TE Connectivity 1-480340-0

TE Connectivity 60619-4

TE Connectivity 1-480586-0

TE Connectivity 1-480305-0

TE Connectivity 350424-1

TE Connectivity 1-641737-1

TE Connectivity 1-380999-0

TE Connectivity 106014-1

TE Connectivity 1-1612257-4

TE Connectivity 58529-1

Price
RoHS
Lead Status
Housing Material Nylon Nylon Nylon Nylon Nylon Nylon
Packaging Quantity 1 1000 1 1 100 100 100
Product Type Housing Contact Housing Housing Header Header Header
Agency/Standard Number E28476 E28476 E28476 E28476 E28476 E28476
For Use With Socket (Plug) Housing Commercial MATE-N-LOK housings Socket (Plug) Housing Socket (Plug) Housing Socket (Plug) Housing Socket (Plug) Housing
Connector & Contact Terminates To Wire & Cable Wire & Cable Wire & Cable Wire & Cable Printed Circuit Board Printed Circuit Board Printed Circuit Board
Number of Positions 6 9 3 4 4 6
Number of Rows 2 3 1 1 1 2
Contact Retention Without Without Without Without Without Without
Agency/Standard CSA CSA CSA CSA CSA
Glow Wire Rating Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire
Contact Type Pin Socket Pin Pin Pin Pin Pin
Row-to-Row Spacing 9.14 6.1 4.95
Operating Voltage 250 250 250 250 250 250 250
Centerline (Pitch) 4.95 6.1 5.08 5.08 5.08 4.95
Housing Type Receptacle Receptacle Receptacle Receptacle Plug Plug
Circuit Identification Feature With With
UL Rating Certified Certified Certified Certified Certified
Circuit Application Power & Signal Power Power & Signal Power & Signal Power Power Power
Termination Method to Wire & Cable Crimp Crimp Crimp
UL Flammability Rating UL 94V-2 UL 94V-2 UL 94V-2 UL 94V-2 UL 94V-0 UL 94V-2
Packaging Method Package Bag/Box Package Package Bag Bag Bag
Operating Temperature Range -67 – 221 -67 – 221 -67 – 221 -67 – 221 -67 – 221 -67 – 221 -67 – 221
Housing Color Natural Natural Natural Natural White Natural
CSA File Number LR16455 LR16455 LR16455 LR16455 LR16455
VDE Tested No No No Yes No No
Connector Mounting Type Cable Mount Cable Mount Cable Mount Cable Mount Board Mount Board Mount Board Mount
Panel Mount Feature Without Without
Sealable No No No No No No
Connector System Wire-to-Wire Wire-to-Wire Wire-to-Wire Wire-to-Wire Wire-to-Board Wire-to-Board Wire-to-Board
Contact Angle Straight
Mating Pin Diameter .084
Termination Type Crimp
Contact Mating Area Plating Material Tin Pre-Tin Pre-Tin Pre-Tin
Wire/Cable Type Discrete Wire
Wire/Cable Size 20 – 14
Wire Contact Termination Area Plating Material Tin
Wire Insulation Support Without
Contact Current Rating (Max) 15 12 12 12
Contact Retention in Housing With
Contact Base Material Phosphor Bronze
Contact Termination Area Plating Material Tin Pre-Tin Pre-Tin Pre-Tin
For Multiple Crimp No
Barrel Type Open Barrel
Contact Shape Round
Accepts Wire Insulation Diameter Range 3.3
Contact Retention Type within Housing Locking Lance
Wire Type Stranded
Contact Layout Matrix Inline Inline Inline
Length 28.7 .915
Width 19.17 .375
Height 21.46 8.382
Underplate Material Thickness 50
PCB Thickness (Recommended) 1.57 1.57 1.57
Mating Retention Type Detent Lock Detent Lock Positive Lock
Contact Mating Area Plating Thickness 150 – 200 150 – 200 150 – 200
Termination Post &Tail Length .18 .14 .149
PCB Mount Orientation Vertical Right Angle Vertical
Number of Power Positions 4 4 6
Termination Method to Printed Circuit Board Through Hole - Solder Through Hole - Solder Through Hole - Solder
Mating Retention With With With
Mating Alignment With With With
Contact Termination Area Plating Thickness 100
Mating Alignment Type Polarization Polarization Polarization
Termination Post & Tail Length 4.57 3.56 3.81
PCB Mount Alignment Type Locating Posts
PCB Mount Alignment With
PCB Mount Retention With
PCB Mount Retention Type Boardlock
