TMR 3-2421WIR
TRACOPOWER
TRACOPOWER TMR 3WI 3W Isolated DC-DC Converter Through Hole, Vin 9 → 36 V dc, Vout ±5V dc. Input Voltage Nominal: 24 V dc. Isolation Voltage: 1600V dc. Output Current: ±300mA. Number of Outputs: 2. Railway Approved: Yes. Package: SIP 8. Minimum Temperature: -40°C. Maximum Temperature: +85°C. Load Regulation: 0.01. Line Regulation: 0.002. Application: Battery Operated Equipment. MPN: TMR 3-2421WIR
TIM 2-2411SM
TRACOPOWER
TRACOPOWER TIM 2 2W Isolated DC-DC Converter Surface Mount, Vin 18 → 36 V dc, Vout 5V dc Medical Approved. Input Voltage Nominal: 24 V dc. Output Current: 400mA. Medical Approved: Yes. Package: SMD 16. Efficiency: 0.78. Minimum Temperature: -40°C. Maximum Temperature: +105°C. Load Regulation: 0.01. Line Regulation: 0.002. Protection Features: Continuous Short Circuit Protection. MPN: TIM 2-2411SM
TIM 3.5-1223
TRACOPOWER
TRACOPOWER TIM 3.5 3.5W Isolated DC-DC Converter Through Hole, Vin 9 → 18 V dc, Vout ±15V dc Medical Approved. Input Voltage Nominal: 12 V dc. Medical Approved: Yes. Number of Outputs: 2. Package: DIP 16. Length: 24.3mm. Protection Features: Patient Protection. Depth: 10.2mm. Width: 14.4mm. Special Features: 2:1 Input Voltage with Extended, Isolation 5000 Vrms ac Rated for 250 Vrms ac Working Voltage, Low Leakage Current. Standards Met: EN 55022, IEC/EN/ES 60601-1. MPN: TIM 3.5-1223
TIM 3.5-1215SM
TRACOPOWER
TRACOPOWER TIM 3.5 3.5W Isolated DC-DC Converter Surface Mount, Vin 9 → 18 V dc, Vout 24V dc Medical Approved. Input Voltage Nominal: 12 V dc. Medical Approved: Yes. Package: SMD 16. Length: 24.3mm. Protection Features: Patient Protection. Depth: 10.5mm. Width: 14.4mm. Special Features: 2:1 Input Voltage with Extended, Isolation 5000 Vrms ac Rated for 250 Vrms ac Working Voltage, Low Leakage Current. Standards Met: EN 55022, IEC/EN/ES 60601-1. MPN: TIM 3.5-1215SM
TIM 3.5-2413SM
TRACOPOWER
TRACOPOWER TIM 3.5 3.5W Isolated DC-DC Converter Surface Mount, Vin 18 → 36 V dc, Vout 15V dc Medical Approved. Input Voltage Nominal: 24 V dc. Medical Approved: Yes. Package: SMD 16. Length: 24.3mm. Protection Features: Patient Protection. Depth: 10.5mm. Width: 14.4mm. Special Features: 2:1 Input Voltage with Extended, Isolation 5000 Vrms ac Rated for 250 Vrms ac Working Voltage, Low Leakage Current. MPN: TIM 3.5-2413SM
TIM 3.5-4812SM
TRACOPOWER
TRACOPOWER TIM 3.5 3.5W Isolated DC-DC Converter Surface Mount, Vin 36 → 75 V dc, Vout 12V dc Medical Approved. Input Voltage Nominal: 48 V dc. Medical Approved: Yes. Package: SMD 16. Length: 24.3mm. Protection Features: Patient Protection. Depth: 10.5mm. Width: 14.4mm. Special Features: 2:1 Input Voltage with Extended, Isolation 5000 Vrms ac Rated for 250 Vrms ac Working Voltage, Low Leakage Current. Standards Met: EN 55022, IEC/EN/ES 60601-1. MPN: TIM 3.5-4812SM
TMR 3-4823WIR
TRACOPOWER
TRACOPOWER TMR 3WIR 3W Isolated DC-DC Converter Through Hole, Vin 18 → 75 V dc, Vout ±15V dc Railway Approved. Input Voltage Nominal: 48 V dc. Isolation Voltage: 1600V dc. Output Current: ±100mA. Number of Outputs: 2. Package: SIP 8. Railway Approved: Yes. Efficiency: 0.81. Minimum Temperature: -40°C. Maximum Temperature: +85°C. Line Regulation: 0.002. MPN: TMR 3-4823WIR
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | TMR 3-4823WIR | 4 | $38.29 | ||||||
| Farnell | TMR 3-4823WIR | 4 | $22.48 | ||||||
| Newark | TMR 3-4823WIR | 10 | $24.92 | ||||||
| RS Components | TMR 3-4823WIR | 0 | $224.88 | ||||||
| RS Components (APAC) | TMR 3-4823WIR | 0 | $423.61 | ||||||
| TME | TMR 3-4823WIR | 14 | $27.96 | ||||||
| Win Source | TMR 3-4823WIR | 750 |
TMR 3-7212WIR
TRACOPOWER
TRACOPOWER TMR 3WI 3W Isolated DC-DC Converter Through Hole, Vout 12V dc, I/O isolation 1600V dc. Package: SIP 8. Railway Approved: Yes. Width: 9.2mm. Depth: 11.1mm. Protection Features: Continuous Short Circuit Protection. Weight: 4.8g. Ripple And Noise: 30mV Pk-Pk. Special Features: Excellent Load & Line Regulation, Remote On/Off, Ultra Wide 4:1 Input Range. Application: Battery Operated Equipment. Standards Met: cULus Listed, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC 60950-1, MIL-STD-810F, UL 94 V-0, UL/cUL 60950-1. MPN: TMR 3-7212WIR
TIM 2-2422
TRACOPOWER
TRACOPOWER TIM 2 2W Isolated DC-DC Converter Through Hole, Vin 18 → 36 V dc, Vout ±12V dc Medical Approved. Input Voltage Nominal: 24 V dc. Output Current: ±83mA. Medical Approved: Yes. Package: DIP 16. Efficiency: 0.82. Minimum Temperature: -40°C. Maximum Temperature: +105°C. Load Regulation: 0.01. Line Regulation: 0.002. Protection Features: Continuous Short Circuit Protection. MPN: TIM 2-2422
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | TIM 2-2422 | 10 | 1 | * $32.45 | * $31.42 | * $29.96 | * $27.47 | * $27.47 | * $27.47 |
| Farnell | TIM 2-2422 | 10 | 1 | * $33.06 | * $28.92 | * $27.76 | * $27.18 | * $27.18 | * $27.18 |
| Newark | TIM 2-2422 | 10 | 10 | $0.00 | $25.90 | $24.74 | $24.74 | $24.74 | $24.74 |
| RS Components | TIM 2-2422 | 0 | $311.04 | ||||||
| RS Components (APAC) | TIM 2-2422 | 0 | $585.86 | ||||||
| TME | TIM 2-2422 | 10 | $28.55 |
TIM 3.5-2415
TRACOPOWER
TRACOPOWER TIM 3.5 3.5W Isolated DC-DC Converter Through Hole, Vin 18 → 36 V dc, Vout 24V dc Medical Approved. Input Voltage Nominal: 24 V dc. Medical Approved: Yes. Package: DIP 16. Width: 14.4mm. Special Features: 2:1 Input Voltage with Extended, Isolation 5000 Vrms ac Rated for 250 Vrms ac Working Voltage, Low Leakage Current. Standards Met: EN 55022, IEC/EN/ES 60601-1. Length: 24.3mm. MPN: TIM 3.5-2415
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| element14 APAC | TIM 3.5-2415 | 10 | $51.61 | ||||||
| Farnell | TIM 3.5-2415 | 10 | $29.56 | ||||||
| Newark | TIM 3.5-2415 | 10 | $31.87 | ||||||
| RS Components | TIM 3.5-2415 | 0 | $244.93 | ||||||
| RS Components (APAC) | TIM 3.5-2415 | 0 | $71.25 | ||||||
| TME | TIM 3.5-2415 | 2 | $35.78 |
