CWA2410E
Sensata Technologies
SSR PANEL MOUNT 280VAC 36VAC 10A; Control Voltage Range:18Vrms to 36Vrms; Operating Voltage Range:24Vrms to 280Vrms; Contact Configuration:SPST-NO; Load Current:10A; Switching Mode:Zero Crossing; Relay Terminals:Screw
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | CWA2410E | 14 | 1 | $67.18 | $63.98 | $61.08 | $59.28 | $59.28 | $59.28 |
| element14 APAC | CWA2410E | 0 | 1 | $104.88 | $94.39 | $73.41 | $73.41 | $73.41 | $73.41 |
| Farnell | CWA2410E | 0 | 10 | $0.00 | $36.51 | $35.46 | $35.46 | $35.46 | $35.46 |
| Newark | CWA2410E | 86 | 3 | $67.85 | $64.46 | $58.47 | $58.47 | $58.47 | $58.47 |
| Verical Marketplace | CWA2410E | 90 | 1 | $70.04 | $63.21 | $58.89 | $58.89 | $58.89 | $58.89 |
MP240D4
Sensata Technologies
SSR 4A 24-280VAC 3-32VDC; Contact Configuration:SPST-NO; Load Current:4A; Operating Voltage Max:280Vrms; Relay Mounting:PCB; Relay Terminals:Through Hole; Switching Mode:Zero Crossing; Operating Voltage Min:24Vrms; Control Voltage Min:3VDC; Control Voltage Max:32VDC; Product Range:MP Series; SVHC:No SVHC (07-Jul-2017); Control Voltage DC Max:32VDC; Control Voltage DC Min:3VDC; Operating Temperature Max:80°C; Operating Temperature Min:-40°C
MPDCD3
Sensata Technologies
SSR 3A 3-60VDC; Contact Configuration:SPST-NO; Load Current:3A; Operating Voltage Max:60VDC; Relay Mounting:PCB; Relay Terminals:Through Hole; Switching Mode:Zero Crossing; Operating Voltage Min:3VDC; Control Voltage Min:3VDC; Control Voltage Max:32VDC; Product Range:MP Series; SVHC:No SVHC (07-Jul-2017); Approval Bodies:CSA VDE; Approval Category:UL Recognised; Blocking voltage:600V; Control Current @ 5VDC:2.6mA; Control Voltage DC Max:32VDC; Control Voltage DC Min:3VDC; Control Voltage Range:3V DC to 32V DC; Control Voltage Type:DC; External Depth:25.4mm; External Length / Height:44mm; External Width:10mm; Input Impedance:1500kohm; Input Voltage:3V DC to 32V DC; Insulation Resistance:1000Mohm; Isolation Voltage:4kV; Lead Diameter:1mm; Leakage Current:1mA; Load Current Max:3A; Load Current Min:0.02A; Load Current RMS Max:3A; Load Voltage DC Max:60V; Load Voltage DC Min:3V; Load Voltage Range:3V DC to 60V DC; On State AC Resistance @ temp:270ohm; Operating Temperature Max:80°C
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | MPDCD3 | 0 | 1 | $49.00 | $46.67 | $44.55 | $43.24 | $43.24 | $43.24 |
| element14 APAC | MPDCD3 | 166 | 1 | * $38.01 | * $34.51 | * $33.82 | * $33.82 | * $33.82 | * $33.82 |
| Farnell | MPDCD3 | 166 | 1 | * $38.11 | * $34.37 | * $33.69 | * $33.69 | * $33.69 | * $33.69 |
| Newark | MPDCD3 | 2 | 1 | $45.30 | $43.33 | $40.98 | $40.98 | $40.98 | $40.98 |
| TME | MPDCD3 | 28 | $33.40 | ||||||
| Verical Marketplace | MPDCD3 | 29 | 16 | $18.83 | $18.33 | $17.20 | $17.20 | ||
| Win Source | MPDCD3 | 1150 | 1 |
A53TP25D
Sensata Technologies
SSR 25A; Load Current:25A; Operating Voltage Max:530VAC; Control Voltage Max:280VAC; Switching Mode:Zero Voltage Turn On; Contactor Mounting:Panel; Contactor Terminals:Screw; Operating Voltage Min:48VAC; Control Voltage Min:90VAC; Product Range:53TP Series; SVHC:No SVHC (07-Jul-2017); Blocking voltage:1200V; Contact Configuration:SPST-NO; Control Voltage AC Max:280VAC; Control Voltage AC Min:90VAC; Control Voltage Range:90V AC to 280V AC; Control Voltage Type:AC; External Depth:22mm; External Length / Height:104mm; External Width:73.5mm; Fixing Centres LxW:92 x 47.6mm; I2t:450s; Isolation Voltage:4kV; Load Current Max:45A; Load Current Min:50mA; Load Current RMS Max:25A; Must Release Voltage:100V; No. of Phases:Three Phase; On State Resistance Max:16.7kohm; Operating Frequency Max:65Hz; Operating Frequency Min:25Hz; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Voltage Range:48Vrms to 530Vrms; Output Type:SCR; RMS Load Current Min:0.05A
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | A53TP25D | 0 | 10 | $266.71 | $266.71 | $266.71 | $266.71 | $266.71 | |
| element14 APAC | A53TP25D | 2 | 1 | * $305.08 | * $305.08 | * $305.08 | * $305.08 | * $305.08 | * $305.08 |
| Farnell | A53TP25D | 1 | 1 | * $265.08 | * $265.08 | * $265.08 | * $265.08 | * $265.08 | * $265.08 |
| Newark | A53TP25D | 7 | 1 | $317.48 | $304.49 | $295.10 | $295.10 | $295.10 | $295.10 |
| Verical Marketplace | A53TP25D | 9 | 1 | $214.90 | $161.83 | $154.22 | $154.22 | $154.22 | $154.22 |
D53TP25D
Sensata Technologies
SSR 25A; Load Current:25A; Operating Voltage Max:530VAC; Control Voltage Max:32VDC; Switching Mode:Zero Voltage Turn On; Contactor Mounting:Panel; Contactor Terminals:Screw; Operating Voltage Min:48VAC; Control Voltage Min:4VDC; Product Range:53TP Series; SVHC:No SVHC (07-Jul-2017); Blocking voltage:1200V; Control Voltage DC Max:32VDC; Control Voltage DC Min:4VDC; Control Voltage Range:4V DC to 32V DC; Control Voltage Type:DC; External Depth:22mm; External Length / Height:104mm; External Width:73.5mm; Fixing Centres LxW:92 x 47.6mm; I2t:450s; Insulation Resistance:4000ohm; Isolation Voltage:4kV; Load Current Max:45A; Load Current Min:50mA; Load Current RMS Max:25A; Must Release Voltage:100V; No. of Phases:Three Phase; On State Resistance Max:300ohm; Operating Frequency Max:25Hz; Operating Frequency Min:65Hz; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Voltage Range:48Vrms to 530Vrms; Output Type:SCR; RMS Load Current Min:0.05A
CSD2410
Sensata Technologies
SSR 10A 240VAC; Contact Configuration:SPST-NO; Load Current:10A; Operating Voltage Max:280VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24VAC; Control Voltage Min:3.5VDC; Control Voltage Max:15VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:EN; Blocking voltage:600V; Control Voltage DC Max:15VDC; Control Voltage DC Min:3.5VDC; Control Voltage Range:3.5V DC to 15V DC; Control Voltage Type:DC; Isolation Voltage:4kV; Leakage Current:1mA; Load Current Min:150mA; Load Current RMS Max:10A; Operating Voltage Range:24Vrms to 280Vrms; Output Type:SCR; RMS Load Current Min:0.15A; RMS Load Voltage Max:280V; RMS Load Voltage Min:24V; Rate of Voltage Change dv / dt:200V/µs; Surge Current:120A
CSD2450
Sensata Technologies
SSR 50A 3.5-15VDC 24-280VAC ZERO; Contact Configuration:SPST-NO; Load Current:50A; Operating Voltage Max:280VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24VAC; Control Voltage Min:3.5VDC; Control Voltage Max:15VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017)
D2490
Sensata Technologies
SSR 90A; Contact Configuration:SPST-NO; Load Current:90A; Operating Voltage Max:280VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24VAC; Control Voltage Min:3VDC; Control Voltage Max:32VDC; Product Range:1 Series; SVHC:No SVHC (07-Jul-2017); Blocking voltage:600V; Control Voltage DC Max:32VDC; Control Voltage DC Min:3VDC; Control Voltage Range:3V DC to 32V DC; Control Voltage Type:DC; External Depth:22.2mm; External Diameter:4.4mm; External Length / Height:57.2mm; External Width:44.4mm; Fixing Centres:47.6mm; Isolation Voltage:4kV; Load Current Min:40mA; Load Current RMS Max:90A; Must Release Voltage:1V; Operating Voltage Range:24Vrms to 280Vrms; Output Type:Thyristor; RMS Load Current Min:40mA; RMS Load Voltage Max:280V; RMS Load Voltage Min:48V; Rate of Voltage Change dv / dt:500V/µs; Resistance:1500ohm; Single Cycle Surge Current:1200A; Surge Current:1200A
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | CC1083-ND | 22 | 1 | $111.48 | $106.17 | $101.35 | $98.37 | $98.37 | $98.37 |
| element14 APAC | D2490 | 12 | 1 | * $113.23 | * $104.33 | * $104.33 | * $104.33 | * $104.33 | * $104.33 |
| Farnell | D2490 | 12 | 1 | * $110.53 | * $99.48 | * $99.48 | * $99.48 | * $99.48 | * $99.48 |
| Newark | D2490 | 13 | 1 | $113.72 | $108.40 | $97.76 | $97.76 | $97.76 | $97.76 |
| Verical Marketplace | D2490 | 11 | 1 | $108.14 | $104.48 | $104.48 | $104.48 | $104.48 | $104.48 |
| Win Source | D2490 | 370 | 1 |
D4825
Sensata Technologies
SSR 25A 480VAC; Contact Configuration:SPST-NO; Load Current:25A; Operating Voltage Max:530Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:48VAC; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:D48 Series; SVHC:No SVHC (07-Jul-2017); Blocking voltage:800V; Control Voltage DC Max:32VDC; Control Voltage DC Min:3VDC; Control Voltage Range:3V DC to 32V DC; Control Voltage Type:DC; External Depth:22.2mm; External Diameter:4.4mm; External Length / Height:57.2mm; External Width:44.4mm; Fixing Centres:47.6mm; Isolation Voltage:4kV; Load Current Min:40mA; Load Current RMS Max:25A; Must Release Voltage:1V; Operating Voltage Range:80Vrms to 530Vrms; Output Type:Thyristor; RMS Load Current Min:40mA; RMS Load Voltage Max:530V; RMS Load Voltage Min:80V; Rate of Voltage Change dv / dt:500V/µs; Resistance:1500ohm; Single Cycle Surge Current:250A; Surge Current:250A
HD4825
Sensata Technologies
SSR 4-32VDC 48-530VAC 25A; Contact Configuration:SPST-NO; Load Current:25A; Operating Voltage Max:530VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:48VAC; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017)
