The LTC3111 is a fixed frequency, synchronous buckboost DC/DC converter with an extended input and output range. The unique 4-switch, single inductor architecture provides low noise and seamless operation from input voltages above, below or equal to the output voltage.With an input and output range of 2.5V to 15V, the LTC3111 is well suited for a wide variety of single or multiple-cell batteries, back-up capacitor or wall adapter source applications. Low RDS(ON) internal N-channel MOSFET switches and selectable PWM or Burst Mode operation produce high efficiency over a wide range of operating conditions. An accurate RUN pin allows the user to program the turn-on threshold voltage of the converter. Other features include: short-circuit protection, internal soft-start and thermal shutdown.The LTC3111 is offered in both thermally enhanced 14-lead (3mm ? 4mm ? 0.75mm) DFN and 16-lead MSOP packages.Applications 3.3V or 5V from 1, 2 or 3 Li-Ion, Multiple-Cell?Alkaline/NiMH Batteries RF Transmitters Military, Industrial Power Systems

The LTC3787 is a high performance PolyPhase? single output synchronous boost converter controller that drives two N-channel power MOSFET stages out-of-phase. Multiphase operation reduces input and output capacitor requirements and allows the use of smaller inductors than the single-phase equivalent. Synchronous rectification increases efficiency, reduces power losses and eases thermal requirements, enabling high power boost applications. A 4.5V to 38V input supply range encompasses a wide range of system architectures and battery chemistries. When biased from the output of the boost converter or another auxiliary supply, the LTC3787 can operate from an input supply as low as 2.5V after start-up. The operating frequency can be set for a 50kHz to 900kHz range or synchronized to an external clock using the internal PLL. PolyPhase operation allows the LTC3787 to be configured for 2-, 3-, 4-, 6- and 12-phase operation. The SS pin ramps the output voltage during start-up. The PLLIN/MODE pin selects Burst Mode? operation, pulse- skipping mode or forced continuous mode at light loads.Applications Industrial Automotive Medical Military?

The LTC3622 is a dual 1A output, high efficiency synchronous monolithic step-down regulator capable of operating from input supplies up to 17V. The switching frequency is fixed to 1MHz or 2.25MHz with a ?50% synchronization range to an external clock. The regulator features ultralow quiescent current and high efficiency over a wide output voltage range.The step-down regulators operate from an input voltage range of 2.7V to 17V and provide an adjustable output from 0.6V to VIN while delivering up to 1A of output current. A user-selectable mode input is provided to allow the user to trade off ripple noise for light load efficiency. Burst Mode? operation provides the highest efficiency at light loads, while pulse-skipping mode provides the lowest ripple noise. The switching regulators can be synchronized to an external clock. Furthermore, fixed VOUT options are available to eliminate the external feedback resistors.? LTC3622 Options Part Name Frequency VOUT LTC3622 1.00MHz Adjustable LTC3622-2 2.25MHz Adjustable LTC3622-23/5 2.25MHZ 5V/3.3V ?Applications Battery Powered Systems Point-of-Load Supplies Portable ? Handheld Scanners

The LTC3862-2 is a two-phase constant frequency, current mode boost and SEPIC controller that drives N-channel power MOSFETs. Two-phase operation reduces system filtering capacitance and inductance requirements.The operating frequency can be set with an external resistor over a 75kHz to 500kHz range and can be synchronized to an external clock using the internal PLL. Multiphase operation is possible using the SYNC input, the CLKOUT output and the PHASEMODE control pin allowing 2-, 3-, 4-, 6- or 12-phase operation.Other features include an internal 10V LDO with undervoltage lockout protection for the gate drivers, a precision RUN pin threshold with programmable hysteresis, soft-start and programmable leading edge blanking and maximum duty cycle. Part Number Vin Range INTVcc UV+ UV- LTC3862 4V to 36V 5V 3.3V 2.9V LTC3862-1 8.5V to 36V 10V 7.5V 7.0V LTC3862-2 5.5V to 36V 10V 4.4V 3.9V Applications Automotive, Telecom and Industrial Power Supplies

Demonstration circuit 2007A-B features a PolyPhase® design using the LTM4630EV, the high efficiency, high density, dual 18A, switch mode step-down power μModule® regulator. The input voltage is from 4.5V to 15V. The output voltage is jumper selectable from 0.9V to 1.8V. The DC2007A-B can deliver a nominal 105A output current. As explained in the data sheet, output current derating is necessary for certain VIN, VOUT, and thermal conditions. The LTM4630 on DC2007A-B always operates in continuous conduction mode. The switching frequency can be programmed through a resistor or can be synchronized to an external clock signal.

The LTM8054 is a 36VIN, buck-boost ?Module?(micromodule) regulator. Included in the package are theswitching controller, power switches, inductor and supportcomponents. A resistor to set the switching frequency, aresistor divider to set the output voltage, and input andoutput capacitors are all that are needed to complete thedesign. Other features such as input and output averagecurrent regulation may be implemented with just a fewcomponents. The LTM8054 operates over an input voltagerange of 5V to 36V, and can regulate output voltagesbetween 1.2V and 36V. The SYNC input and CLKOUToutput allow easy synchronization.The LTM8054 is housed in a compact overmolded ballgrid array (BGA) package suitable for automated assemblyby standard surface mount equipment. The LTM8054 isRoHS compliant.Buck Boost Selection Table LTM8054 LTM8055 LTM8056 VIN (Operation) 36 36 58 VIN Abs Max 40 40 60 VOUT Abs Max 40 40 60 IOUT (Peak) 24VIN, 12VOUT 5.4 8.5 5.5 Package 15 x 11.25mm x 3.42mm BGA 15 x 15mm x 4.92mm BGA 15 x 15mm x 4.92mm BGA Applications High Power Battery-Operated Devices Industrial Control Solar Powered Voltage Regulator Solar Powered Battery Charging

Demonstration circuit 2024A features the LTC4282 high current Hot Swap™ controller. The LTC4282 is well suited to high power applications because the precise monitoring capability and accurate current limiting reduces the extremes in which both loads and power supplies must safely operate. Non-volatile configuration allows for flexibility in the autonomous generation of alerts and response to faults.

DC2042A - Demo Board for: LTC3588-1 Piezoelectric Energy Harvesting Power Supply LTC3108 Ultralow Voltage Step-Up Converter and Power Manager LTC3105 400mA Step-Up DC/DC Converter with Maximum Power Point Control and 250mV Start-Up LTC3459 10V Micropower Synchronous Boost Converter in ThinSOT LTC2935 Ultra-Low Power Supervisor with Power-Fail Output, Selectable Thresholds

Demonstration circuit 2044B is a 55V buck-boost multi-chemistry battery charger featuring the LTC4020. The board will accept an input voltage between 15V and 55V. The float voltage of the battery output (BAT) is 25.2V, with 3.3A maximum charge current. The converter output (VOUT) has a voltage range of 21V to 28V, with 3A maximum load current. The LTC4020 contains a high efficiency synchronous buck-boost DC/DC controller and uses a proprietary average current mode architecture. The LTC4020 battery charger can provide a constant-current/constant-voltage charge algorithm (CC/CV); a four-step, three-stage lead-acid battery-charge profile or constant-current charging (CC). Battery-chemistry type is selected using on-board jumper JP1. The LTC4020 data sheet gives a complete description of the IC operation and application information. The data sheet must be read in conjunction with the quick start guide.

The LTC1563-2/LTC1563-3 are a family of extremely easy-to-use, active RC lowpass filters with rail-to-rail inputs and outputs and low DC offset suitable for systems with a resolution of up to 16 bits. The LTC1563-2, with a single resistor value, gives a unity-gain Butterworth response. The LTC1563-3, with a single resistor value, gives a unity-gain Bessel response. The proprietary architecture of these parts allows for a simple resistor calculation:R = 10k (256kHz/fC); fC = Cutoff Frequencywhere fC is the desired cutoff frequency. For many applications,this formula is all that is needed to design a filter.By simply utilizing different valued resistors, gain andother responses are achieved.The LTC1563-X features a low power mode, for the lowerfrequency applications, where the supply current is reducedby an order of magnitude and a near zero powershutdown mode.The LTC1563-Xs are available in the narrow SSOP-16package (Same footprint as an SO-8 package).Applications Discrete RC Active Filters and Modules Antialiasing Filters Smoothing or Reconstruction Filters Linear Phase Filtering for Data Communication Phase Locked Loops
