mm; External Width:34.5mm; Nom Operating Power:2.7VA; Operating Temperature Max:60°C; Operating Temperature Min:-40°C; Relay Type:Power
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | MKS3PI5AC24 | 0 | 1 | $22.08 | $19.67 | $18.14 | $17.51 | $14.82 | $14.82 |
| element14 APAC | MKS3PI5AC24 | 7 | 1 | * $20.90 | * $16.20 | * $15.50 | * $15.50 | * $15.50 | * $15.50 |
| Farnell | MKS3PI5AC24 | 7 | 1 | * $14.86 | * $14.01 | * $13.26 | * $13.26 | * $13.26 | * $13.26 |
MKS3PI5AC230
Omron Automation and Safety
RELAY 3PDT 250VAC 30VDC 10A; Contact Configuration:3PDT; Coil Voltage:230VAC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30VDC; Contact Material:Silver Tin Indium; Coil Resistance:6.17kohm; Approvals & Standards:-; Coil Current:11.5mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:230V; Contact Current AC Max:10A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:250V; Contact Voltage DC Nom:30V; Dielectric Strength VDC:2500V; External Depth:34.5mm; External Height:52.5mm; External Length / Height:52.5mm; External Width:34.5mm; Nom Operating Power:2.7VA; Operating Temperature Max:60°C; Operating Temperature Min:-40°C; Relay Type:Power
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | MKS3PI-5AC230-ND | 0 | 1 | $26.32 | $26.32 | $26.32 | $26.32 | $26.32 | $26.32 |
| element14 APAC | MKS3PI5AC230 | 18 | 1 | * $14.03 | * $14.03 | * $13.79 | * $13.79 | * $13.79 | * $13.79 |
| Farnell | MKS3PI5AC230 | 20 | 1 | * $20.48 | * $16.74 | * $16.08 | * $13.45 | * $13.45 | * $13.45 |
MKS3PI5DC24
Omron Automation and Safety
RELAY 3PDT 250VAC 30VDC 10A; Contact Configuration:3PDT; Coil Voltage:24VDC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30VDC; Contact Material:Silver Tin Indium; Coil Resistance:430ohm; Approvals & Standards:-; Coil Current:55.8mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VDC Nom:24V; Contact Current AC Max:10A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:250V; Contact Voltage DC Nom:30V; Dielectric Strength VDC:2500V; External Depth:34.5mm; External Height:52.5mm; External Length / Height:52.5mm; External Width:34.5mm; Nom Operating Power:1.4W; Operating Temperature Max:60°C; Operating Temperature Min:-40°C; Relay Type:Power
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | Z3218-ND | 11 | 1 | $22.08 | $19.67 | $18.14 | $17.51 | $16.15 | $16.15 |
| element14 APAC | MKS3PI5DC24 | 22 | 1 | * $17.08 | * $17.08 | * $16.84 | * $16.84 | * $16.84 | * $16.84 |
| Farnell | MKS3PI5DC24 | 36 | 1 | * $10.71 | * $10.71 | * $10.71 | * $10.71 | * $10.71 | * $10.71 |
G3NA240BUTUDC524
Omron Automation and Safety
SSR 40A; Contact Configuration:SPST-NO; Load Current:40A; Operating Voltage Max:264VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:19VAC; Control Voltage Min:5VDC; Control Voltage Max:24VDC; Product Range:G3NA Series; Approval Bodies:CSA UL; Control Voltage DC Max:24VDC; Control Voltage DC Min:5VDC; Control Voltage Range:5V DC to 24V DC; Control Voltage Type:DC; External Depth:27mm; External Diameter:4.5mm; External Length / Height:58mm; External Width:43mm; Fixing Centres:47.5mm; Isolation Voltage:2.5kV; Load Current Max:40A; Load Current Min:100mA; Load Current RMS Max:40A; Operating Voltage Range:19V AC to 264V AC; Output Type:Triac; RMS Load Current Min:0.1A; RMS Load Voltage Max:264V; RMS Load Voltage Min:19V; Single Cycle Surge Current:440A; Surge Current:440A
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | Z7484-ND | 190 | 1 | $107.50 | $95.73 | $88.26 | $88.26 | $88.26 | $88.26 |
| element14 APAC | G3NA240BUTUDC524 | 21 | 1 | * $48.16 | * $44.30 | * $40.10 | * $40.10 | * $40.10 | * $40.10 |
| Farnell | G3NA240BUTUDC524 | 27 | 1 | * $47.69 | * $47.69 | * $47.69 | * $47.69 | * $47.69 | * $47.69 |
R9904
Omron Automation and Safety
BRACKET; Product Range:G7J Series; Accessory Type:Mounting Bracket; For Use With:G7J Series; Material:Metal
PL08
Omron Automation and Safety
$2.00
SOCKET CHASSIS 8 PIN; Socket Mounting:Through Hole; Socket Terminals:Solder Lug; No. of Pins:8Pins; Current Rating:10A; Voltage Rating:250VAC; Product Range:MKS Series; Accessory Type:Socket; External Diameter:29mm; Fixing Centres:40mm; For Use With:Omron MK Series General Purpose Relays
A16-24DY
Omron Automation and Safety
LED 24V YELLOW; For Use With:A16 Series; Product Range:A16 Series; Current Rating:10mA; Forward Current If Max:10mA; Forward Voltage VF Max:24VDC; LED / Lamp Size:6mm; LED Colour:Yellow; LED Type:Backlight; Mounting Hole Dia:16mm; No. of Pins:2Pins; Nom Operating Voltage:24V; Operating Temperature Max:55°C; Operating Temperature Min:-10°C; Operating Temperature Range:-10°C to +55°C; Operating life Time:50000h; Voltage Rating V DC:24V; Voltage Vf Typ:24VDC
A16-24DG
Omron Automation and Safety
LED 24V GREEN; For Use With:A16 Series; Product Range:A16 Series; Current Rating:10mA; Forward Current If Max:10mA; Forward Voltage VF Max:24VDC; LED / Lamp Size:6mm; LED Colour:Green; LED Type:Backlight; Mounting Hole Dia:16mm; No. of Pins:2Pins; Nom Operating Voltage:24V; Operating Temperature Max:55°C; Operating Temperature Min:-10°C; Operating Temperature Range:-10°C to +55°C; Operating life Time:50000h; Voltage Rating V DC:24V; Voltage Vf Typ:24VDC
