The ADL5320 incorporates a dynamically adjustable biasing circuit that allows for the customization of OIP3 and P1dB performance from 3.3 V to 5 V without the need for an external bias resistor. This feature gives the designer the ability to tailor driver amplifier performance to the specific needs of the design. This feature also creates the opportunity for dynamic biasing of the driver amplifier, where a variable supply is used to allow for full 5 V biasing under large signal conditions and then can reduce the supply voltage when signal levels are smaller and lower power consumption is desirable. This scalability reduces the need to evaluate and inventory multiple driver amplifiers for different output power requirements from 22 dBm to 26 dBm output power levels.The ADL5320 is also rated to operate across the wide temperature range of ?40?C to +105?C for reliable performance in designs that experience higher temperatures, such as power amplifiers. The 1?4 watt driver amplifier also covers the 400 MHz to 2700 MHz wide frequency range and only requires a few external components to be tuned to a specific band within that wide range. This high performance, broadband RF driver amplifier is well suited for a variety of wired and wireless applications including cellular infrastructure, ISM band power amplifiers, defense equipment, and instrumentation equipment. A fully populated evaluation board is available.The ADL5320 also delivers excellent adjacent channel power ratio (ACPR) vs. output power and bias voltage. The driver can deliver greater than 17 dBm of output power at 2140 MHz while achieving an ACPR of ?55 dBc at 5 V. If the bias is reduced to 3.3 V, the ?55 dBc ACPR output power reduces to 9 dBm.Applications Wireless infrastructure Automated test equipment ISM/AMR applications

The ADL5321 is a broadband, linear driver RF amplifier that operates at frequencies from 2.3 GHz to 4.0 GHz. The device can be used in a wide variety of wired and wireless applications, including ISM, WLL, PCS, GSM, CDMA, and W-CDMA.The ADL5321 operates with a 5 V supply voltage and a supply current of 90 mA.The ADL5321 is fabricated on the GaAs HBT process. The device is packaged in a low cost SOT-89 that uses an exposed paddle for excellent thermal impedance. It operates from ?40?C to +105?C, and a fully populated evaluation board is available.The ADL5320 is a companion part to the ADL5321 that operates at similar performance from 400 MHz to 2700 MHz.

The ADL5372 is a member of the fixed-gain quadrature modulator(F-MOD) family designed for use from 1500 MHz to 2500 MHz.Its excellent phase accuracy and amplitude balance enable highperformance intermediate frequency or direct radio frequencymodulation for communication systems.The ADL5372 provides a >500 MHz, 3 dB baseband bandwidth,making it ideally suited for use in broadband zero IF or lowIF-to-RF applications and in broadband digital predistortiontransmitters. The ADL5372 accepts two differential baseband inputs and asingle-ended, local oscillator (LO) and generates a single-endedoutput.The ADL5372 is fabricated using the Analog Devices, Inc.,advanced silicon-germanium bipolar process. It is available ina 24-lead, exposed-paddle, RoHS compliant, LFCSP. Performanceis specified over a ?40?C to +85?C temperature range. A RoHScompliant evaluation board is available. Applications Cellular communication systems:?CDMA2000/GSM/WCDMA WiMAX/broadband wireless access systems Satellite modems

The ADL5373 supports a frequency of operation from 2300 MHzto 3000 MHz and is a pin-compatible member of the fixed gainquadrature modulator (F-MOD) family designed for use from300 MHz to 4000 MHz. The ADL5373 provides excellent phaseaccuracy and amplitude balance enabling high performanceintermediate frequency or direct radio frequency modulationfor communications systems.The ADL5373 provides a >500 MHz, 3 dB baseband bandwidth,making it ideally suited for use in broadband zero IF or lowIF-to-RF applications and in broadband digital predistortiontransmitters. The ADL5373 accepts two differential baseband inputs that aremixed with a local oscillator (LO) to generate a single-endedoutput.The ADL5373 is fabricated using the Analog Devices, Inc.advanced silicon-germanium bipolar process. It is availablein a 24-lead, exposed paddle, Pb-free LFCSP. Performance isspecified over a ?40?C to +85?C temperature range. A Pb-freeevaluation board is available.Applications WiMAX/broadband wireless access systems Satellite modems

The ADL5385 is a silicon, monolithic, quadrature modulatordesigned for use from 30 MHz to 2200 MHz. Its excellent phaseaccuracy and amplitude balance enable both high performanceintermediate frequency (IF) and direct radio frequency (RF)modulation for communication systems.The ADL5385 takes the signals from two differential basebandinputs and modulates them onto two carriers in quadraturewith each other. The two internal carriers are derived from asingle-ended, external local oscillator input signal at twice thefrequency as the desired carrier output. The two modulatedsignals are summed together in a differential-to-single-endedamplifier designed to drive 50 ? loads.The ADL5385 can be used as either an IF or a direct-to-RFmodulator in digital communication systems. The widebaseband input bandwidth allows for either baseband drive ordrive from a complex IF. Typical applications are in radio-linktransmitters, cable modem termination systems, and broadbandwireless access systems.The ADL5385 is fabricated using the Analog Devices, Inc.,advanced silicon germanium bipolar process and is packaged ina 24-lead, RoHS-compliant LFCSP with exposed pad. Performanceis specified over ?40?C to +85?C. A RoHS-compliant evaluationboard is also available.Applications Radio-link infrastructure Cable modem termination systems UHF/VHF radio Wireless infrastructure systems Wireless local loop WiMAX/broadband wireless access systems

The ADL5387 is a broadband quadrature I/Q demodulator that covers an RF/IF input frequency range from 30 MHz to 2 GHz. With a NF = 13.2 dB, IP1dB = 12.7 dBm, and IIP3 = 32 dBm @ 450 MHz, the ADL5387 demodulator offers outstanding dynamic range suitable for the demanding infrastructure direct-conversion requirements. The differential RF/IF inputs provide a well-behaved broadband input impedance of 50 ? and are best driven from a 1:1 balun for optimum performance.Ultrabroadband operation is achieved with a divide-by-2 method for local oscillator (LO) quadrature generation. Over a wide range of LO levels, excellent demodulation accuracy is achieved with amplitude and phase balances ~0.05 dB and ~0.4?, respectively. The demodulated in-phase (I) and quadrature (Q) differential outputs are fully buffered and provide a voltage conversion gain of >4 dB. The buffered baseband outputs are capable of driving a 2 Vp-p differential signal into 200 ?.The fully balanced design minimizes effects from second-order distortion. The leakage from the LO port to the RF port is 60 dBm.The ADL5387 operates off a single 4.75 V to 5.25 V supply. The supply current is adjustable with an external resistor from the BIAS pin to ground.The ADL5387 is fabricated using the Analog Devices, Inc. advanced silicon-germanium bipolar process and is available in a 24-lead exposed paddle LFCSP.APPLICATIONS QAM/QPSK RF/IF demodulators W-CDMA/CDMA/CDMA2000/GSM Microwave point-to-(multi)point radios Broadband wireless and WiMAX Broadband CATVs

The ADL5531 is a broadband, fixed-gain, linear amplifier that operates at frequencies up to 500 MHz. The device can be used in a wide variety of equipment, including cellular, satellite, broadband, and instrumentation equipment.The ADL5531 provides a gain of 20 dB, which is stable over frequency, temperature, power supply, and from device to device. This amplifier is single-ended and internally matched to 50 ?. Only input/output ac coupling capacitors, power supply decoupling capacitors, and external inductors are required for operation.The ADL5531 is fabricated on a GaAs HBT process and has an ESD rating of ?2 kV (Class 2). The device is packaged in an 8-lead 3 mm ? 3 mm LFCSP that uses an exposed paddle for excellent thermal impedance.The ADL5531 consumes 100 mA on a single 5 V supply and is fully specified for operation from ?40?C to +85?C.The dual-channel 20 dB gain version, ADL5534, is also available.

The ADL5569 is a high performance, dual, differential amplifier with 20 dB of voltage gain, optimized for applications spanning from dc to 6.5 GHz. The amplifier is available in a dual format, and it offers a low referred to input (RTI) noise spectral density (NSD) of 1.0 nV/?Hz (at 100 MHz) and excellent distortion performance over a wide frequency range, making it an ideal driver for high speed 12-bit to 16-bit analog-to-digital converters (ADCs). The ADL5569 is ideally suited for use in high performance zero intermediate frequency (IF) and complex IF receiver designs. In addition, this device has excellent low distortion for single-ended input driver applications.Using two external series resistors for each amplifier expands the gain flexibility of the amplifier and allows any gain selection from 6 dB to 20 dB for a differential input. For a single-ended input, the gain can be adjusted from 6 dB to 17 dB with the addition of some external resistors. This device maintains low distortion through its output common-mode range of 2.0 V to 3.0 V, providing a flexible capability for driving ADCs with ac levels up to 2 VP-P.Operating from a single 5 V supply, the quiescent current of the ADL5569 is typically 86 mA per amplifier. When disabled, the amplifiers consume only 8 mA per amplifier.The device is optimized for wideband, low distortion, and low noise operation, giving it unprecedented second harmonic distortion (HD2) and third harmonic distortion (HD3) from dc to 4 GHz. These attributes, together with its adjustable gain capability, make this device the amplifier of choice for driving a wide variety of ADCs, mixers, pin diode attenuators, surface acoustic wave (SAW) filters, and a multitude of discrete radio frequency (RF) devices.Fabricated on an Analog Devices, Inc., high speed silicon germanium (SiGe) process, the ADL5569 is supplied in a compact 2.5 mm ? 3 mm, 16-lead LFCSP package and operates over the ?40?C to +85?C temperature range.APPLICATIONS Differential ADC drivers for GSPS ADCs High speed data acquisition Single-ended to differential conversion DAC buffering DC coupling and level shifting RF/IF gain blocks Balun alternative from dc to 4 GHz SAW filter interfacing

The ADL5606 is a broadband, two-stage, 1 W RF driver amplifier that operates over a frequency range of 1800 MHz to 2700 MHz. The device can be used in a wide variety of wired and wireless applications, including ISM, MC-GSM, W-CDMA, TD-SCDMA, and LTE.The ADL5606 operates on a 5 V supply voltage and a supply current of 362 mA. The driver also incorporates a fast power-up/power-down function for TDD applications, applications that require a power saving mode, and applications that intermittently transmit data.The ADL5606 is fabricated on a GaAs HBT process and is packaged in a compact 4 mm ? 4 mm, 16-lead LFCSP that uses an exposed paddle for excellent thermal impedance. The ADL5606 operates from ?40?C to +85?C. A fully populated evaluation board tuned to 2140 MHz is also available.Applications Wireless infrastructure Automated test equipment ISM/AMR applications

The ADL5721 is a narrow-band, high performance, low noise amplifier targeting microwave radio link receiver designs. The monolithic silicon germanium (SiGe) design is optimized for microwave radio link bands ranging from 5.9 GHz to 8.5 GHz. The unique design offers a single-ended 50 ? input impedance and provides a 100 ? balanced differential output that is ideal for driving Analog Devices, Inc., differential downconverters and radio frequency (RF) sampling analog-to-digital converters (ADCs). This low noise amplifier (LNA) provides noise figure performance that, in the past, required more expensive three-five (III-V) compounds process technology to achieve. This LNA uses a band switch feature to allow the input P1dB and noise figure to trade off for optimum system performance.The ADL5721 and ADL5723 to ADL5726 family of narrow-band LNAs are each packaged in a tiny, thermally enhanced, 2.00 mm ? 2.00 mm LFCSP package. The ADL5721 and ADL5723 to ADL5726 family operates over the temperature range of ?40?C to +85?C.Applications Point to point microwave radios Instrumentation Satellite communications (SATCOM) Phased arrays
