| Price | $1.98 | $3.26 | $25.96 | ||||||||
| RoHS | Compliant | Compliant | Compliant | Not Compliant | Compliant | Compliant | Compliant | Yes | Compliant | ||
| Lead Status | No | Yes | No | No | No | Yes | Yes | Yes | |||
| RDS(ON) (HS + LS)(mOhms) | 630 | 1500 | |||||||||
| Control I/F | PWM, PH/EN | Serial | |||||||||
| Peak Output Current(A) | 2.5 | 0.566 | |||||||||
| # of Full Bridges | 2 | ||||||||||
| Rating | Catalog | Catalog | |||||||||
| RMS Output Current(A) | 1.41 | 0.566 | |||||||||
| Package Size | mm2 | mm2 | |||||||||
| Vs(Min)(V) | 6.5 | 8 | |||||||||
| Approx. Price (US$) | 1.60 | 1ku | 1.50 | 1ku | |||||||||
| Vs(Max)(V) | 45 | 38 | |||||||||
| Additional Features | AutoTune, Adaptive blanking time, Configurable off-time PWM, Dedicated Sleep Pin, Higher Microstepping with External Reference, Outputs can be paralleled | Integrated Catch Diodes,Open-Load Detect,Configurable Driving Profile | |||||||||
| Operating Temperature Range(C) | -40 to 125 | -40 to 85 |
