The AD5334/AD5335/AD5336/AD5344 are quad 8-,10-,and 12-bit DACs. They operate from a 2.5 V to 5.5 V supply consuming just 500 ?A at 3 V, and feature a power-down mode that further reduces the current to 80 nA. These devices incorporate an on-chip output buffer that can drive the output to both supply rails.PRODUCT HIGHLIGHTS Available in a 28-lead TSSOP package Low power, single supply operation from 2.5 V to 5.5 V supply Consumes 1.5 mW at 3 V and 3 mW at 5 V On-chip ouput buffer can drive output to both supply rails

The AD5413 is a single-channel, 14-bit voltage and current output, digital-to-analog converter (DAC) that operates within a power supply range from a ?33 V minimum on the AVSS pin to a +33 V maximum on the AVDD1 pin. The CHART pin enables a highway addressable remote transducer (HART?) signal to be ac-coupled on the current output.The AD5413 uses a versatile, 4-wire serial peripheral interface (SPI) that operates at clock rates of up to 50 MHz and is compatible with standard SPI, QSPI?, MICROWIRE?, digital signal processor (DSP), and microcontroller interface standards. The SPI interface has an optional SPI cyclic redundancy check (CRC). The AD5413 implements improved diagnostic features from earlier versions of similar DACs.APPLICATIONS Process control Actuator control Channel isolated analog outputs Programmable logic controller (PLC) and distributed control systems (DCS) applications HART network connectivity

The AD5412/AD5422 are low cost, precision, fully integrated12-/16-bit digital-to-analog converters (DAC) offering a programmable current source and programmable voltage output designed to meet the requirements of industrial process control applications.The output current range is programmable at 4 mA to 20 mA, 0 mA to 20 mA, or an overrange function of 0 mA to 24 mA.The LFCSP version of this product has a CAP2 pin so that the HART signals can be coupled onto the current output of the AD5412/AD5422.Voltage output is provided from a separate pin that can be configured to provide 0 V to 5 V, 0 V to 10 V, ?5 V, or ?10 V output ranges; an overrange of 10% is available on all ranges.Analog outputs are short and open-circuit protected and can drive capacitive loads of 1 ?F.The device operates with an AVDD power supply range from 10.8 V to 40 V. Current loop compliance voltage is 0 V to AVDD ? 2.5 V.The flexible serial interface is SPI- and MICROWIRE?-compatible and can be operated in 3-wire mode to minimize the digital isolation required in isolated applications.The device also includes a power-on-reset function, ensuring that the device powers up in a known state. The part also includes an asynchronous clear pin (CLEAR) that sets the outputs to zero-scale/midscale voltage output or the low end of the selected current range.The total output error is typically ?0.01% in current mode and ?0.01% in voltage mode.Applications Process controls Actuator controls PLC HART network connectivity (LFCSP package only)

The AD5590 is a 16-channel input and 16-channel output analog I/O port with eight uncommitted amplifiers, operating from a single 4.5 V to 5.25 V supply. The AD5590 comprises 16 input channels multiplexed into a 1 MSPS, 12-bit successive approximation ADC with a sequencer to allow a preprogrammed selection of channels to be converted sequentially. The ADC contains a low noise, wide bandwidth track-and-hold amplifier that can handle input frequencies in excess of 1 MHz.The conversion process and data acquisition are controlled using ASYNC and the serial clock signal, allowing the device to easily interface with microprocessors or DSPs. The input signal is sampled on the falling edge of ASYNC and conversion is also initiated at this point. There are no pipeline delays associated with the ADC. By setting the relevant bits in the control register, the analog input range for the ADC can be selected to be a 0 V to VREFA input or a 0 V to 2 ? VREFA with either straight binary or twos complement output coding. The conversion time is determined by the ASCLK frequency because it is also used as the master clock to control the conversion.The DAC section of the AD5590 comprises sixteen 12-bit DACs divided into two groups of eight. Each group has an on-chip reference. The on-board references are off at power-up, allowing the use of external references. The internal references are enabled via a software write.The AD5590 incorporates a power-on reset circuit that ensures that the DAC outputs power up to 0 V and remain powered up at this level until a valid write takes place. The DAC contains a power-down feature that reduces the current consumption of the device and provides software-selectable output loads while in power-down mode for any or all DAC channels. The outputs of all DACs can be updated simultaneously using the LDAC function, with the added functionality of user-selectable DAC channels to simultaneously update. There is also an asynchronous CLR that updates all DACs to a user-programmable code: zero scale, midscale, or full scale.The AD5590 contains eight low noise, single-supply amplifiers. These amplifiers can be used for signal conditioning for the ADCs, DACs, or other independent circuitry, if required.APPLICATIONS Optical Line Cards (Monitoring and Control) Base Stations General Purpose Analog I/O Monitoring and control

The AD5593R has eight input/output (I/O) pins, which can beindependently configured as digital-to-analog converter (DAC)outputs, analog-to-digital converter (ADC) inputs, digital outputs,or digital inputs. When an I/O pin is configured as an analogoutput, it is driven by a 12-bit DAC. The output range of theDAC is 0 V to VREF or 0 V to 2 ? VREF. When an I/O pin isconfigured as an analog input, it is connected to a 12-bit ADCvia an analog multiplexer. The input range of the ADC is 0 V toVREF or 0 V to 2 ? VREF. The I/O pins can also be configured tobe general-purpose, digital input or output (GPIO) pins. Thestate of the GPIO pins can be set or read back by accessing theGPIO write data register and GPIO read configuration registers,respectively, via an I2C write or read operation.The AD5593R has an integrated 2.5 V, 20 ppm/?C reference thatis turned off by default and an integrated temperature indicatorthat gives an indication of the die temperature. The temperaturevalue is read back as part of an ADC read sequence.The AD5593R is available in 16-lead TSSOP and LFCSP, as wellas a 16-ball WLCSP, and operates over a temperature range of?40?C to +105?C.Applications Control and monitoring General-purpose analog and digital I/O

The LTC4079 is a low quiescent current, high voltage linear charger for most battery chemistry types including Li-Ion/Polymer, LiFePO4, Lead-Acid or NiMH battery stacks up to 60V. The maximum charge current is adjustable from 10mA to 250mA with an external resistor. The battery charge voltage is set using an external resistor divider.With an integrated power device, current sensing and reverse current protection, a complete charging solution using the LTC4079 requires very few external components. Thermal regulation ensures maximum charge current up to the specified limit without the risk of overheating. Charging can be terminated by either C/10 or adjustable timer.Input voltage regulation reduces charge current when the input voltage falls to an adjustable level or the battery voltage, making it well suited for energy harvesting applications. Other features include temperature qualified charging, bad battery detection, automatic recharge with sampled feedback in standby for negligible battery drain, and an open-drain CHRG status output. The device is offered in a compact, thermally enhanced 10-lead (3mm ? 3mm) DFN package.APPLICATIONS Embedded Automotive and Industrial Backup Battery Charging from Another Battery Energy Harvesting Charger Thin Film Battery Products

The LTM4631 is a dual 10A or single 20A output switching mode step-down DC/DC ?Module? (power module) regulator. Included in the package are the switching controller, power FETs, inductors and all supporting components. Operating from an input voltage range of 4.5V to 15V, the LTM4631 supports two outputs each with an output voltage range of 0.6V to 1.8V, each set by a single external resistor. Its high efficiency design delivers up to 10A continuous current for each output. Only a few input and output capacitors are needed.The device supports frequency synchronization, multiphase operation, Burst Mode operation and output voltage tracking for supply rail sequencing and has an onboard temperature diode for device temperature monitoring. High switching frequency and a current mode architecture enable a very fast transient response to line and load changes without sacrificing stability.Fault protection features include overvoltage and overcurrent protection. The LTM4631 is offered in an ultrathin 16mm ? 16mm ? 1.91mm LGA and 16mm x 16mm x 2.51mm BGA packages. The LTM4631 is available with SnPb (BGA) or ROHS compliant terminal finish.Applications Telecom and Networking Equipment Storage and ATCA Cards Industrial Equipment

The LTM4630A is a dual 18A or single 36A output switchingmode step-down DC/DC ?Module? (micromodule)regulator with wider VOUT range and higher efficiencythan LTM4630. Included in the package are the switchingcontrollers, power FETs, inductors and all supportingcomponents. Operating from an input voltage range of4.5V to 18V, the LTM4630A supports two outputs eachwith an output voltage range of 0.6V to 8V, each set by asingle external resistor. Its high efficiency design deliversup to 18A continuous current for each output. Only a fewinput and output capacitors are needed. The LTM4630Ais pin compatible with the LTM4620 and LTM4620A (dual13A, single 26A) and the LTM4630 (dual 18A, single 36A).The device supports frequency synchronization, multiphaseoperation, Burst Mode operation and output voltagetracking for supply rail sequencing and has an onboardtemperature diode for device temperature monitoring. Highswitching frequency and a current mode architecture enablea very fast transient response to line and load changeswithout sacrificing stability.Fault protection features include overvoltage andovercurrent protection. The LTM4630A is offered in 16mm? 16mm ? 4.41mm LGA and 16mm ? 16mm ? 5.01mmBGA packages.*Maximum VIN = 15V and VOUT = 5.3V with date code before 1720 Features VOUT LTM4630 0.6V to 1.8V LTM4630-1 0.8% DC and 3% Transient Accuracy 0.6V to 1.8V LTM4630A Higher Light Load Efficiency 0.6V to 5.3V Applications Telecom and Networking Equipment Storage and ATCA Cards Industrial Equipment

The LTC6430-15 is a differential gain block amplifier designed to drive high resolution, high speed ADCs with excellent linearity beyond 1000MHz and with low associated output noise. The LTC6430-15 operates from a single 5V power supply and consumes only 800mW.In its differential configuration, the LTC6430-15 can directly drive the differential inputs of an ADC. Using 1:2 baluns, the device makes an excellent 50? wideband balanced amplifier. While using 1:1.33 baluns, the device makes a high fidelity 50MHz to 1000MHz 75? CATV amplifier.The LTC6430-15 is designed for ease of use, requiring a minimum of support components. The device is internally matched to 100? differential source/load impedance. On-chip bias and temperature compensation ensure consistent performance over environmental changes.The LTC6430-15 uses a high performance SiGe BiCMOS process for excellent repeatability compared with similar GaAs amplifiers. All A-grade LTC6430-15 devices are tested and guaranteed for OIP3 at 240MHz. The LTC6430-15 is housed in a 4mm ? 4mm, 24-lead, QFN package with an exposed pad for thermal management and low inductance. For a single-ended 50? IF gain block with similar performance, see the related LTC6431-15.Applications Differential ADC Driver Differential IF Amplifier OFDM Signal Chain Amplifier 50? Balanced IF Amplifier 75? CATV Amplifier 700MHz to 800MHz LTE Amplifier

Demonstration Circuit 2164A-A features a PolyPhase® design using two paralleled LTM4630EY-1's (A-grade), the high efficiency, high density, dual 18A, switch mode step-down power module regulator. The input voltage is from 4.5V to 15V. The output voltage is jumper selectable and can be set to 0.9V, 1.0V, 1.2V, 1.5V or 1.8V. DC2164A-A can deliver nominal 70A output current. As explained in the data sheet, output current derating is necessary for certain VIN, VOUT, and thermal conditions. The LTM4630-1A on DC2164A-A always operate in continuous conduction mode. The switching frequency can be programmed through a resistor or can be synchronized to an external clock signal. The board allows the user to program how its output voltage ramps up and down through the TRACK pin.
