TE Connectivity 350561-7

TE Connectivity 350924-1

TE Connectivity 350700-7

TE Connectivity 350699-1

TE Connectivity 926868-1

TE Connectivity 350715-4

TE Connectivity 640581-1

TE Connectivity 794901-1

TE Connectivity 350809-1

TE Connectivity 643428-1

Price
RoHS
Lead Status
Contact Angle Straight Straight Straight Straight Straight
Accepts Wire Insulation Diameter Range 1.02 – 2.54 .032 – .057 .13 – .2 1.02 – 2.54 .13 – .2
Mating Pin Diameter .084 .084 2.18 2.18 .081
Agency/Standard UL UL UL UL UL CSA CSA CSA CSA CSA
Glow Wire Rating Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire
CSA Rating Certified Certified Certified Certified Certified Certified Certified Certified Certified Certified
Termination Type Crimp Crimp Crimp Crimp Crimp
Underplate Material Thickness 1.27 1.27
Contact Mating Area Plating Thickness .76 .76 150 – 200
Wire/Cable Type Discrete Wire Discrete Wire Discrete Wire Discrete Wire Discrete Wire
Connector & Contact Terminates To Wire & Cable Wire & Cable Wire & Cable Wire & Cable Wire & Cable Wire & Cable Wire & Cable Wire & Cable Wire & Cable Printed Circuit Board
Contact Mating Area Plating Material Gold Pre-Tin Gold Pre-Tin Pre-Tin Pre-Tin
Crimp Area Plating Thickness 50 50
VDE Tested Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Wire Insulation Support Without Without Without Without Without
Contact Current Rating (Max) 19 19 19 19 12
Contact Design Solid Solid Split Split
Contact Termination Area Plating Material Nickel Pre-Tin Nickel Pre-Tin Pre-Tin Pre-Tin
Contact Type Pin Pin Pin Pin Pin Pin Pin Socket Plug Socket
Product Type Contact Contact Contact Contact Contact Housing Housing Housing Housing Header
Wire Contact Termination Area Plating Material Nickel Pre-Tin Nickel Pre-Tin Pre-Tin
UL Rating Recognized Recognized Recognized Recognized Recognized Recognized Recognized Recognized Recognized Recognized
Contact Retention in Housing With With With With With
Circuit Application Power Power Power Power Power Power & Signal Power & Signal Power & Signal Power & Signal Power
Operating Voltage 600 600 600 600 600 600 600 600 600
For Multiple Crimp No No No No No
Wire/Cable Size 24 – 18 30 – 26 20 – 14 24 – 18 16 – 13
Contact Base Material Brass Brass Brass Brass Brass
Contact Termination Area Plating Thickness 1.27 1.27
Contact Underplating Material Nickel Nickel
CSA File Number LR 16455 LR 7189 LR 7189 LR 7189 LR 16455 LR16455 LR7189 LR 7189 LR16455 LR7189
Operating Temperature Range -67 – 221 -67 – 221 -67 – 221 -67 – 221 -67 – 221 -67 – 221 -67 – 221 -67 – 221 -40 – 221
UL File Number E28476 E28476 E28476 E28476 E28476
Contact Retention Type within Housing Locking Lance Locking Lance Locking Lance Locking Lance Locking Lance
Connector Mounting Type Cable Mount Cable Mount Cable Mount Cable Mount Cable Mount Cable Mount Cable Mount Cable Mount Cable Mount Board Mount
For Use With Universal MATE-N-LOK Plug or Socket Housing Universal MATE-N-LOK Plug or Cap Housing Universal MATE-N-LOK Plug or Socket Housing Universal MATE-N-LOK Plug or Socket Housing Universal MATE-N-LOK Plug or Socket Housing Appropriate Universal MATE-N-LOK Cap or Header Universal MATE-N-LOK Cap or Header Appropriate Universal MATE-N-LOK Cap or Header Appropriate Universal MATE-N-LOK Cap or Header Mates with Plug Housing (Using Pin Contacts)
Wire Type Stranded Stranded Stranded Stranded Stranded
Packaging Quantity 7000 8000 2500 7000 2500 500 1 1 1 50
Packaging Method Reel Reel Reel Reel Reel Package Package Package Package Bag
Connector System Wire-to-Wire Wire-to-Wire Wire-to-Wire Wire-to-Wire Wire-to-Wire Wire-to-Wire Wire-to-Wire Wire-to-Wire Wire-to-Wire Wire-to-Board
Housing Material Nylon PA 66 Nylon Nylon Nylon
Agency/Standard Number E28476 E28476 E28476 E28476 E28476
Assembly Integration Feature Without Without Without Without Without
Number of Positions 6 6 3 5 12
Number of Rows 2 1 1 1 3
Contact Retention Without Without Without Without Without
Multiple Contact Types Without Without Without Without Without
UL Flammability Rating UL 94V-0 UL 94V-0 UL 94V-2 UL 94V-0 UL 94V-0
Row-to-Row Spacing 6.35 6.35
Contact Layout Matrix Inline Inline Inline Matrix
Housing Color White Natural Black Natural White
Centerline (Pitch) 6.35 6.35 6.35 6.35 6.35
Housing Type Plug Plug Plug Plug Receptacle
Termination Method to Wire & Cable Crimp Crimp Crimp Crimp
Sealable No No No No No
Length 39.37 20.32 26.67
Width 7.62 .579 20.32
Panel Thickness .03 – .09
Panel Mount Feature Without Without Without
Circuit Identification Feature Without
Height 27.43 13.97
Selectively Loaded No
Number of Power Positions 0 12
PCB Mount Retention Without
Termination Post &Tail Length .149
Strain Relief Without
PCB Thickness (Recommended) .125
Mating Retention Type Positive Lock
PCB Mount Alignment Type Standard Polarized Tail
PCB Mount Alignment With
PCB Mount Orientation Vertical
Termination Method to Printed Circuit Board Through Hole - Solder
Termination Post & Tail Length 3.81
Mating Retention With
Mating Alignment With
Mating Alignment Type Polarization
