| Price | $3.33 | $2.07 | $3.96 | ||||||||
| RoHS | Compliant | Compliant | Not Compliant | Compliant | Compliant | Not Compliant | Compliant | Compliant | Compliant | Compliant | |
| Lead Status | No | No | No | No | No | No | No | No | No | ||
| Package Size | mm2 | mm2 | mm2 | mm2 | |||||||
| Control I/F | Indexer | Indexer | Indexer | Indexer | |||||||
| Current Regulation Levels | 32 | 16 | 16 | 16 | |||||||
| # of Full Bridges | 2 | 2 | 2 | 2 | |||||||
| Operating Temperature Range(C) | -40 to 85 | -40 to 125 | -40 to 125 | -40 to 125 | |||||||
| Rating | Catalog | Catalog | Catalog | Catalog | |||||||
| Approx. Price (US$) | 1.50 | 1ku | 1.92 | 1ku | 1.92 | 1ku | 1.92 | 1ku | |||||||
| RMS Output Current(A) | 1.1 | 1.41 | 1.41 | 1.41 | |||||||
| RDS(ON) (HS + LS)(mOhms) | 1280 | 630 | 630 | 630 | |||||||
| Peak Output Current(A) | 1.6 | 2.5 | 2.5 | 2.5 | |||||||
| Vs(Max)(V) | 45 | 45 | 45 | 45 | |||||||
| Vs(Min)(V) | 8.2 | 6.5 | 6.5 | 6.5 | |||||||
| Additional Features | 1/32 Microstepping,P2P w/ DRV8825 | AutoTune, Adaptive blanking time, Configurable off-time PWM, Dedicated Sleep Pin, Torque DAC | AutoTune, Adaptive blanking time, Configurable off-time PWM, Dedicated Sleep Pin, Torque DAC | AutoTune, Adaptive blanking time, Configurable off-time PWM, Dedicated Sleep Pin, Torque DAC |
