84130104
Sensata Technologies
DIGITAL I/O MODULE 32VDC DIN RAIL; Current Rating:22mA; Product Range:-; SVHC:No SVHC (07-Jul-2017)
10PCV2415
Sensata Technologies
RELAY SSR 15A; Contact Configuration:SPST-NO; Load Current:15A; Operating Voltage Max:240Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Proportional Output; Operating Voltage Min:100Vrms; Control Voltage Min:2VDC; Control Voltage Max:10VDC; Product Range:PCV Series; SVHC:No SVHC (12-Jan-2017); Blocking voltage:600V; Control Current @ 5VDC:4mA; Control Voltage DC Max:10VDC; Control Voltage DC Min:2VDC; Control Voltage Range:2V DC to 10V DC; Control Voltage Type:DC; External Depth:58.4mm; External Length / Height:23mm; External Width:45.7mm; I2t:94s; Isolation Voltage:2.5kV; Leakage Current:10mA; Load Current RMS Max:15A; Operating Voltage Range:100Vrms to 240Vrms; RMS Load Current Min:150mA; RMS Load Voltage Max:240V; RMS Load Voltage Min:100V; Rate of Voltage Change dv / dt:200V/µs; Surge Current:150A
ASO242
Sensata Technologies
SSR 2A 12-280VAC RANDOM; Contact Configuration:SPST-NO; Load Current:2A; Operating Voltage Max:280Vrms; Relay Mounting:PCB; Relay Terminals:Through Hole; Switching Mode:Zero Crossing; Operating Voltage Min:24Vrms; Control Voltage Min:4VDC; Control Voltage Max:10VDC; Product Range:ASO Series; SVHC:No SVHC (07-Jul-2017); Blocking voltage:600V; Control Current Typ:10mA; Control Voltage DC Max:10VDC; Control Voltage DC Min:4VDC; Control Voltage Range:4V DC to 10V DC; Control Voltage Type:DC; External Depth:5.08mm; External Length / Height:12.7mm; External Width:24.9mm; Input Voltage:4V DC to 10V DC; Isolation Voltage:2.5kV; Load Current Max:2A; Load Current Min:60mA; Load Current RMS Max:2A; Load Voltage Range:12Vrms to 280Vrms; Output Type:Thyristor; RMS Load Current Min:0.06A; RMS Load Voltage Max:280V; RMS Load Voltage Min:12V; Rate of Voltage Change dv / dt:200V/s; Surge Current:120A
D1D07
Sensata Technologies
SSR 7A 100VDC; Contact Configuration:SPST-NO; Load Current:7A; Operating Voltage Max:100VDC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:DC Switch; Operating Voltage Min:0VDC; Control Voltage Min:3.5VDC; Control Voltage Max:32VDC; Product Range:1-DC Series; SVHC:No SVHC (07-Jul-2017); Control Current Max:28mA; Control Current Typ:1.6mA; Control Voltage DC Max:32VDC; Control Voltage DC Min:3.5VDC; Control Voltage Range:3.5V DC to 32V DC; Control Voltage Type:DC; Isolation Voltage:2.5kV; Load Current Min:20mA; Load Current RMS Max:7A; Load Voltage DC Max:100V; On State Resistance Max:0.29ohm; Operating Voltage Range:0V DC to 100V DC; Output Type:MOSFET; RMS Load Voltage Max:100VDC; Single Cycle Surge Current:15A; Surge Current:15A; Turn Off Time:1ms; Turn On Time:0.1ms
D1D100
Sensata Technologies
SSR 100A 100V SIP; Contact Configuration:SPST-NO; Load Current:100A; Operating Voltage Max:100VDC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:DC Switch; Operating Voltage Min:0VDC; Control Voltage Min:3.5VDC; Control Voltage Max:32VDC; Product Range:1-DC Series; SVHC:No SVHC (12-Jan-2017); Control Current Max:28mA; Control Current Typ:1.6mA; Control Voltage DC Max:32VDC; Control Voltage DC Min:3.5VDC; Control Voltage Range:3.5V DC to 32V DC; Control Voltage Type:DC; Isolation Voltage:2.5kV; Load Current Min:20mA; Load Current RMS Max:100A; Load Voltage DC Max:100V; On State Resistance Max:0.005ohm; Operating Voltage Range:0V DC to 100V DC; RMS Load Voltage Max:100VDC; Single Cycle Surge Current:330A; Surge Current:330A; Turn Off Time:1ms; Turn On Time:0.1ms
D1D40L
Sensata Technologies
RELAY SSR 40A; Contact Configuration:SPST-NO; Load Current:40A; Operating Voltage Max:100VDC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:DC Switch; Operating Voltage Min:0VDC; Control Voltage Min:3.5VDC; Control Voltage Max:32VDC; Product Range:1-DCL Series; SVHC:No SVHC (12-Jan-2017); Control Current @ 5VDC:10mA; Control Voltage DC Max:32VDC; Control Voltage DC Min:3.5VDC; Control Voltage Range:3.5V DC to 32V DC; Control Voltage Type:DC; External Depth:58.4mm; External Length / Height:23mm; External Width:45.7mm; Isolation Voltage:2.5kV; Leakage Current:0.3mA; Load Current RMS Max:40A; Load Voltage DC Max:100VDC; Load Voltage DC Min:0VDC; Operating Voltage Range:0V DC to 100V DC; RMS Load Current Min:0A; RMS Load Voltage Max:100VDC; Surge Current:106A
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | D1D40L | 0 | 40 | $92.73 | $88.32 | $84.30 | $81.82 | $81.82 | $81.82 |
| element14 APAC | D1D40L | 7 | 1 | * $132.81 | * $122.65 | * $122.65 | * $122.65 | * $122.65 | * $122.65 |
| Farnell | D1D40L | 2 | 1 | * $44.42 | * $44.42 | * $44.42 | * $44.42 | * $44.42 | * $44.42 |
| Newark | D1D40L | 13 | 1 | $0.00 | $0.00 | $0.00 | $0.00 | $0.00 | $0.00 |
| Verical Marketplace | D1D40L | 12 | 1 | $72.58 | $72.58 | $72.58 | $72.58 | $72.58 | $72.58 |
DR06D03
Sensata Technologies
SSR 3A 1-60VDC 4-32VDC ZERO TURN ON; Contact Configuration:-; Load Current:3A; Operating Voltage Max:60VDC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:Zero Voltage Turn On; Operating Voltage Min:1VDC; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017)
DR06D12
Sensata Technologies
SSR 60VDC/12A 4-32VDC IN 18MM; Contact Configuration:-; Load Current:12A; Operating Voltage Max:60VDC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:1VDC; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Control Voltage DC Max:32VDC; Control Voltage DC Min:4VDC; Control Voltage Range:4V DC to 32V DC; Control Voltage Type:DC; Operating Voltage Range:1V DC to 60V DC; Peak Surge Current:100A
DR2260A30UR
Sensata Technologies
SSR 48-600VAC 30A DIN RAIL; Contact Configuration:SPST-NO; Load Current:30A; Operating Voltage Max:600VAC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:Random Turn On; Operating Voltage Min:48VAC; Control Voltage Min:90VDC; Control Voltage Max:280VDC; Product Range:DR22 Series; SVHC:No SVHC (12-Jan-2017)
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | DR2260A30UR | 1 | $89.38 | $64.49 | $61.52 | $59.74 | $59.74 | $59.74 | |
| element14 APAC | DR2260A30UR | 2 | 1 | * $99.78 | * $94.96 | * $94.96 | * $94.96 | * $94.96 | * $94.96 |
| Farnell | DR2260A30UR | 2 | 1 | * $93.28 | * $85.10 | * $85.10 | * $85.10 | * $85.10 | * $85.10 |
| Newark | DR2260A30UR | 12 | 3 | $128.93 | $128.93 | $128.93 | $128.93 | $128.93 | $128.93 |
| Verical Marketplace | DR2260A30UR | 12 | 1 | $60.90 | $55.37 | $55.37 | $55.37 | $55.37 | $55.37 |
H12WD4850
Sensata Technologies
SSR PANEL MOUNT 660VAC 32VDC 50A; Contact Configuration:SPST-NO; Load Current:50A; Operating Voltage Max:660VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:48VAC; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:H12WD Series; SVHC:No SVHC (07-Jul-2017); Blocking voltage:1200V; Control Voltage DC Max:32VDC; Control Voltage DC Min:4VDC; Control Voltage Range:4V DC to 32V DC; Control Voltage Type:DC; External Depth:22.2mm; External Diameter:4.4mm; External Length / Height:57.2mm; External Width:44.4mm; Fixing Centres:47.6mm; Isolation Voltage:4kV; Load Current Min:150mA; Load Current RMS Max:50A; Must Release Voltage:1V; Operating Voltage Range:48Vrms to 660Vrms; Output Type:Thyristor; RMS Load Current Min:150mA; RMS Load Voltage Max:660V; RMS Load Voltage Min:48V; Rate of Voltage Change dv / dt:500V/µs; Resistance:1500ohm; Single Cycle Surge Current:625A; Surge Current:625A
