The ADG5248F and ADG5249F are 8:1 and dual 4:1 analog multiplexers. The ADG5248F switches one of eight inputs to a common output and the ADG5249F switches one of four differential inputs to a common differential output. Each channel conducts equally well in both directions when on, and each channel has an input signal range that extends to the supplies. The primary supply voltages define the on-resistance profile, whereas the secondary supply voltages define the voltage level at which the overvoltage protection engages.When no power supplies are present, the channel remains in the off condition, and the switch inputs are high impedance. Under normal operating conditions, if the analog input signal levels on any Sx pin exceed positive fault voltage (POSFV) or negative fault voltage (NEGFV) by a threshold voltage (VT), the channel turns off and that Sx pin becomes high impedance. If the switch is selected to be on, then the drain pin is pulled to the secondary supply voltage that was exceeded. Input signal levels up to +55 V or ?55 V relative to ground are blocked, in both the powered and unpowered condition.The low capacitance and charge injection of these switches make them ideal solutions for data acquisition and sample-and-hold applications, where low glitch switching and fast settling times are required.?Note that, throughout this data sheet, multifunction pins, such as A0/F2, are referred to either by the entire pin name or by a single function of the pin, for example, A0, when only that function is relevant.?Product Highlights Source pins are protected against voltages greater than the secondary supply rails, up to ?55 V and +55 V. Source pins are protected against voltages between ?55 V and +55 V in an unpowered state. Overvoltage detection with digital output indicates operating state of switches. Trench isolation guards against latch-up. Optimized for low charge injection and on-capacitance. The ADG5248F/ADG5249F can be operated from a dual?supply of ?5 V to ?22 V or a single power supply of 8 V to 44 V.Applications Analog input/output modules Process control/distributed control systems Data acquisition Instrumentation Avionics Automatic test equipment Communication systems Relay replacement

The ADG5412F and ADG5413F contain four independently controlled single-pole/single-throw (SPST) switches. The ADG5412F has four switches that turn on with Logic 1 inputs. The ADG5413F has two switches with that turn on and two switches that turn off with Logic 1 inputs. Each switch conducts equally well in both directions when on, and each switch has an input signal range that extends to the supplies. The digital inputs are compatible with 3 V logic inputs over the full operating supply range.When no power supplies are present, the switch remains in the off condition, and the switch inputs are high impedance. Under normal operating conditions, if the analog input signal levels on any Sx pin exceed VDD or VSS by a threshold voltage, VT, then the switch turns off. Input signal levels up to +55 V or ?55 V relative to ground are blocked, in both the powered and unpowered condition.The low on resistance of these switches, combined with on-resistance flatness over a significant portion of the signal range make them an ideal solution for data acquisition and gain switching applications where excellent linearity and low distortion are critical.Product Highlights Source pins are protected against voltages greater than the supply rails, up to ?55 V and +55 V. Source pins are protected against voltages between ?55 V and +55 V, in an unpowered state. Overvoltage detection with digital output indicates operating state of switches. Trench isolation guards against latch-up. Optimized for low on resistance and on-resistance flatness. The ADG5412F/ADG5413F can be operated from a dual?supply of ?5 V up to ?22 V or a single power supply of 8 V up to 44 V.Applications Analog input/output modules Process control/distributed control systems Data acquisition Instrumentation Avionics Automatic test equipment Communication systems Relay replacement

The ADG918/ADG919 are wideband switches using a CMOSprocess to provide high isolation and low insertion loss to1 GHz. The ADG918 is an absorptive (matched) switch having50 ? terminated shunt legs, whereas the ADG919 is a reflectiveswitch. These devices are designed such that the isolation ishigh over the dc to 1 GHz frequency range. They have on-boardCMOS control logic, thus eliminating the need for externalcontrolling circuitry. The control inputs are both CMOS andLVTTL compatible. The low power consumption of theseCMOS devices makes them ideally suited to wireless andgeneral-purpose high frequency switching applications.Product Highlights ?43 dB off isolation at 1 GHz. 0.8 dB insertion loss at 1 GHz. Tiny 8-lead MSOP/LFCSP.Applications Wireless communications General-purpose RF switching Dual-band applications High speed filter selection Digital transceiver front end switch IF switching Tuner modules Antenna diversity switching

The ADGM1304 is a wideband, single-pole, four-throw (SP4T) switch, fabricated using Analog Devices, Inc., microelectro-mechanical system (MEMS) switch technology. This technology enables a small form factor, wide RF bandwidth, highly linear, low insertion loss switch that is operational from 0 Hz/dc to 14 GHz, making the ADGM1304 an ideal solution for a wide range of RF and precision equipment switching needs.An integrated driver chip generates a high voltage to electrostatically actuate a switch that can be controlled by a parallel interface and a serial peripheral interface (SPI). All four switches are independently controllable.The device is packaged in a 24-lead, 5 mm ? 4 mm ? 0.95 mm, lead frame chip-scale package (LFCSP).To ensure optimum operation of the ADGM1304, the Critical Operational Requirements section must be followed exactly.The on resistance (RON) performance of the ADGM1304 is affected by device to device variation, channel to channel variation, cycle actuations, settling time post turn on, bias voltage, and temperature changes.APPLICATIONS Relay replacements Automatic test equipment: RF/high speed digital and mixed signals Load and probe boards: RF/high speed digital and mixed signals RF test instrumentation Reconfigurable filters and attenuators High performance RF switching

The ADGS1212 contains four independent single-pole/single-throw(SPST) switches. A serial peripheral interface (SPI)controls the switches. The SPI interface has robust error detectionfeatures such as cyclic redundancy check (CRC) error detection,invalid read/write address detection, and SCLK count errordetection.It is possible to daisy-chain multiple ADGS1212 devices together.Daisy-chain mode enables the configuration of multiple deviceswith minimal digital lines. The ADGS1212 can also operate inburst mode to decrease the time between SPI commands.iCMOS construction ensures ultralow power dissipation, makingthe device ideal for portable and battery-powered instruments.Each switch conducts equally well in both directions when on,and each switch has an input signal range that extends to thesupplies.In the off condition, signal levels up to the supplies are blocked.The ultralow capacitance and charge injection of these switchesmake them ideal solutions for data acquisition and sample-andholdapplications where low glitch and fast settling are required.Fast switching speed coupled with high signal bandwidth makethe device suitable for video signal switching.Multifunction pin names may be referenced by their relevantfunction only.Product Highlights SPI interface removes the need for parallel conversion, logic traces, and reduces the general-purpose input/output (GPIO) channel count. Daisy-chain mode removes additional logic traces when multiple devices are used. CRC error detection, invalid read/write address detection, and SCLK count error detection ensure a robust digital interface. CRC and error detection capabilities allow the ADGS1212 to be used in safety critical systems. Guaranteed break-before-make switching allows the the ADGS1212 to be used in multiplexer configurations with external wiring. The ADGS1212 1.8 V logic compatibility with 2.7 V ? VL ? 3.3 V Ultralow capacitance. <1 pC charge injection.Applications Automated test equipment Data acquisition systems Battery-powered systems Sample-and-hold systems Audio signal routing Video signal routing Communications systems

The ADM1064 Super Sequencer? is a configurable supervisory/ sequencing device that offers a single-chip solution for supply monitoring and sequencing in multiple supply systems. In addition to these functions, the ADM1064 integrates a 12-bit ADC that can be used to accurately read back up to 12 separate voltages. The device also provides up to 10 programmable inputs for moni-toring undervoltage faults, overvoltage faults, or out-of-window faults on up to 10 supplies. In addition, 10 programmable outputs can be used as logic enables. Six of these programmable outputs can provide up to a 12 V output for driving the gate of an N-FET that can be placed in the path of a supply. ApplicationsCentral office systemsServers/routersMultivoltage system line cardsDSP/FPGA supply sequencingIn-circuit testing of margined supplies

The ADM2482E/ADM2487E are isolated data transceivers with ?15 kV ESD protection and are suitable for high speed, half-duplex or full-duplex communication on multipoint transmission lines. For half-duplex operation, the transmitter outputs and receiver inputs share the same transmission line. Transmitter Output Pin Y is linked externally to Receiver Input Pin A, and Transmitter Output Pin Z to Receiver Input Pin B. The parts are designed for balanced transmission lines and comply with TIA/EIA- 485-A-98 and ISO 8482:1987(E).The devices employ the Analog Devices, Inc., iCoupler? technology to combine a 3-channel isolator, a three-state differential line driver, and a differential input receiver into a single package. An on-chip oscillator outputs a pair of square waveforms that drive an external transformer to provide isolated power. The logic side of the device can be powered with either a 5 V or a 3.3 V supply, and the bus side is powered with an isolated 3.3 V supply.The ADM2482E/ADM2487E driver has an active high enable, and the receiver has an active low enable. The driver output enters a high impedance state when the driver enable signal is low. The receiver output enters a high impedance state when the receiver enable signal is high.The device has current-limiting and thermal shutdown features to protect against output short circuits and situations where bus contention might cause excessive power dissipation. The part is fully specified over the industrial temperature range of ?40?C to +85?C and is available in a 16-lead, wide-body SOIC package.Applications Isolated RS-485/RS-422 interfaces Industrial field networks Multipoint data transmission systems

The ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E are 3.0 V to5.5 V, IEC electrostatic discharge (ESD) protected RS-485transceivers, allowing the devices to withstand ?12 kV contactdischarges on the transceiver bus pins without latch-up ordamage. The ADM3062E/ADM3064E/ADM3066E/ADM3068Efeature a VIO logic supply pin that allows a flexible digital interfacecapable of operating as low as 1.62 V. The ADM3065E/ADM3066E/ADM3067E/ADM3068E aresuitable for high speed, 50 Mbps, bidirectional data communication on multipoint bus transmission lines. The ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E feature a 1/4 unit load inputimpedance that allows up to 128 transceivers on a bus. TheADM3061E/ADM3062E/ADM3063E/ADM3064E models offerall of the same features as the ADM3065E/ADM3066E/ADM3067E/ADM3068E models at a low 500 kbps data rate thatis suitable for operation over long cable runs. The ADM3061E/ADM3062E/ADM3065E/ADM3066E are halfduplex RS-485 transceivers, fully compliant to the PROFIBUS?standard with increased 2.1 V bus differential voltage at VCC ?4.5 V. The ADM3063E/ADM3064E/ADM3067E/ADM3068Eare full duplex RS-485 transceiver options. The RS-485 transceivers are available in a number of spacesaving packages, including the 10-lead, 3 mm ? 3 mm lead framechip-scale package (LFCSP), the 8-lead or 10-lead, 3 mm ? 3 mmmini small outline package (MSOP), and the 8-lead or 14-lead,narrow body standard small outline packages (SOIC_N).Models with operating temperature ranges of ?40?C to +125?Cand ?40?C to +85?C are available. Excessive power dissipation caused by bus contention or byoutput shorting is prevented by a thermal shutdown circuit. If asignificant temperature increase is detected in the internal drivercircuitry during fault conditions, this feature forces the driveroutput into a high impedance state. The ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E guarantee alogic high receiver output when the receiver inputs are shorted,open, or connected to a terminated transmission line with alldrivers disabled. Table 2 in the data sheet presents an overview of the ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E data rate capability across temperature, power supply,and package options. Refer to the Ordering Guide section formodel numbering.APPLICATIONS Industrial fieldbuses Process control Building automation PROFIBUS networks Motor control servo drives and encoders?

The ADM3095E is a 3.0 V to 5.5 V, 2.5 Mbps, RS-485 transceiverthat features up to ?42 V ac/dc peak bus overvoltage faultprotection on the RS-485 bus pins. This device is designed towithstand overvoltage faults, such as short circuits directly to powersupplies, and overvoltage faults, such as ?24 V ac suppliesconnected in error to the RS-485 A and B bus pins. TheADM3095E is an RS-485 transceiver that integrates IEC 61000-4-5Level 4 surge protection, allowing up to ?4 kV protection onthe RS-485 bus pins. The device has IEC 61000-4-4 Level 4electrical fast transient (EFT) protection up to ?2 kV, andIEC 61000-4-2 Level 4 electrostatic discharge (ESD) protectionon the bus pins, allowing the device to withstand up to ?15 kVon the transceiver interface pins without latch-up or damage.This device has an extended common-mode input voltage rangeof ?25 V to improve data communication reliability in noisyenvironments over long cable lengths where ground loop voltagesare possible. The combination of extended common-mode inputvoltage range, overvoltage fault protection, surge protection, EFTprotection, and ESD protection make the ADM3095E acompletely integrated electromagnetic compatibility (EMC)protected RS-485 transceiver.The ADM3095E also features a logic supply pin, VIO, for a flexibledigital interface, operational to voltages as low as 1.62 V. TheADM3095E is PROFIBUS? compliant with a high driverdifferential output voltage, VOD, of 2.1 V minimum at power supplyvoltages greater than 4.5 V. The device is fully characterized overextended operating temperature ranges, with options of ?40?C to+125?C, and is available in a 16-lead, narrow body SOIC package..Applications Heating ventilation and air conditioning (HVAC) networks Industrial field buses Building automation Utility networks

The ADN4654/ADN4655/ADN46561? are signal isolated, low voltage differential signaling (LVDS) buffers that operate at up to 1.1 Gbps with low jitter. The devices integrate Analog Devices, Inc., iCoupler? technology, enhanced for high speed operation to provide galvanic isolation of the TIA/EIA-644-A compliant LVDS drivers and receivers. This integration allows drop-in isolation of an LVDS signal chain.The ADN4654/ADN4655/ADN4656 comprise multiple channel configurations, and the LVDS receivers on the ADN4655 and ADN4656 include a fail-safe mechanism to ensure a Logic 1 on the corresponding LVDS driver output when the inputs are floating, shorted, or terminated but not driven.For high speed operation with low jitter, the LVDS and isolator circuits rely on a 2.5 V supply. An integrated on-chip low dropout (LDO) regulator can provide the required 2.5 V from an external 3.3 V power supply. The devices are fully specified over a wide industrial temperature range and come in a 20-lead, wide body SOIC_W package with 5 kV rms isolation or in a 20-lead SSOP package with 3.75 kV rms isolation.Applications Isolated video and imaging data Analog front-end isolation Data plane isolation Isolated high speed clock and data links1 Protected by U.S. Patents 5,952,849; 6,873,065; 6,903,578; and 7,075,329. Other patents are pending.
