The ADM3050E is a 5.7 kV rms isolated controller area network (CAN) physical layer transceiver with a high performance, basic feature set. The ADM3050E fully meets the CAN flexible data rate (CAN FD) ISO 11898-2:2016 requirements and is further capable of supporting data rates as high as 12 Mbps.The device employs Analog Devices, Inc., iCoupler? technology to combine a 2-channel isolator and a CAN transceiver into a single small outline integrated circuit (SOIC) surface-mount package. The ADM3050E is a fully isolated solution for CAN and CAN FD applications. The ADM3050E provides isolation between the CAN controller and physical layer bus. Safety and regulatory approvals (pending) for a 5.7 kV rms withstand voltage, an 849 VPEAK working voltage, and a 12.8 kV surge test, ensure that the ADM3050E meets application isolation requirements.Low loop propagation delays and the extended common-mode range of ?25 V support robust communication on longer bus cables. Dominant timeout functionality protects against bus lock up in a fault condition, and current limiting and thermal shutdown features protect against output short circuits. The CAN bus input and output pins are protected to ?40 V against accidental connection to a +24 V bus supply. The device is fully specified over the ?40?C to +125?C industrial temperature range.Applications CANOpen, DeviceNet, and other CAN bus implementations Industrial automation Process control and building control Transport and infrastructure

The ADM3055E/ADM3057E are 5 kV rms and 3 kV rms isolated controller area network (CAN) physical layer transceivers with integrated isolated dc-to-dc converters. The ADM3055E/ADM3057E meet flexible data rate (CAN FD) requirements for operation to 5 Mbps and higher and comply with the ISO 11898-2: 2016 standard. The ADM3055E/ADM3057E are capable of supporting data rates as high as 12 Mbps.The devices employ Analog Devices, Inc., iCoupler? technology to combine a 3-channel isolator, a CAN transceiver, and an Analog Devices isoPower? dc-to-dc converter into a single, surface-mount, small outline integrated circuit (SOIC) package. The devices are powered by a single 5 V supply, realizing a fully isolated solution for CAN and CAN FD. Radiated emissions from the high frequency switching of the dc-to-dc convertors are kept below EN 55022 Class B limits by continuous adjustments to the switching frequency.The ADM3055E/ADM3057E provide complete isolation between the CAN controller and physical layer bus. Safety and regulatory approvals (pending) for 5 kV rms isolation voltage, 10 kV surge test, and 8.3 mm creepage and clearance ensure the ADM3055E meets application reinforced isolation requirements. The ADM3057E has an isolation voltage of 3 kV rms and 7.8 mm creepage in a 20-lead, wide body SOIC.Low propagation delays through the isolation support longer bus cables. Slope control mode is available for standard CAN at low data rates. Standby mode minimizes power consumption when the bus is idle or if the node goes offline. Silent mode allows the TXD input to be ignored for listen only mode.Dominant timeout functionality protects against bus lock up in a fault condition. The current limiting and thermal shutdown features protect against output short circuits. The devices are fully specified over an industrial temperature range of ?40?C to +105?C.Applications CANOpen, DeviceNet, and other CAN bus implementations Industrial automation Process control and building control Transport and infrastructure

The ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E are 3.0 V to5.5 V, IEC electrostatic discharge (ESD) protected RS-485transceivers, allowing the devices to withstand ?12 kV contactdischarges on the transceiver bus pins without latch-up ordamage. The ADM3062E/ADM3064E/ADM3066E/ADM3068Efeature a VIO logic supply pin that allows a flexible digital interfacecapable of operating as low as 1.62 V. The ADM3065E/ADM3066E/ADM3067E/ADM3068E aresuitable for high speed, 50 Mbps, bidirectional data communication on multipoint bus transmission lines. The ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E feature a 1/4 unit load inputimpedance that allows up to 128 transceivers on a bus. TheADM3061E/ADM3062E/ADM3063E/ADM3064E models offerall of the same features as the ADM3065E/ADM3066E/ADM3067E/ADM3068E models at a low 500 kbps data rate thatis suitable for operation over long cable runs. The ADM3061E/ADM3062E/ADM3065E/ADM3066E are halfduplex RS-485 transceivers, fully compliant to the PROFIBUS?standard with increased 2.1 V bus differential voltage at VCC ?4.5 V. The ADM3063E/ADM3064E/ADM3067E/ADM3068Eare full duplex RS-485 transceiver options. The RS-485 transceivers are available in a number of spacesaving packages, including the 10-lead, 3 mm ? 3 mm lead framechip-scale package (LFCSP), the 8-lead or 10-lead, 3 mm ? 3 mmmini small outline package (MSOP), and the 8-lead or 14-lead,narrow body standard small outline packages (SOIC_N).Models with operating temperature ranges of ?40?C to +125?Cand ?40?C to +85?C are available. Excessive power dissipation caused by bus contention or byoutput shorting is prevented by a thermal shutdown circuit. If asignificant temperature increase is detected in the internal drivercircuitry during fault conditions, this feature forces the driveroutput into a high impedance state. The ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E guarantee alogic high receiver output when the receiver inputs are shorted,open, or connected to a terminated transmission line with alldrivers disabled. Table 2 in the data sheet presents an overview of the ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E data rate capability across temperature, power supply,and package options. Refer to the Ordering Guide section formodel numbering.APPLICATIONS Industrial fieldbuses Process control Building automation PROFIBUS networks Motor control servo drives and encoders?

The ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E are 3.0 V to5.5 V, IEC electrostatic discharge (ESD) protected RS-485transceivers, allowing the devices to withstand ?12 kV contactdischarges on the transceiver bus pins without latch-up ordamage. The ADM3062E/ADM3064E/ADM3066E/ADM3068Efeature a VIO logic supply pin that allows a flexible digital interfacecapable of operating as low as 1.62 V. The ADM3065E/ADM3066E/ADM3067E/ADM3068E aresuitable for high speed, 50 Mbps, bidirectional data communication on multipoint bus transmission lines. The ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E feature a 1/4 unit load inputimpedance that allows up to 128 transceivers on a bus. TheADM3061E/ADM3062E/ADM3063E/ADM3064E models offerall of the same features as the ADM3065E/ADM3066E/ADM3067E/ADM3068E models at a low 500 kbps data rate thatis suitable for operation over long cable runs. The ADM3061E/ADM3062E/ADM3065E/ADM3066E are halfduplex RS-485 transceivers, fully compliant to the PROFIBUS?standard with increased 2.1 V bus differential voltage at VCC ?4.5 V. The ADM3063E/ADM3064E/ADM3067E/ADM3068Eare full duplex RS-485 transceiver options. The RS-485 transceivers are available in a number of spacesaving packages, including the 10-lead, 3 mm ? 3 mm lead framechip-scale package (LFCSP), the 8-lead or 10-lead, 3 mm ? 3 mmmini small outline package (MSOP), and the 8-lead or 14-lead,narrow body standard small outline packages (SOIC_N).Models with operating temperature ranges of ?40?C to +125?Cand ?40?C to +85?C are available. Excessive power dissipation caused by bus contention or byoutput shorting is prevented by a thermal shutdown circuit. If asignificant temperature increase is detected in the internal drivercircuitry during fault conditions, this feature forces the driveroutput into a high impedance state. The ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E guarantee alogic high receiver output when the receiver inputs are shorted,open, or connected to a terminated transmission line with alldrivers disabled. Table 2 in the data sheet presents an overview of the ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E data rate capability across temperature, power supply,and package options. Refer to the Ordering Guide section formodel numbering.APPLICATIONS Industrial fieldbuses Process control Building automation PROFIBUS networks Motor control servo drives and encoders?

The ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E are 3.0 V to5.5 V, IEC electrostatic discharge (ESD) protected RS-485transceivers, allowing the devices to withstand ?12 kV contactdischarges on the transceiver bus pins without latch-up ordamage. The ADM3062E/ADM3064E/ADM3066E/ADM3068Efeature a VIO logic supply pin that allows a flexible digital interfacecapable of operating as low as 1.62 V. The ADM3065E/ADM3066E/ADM3067E/ADM3068E aresuitable for high speed, 50 Mbps, bidirectional data communication on multipoint bus transmission lines. The ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E feature a 1/4 unit load inputimpedance that allows up to 128 transceivers on a bus. TheADM3061E/ADM3062E/ADM3063E/ADM3064E models offerall of the same features as the ADM3065E/ADM3066E/ADM3067E/ADM3068E models at a low 500 kbps data rate thatis suitable for operation over long cable runs. The ADM3061E/ADM3062E/ADM3065E/ADM3066E are halfduplex RS-485 transceivers, fully compliant to the PROFIBUS?standard with increased 2.1 V bus differential voltage at VCC ?4.5 V. The ADM3063E/ADM3064E/ADM3067E/ADM3068Eare full duplex RS-485 transceiver options. The RS-485 transceivers are available in a number of spacesaving packages, including the 10-lead, 3 mm ? 3 mm lead framechip-scale package (LFCSP), the 8-lead or 10-lead, 3 mm ? 3 mmmini small outline package (MSOP), and the 8-lead or 14-lead,narrow body standard small outline packages (SOIC_N).Models with operating temperature ranges of ?40?C to +125?Cand ?40?C to +85?C are available. Excessive power dissipation caused by bus contention or byoutput shorting is prevented by a thermal shutdown circuit. If asignificant temperature increase is detected in the internal drivercircuitry during fault conditions, this feature forces the driveroutput into a high impedance state. The ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E guarantee alogic high receiver output when the receiver inputs are shorted,open, or connected to a terminated transmission line with alldrivers disabled. Table 2 in the data sheet presents an overview of the ADM3061E/ADM3062E/ADM3063E/ADM3064E/ADM3065E/ADM3066E/ADM3067E/ADM3068E data rate capability across temperature, power supply,and package options. Refer to the Ordering Guide section formodel numbering.APPLICATIONS Industrial fieldbuses Process control Building automation PROFIBUS networks Motor control servo drives and encoders?

Based on the iCoupler? and isoPower? chip scale transformertechnology, the ADM3260 is a hot swappable digital and powerisolator with two nonlatching, bidirectional communicationchannels, supporting a complete isolated I2C interface, and anintegrated isolated dc-to-dc converter, supporting up to150 mW of isolated power conversion.iCoupler is a chip scale transformer technology with functional,performance, size, and power consumption advantages ascompared to optocouplers. The bidirectional I2C channels eliminate the need for splitting I2C signals into separate transmitand receive signals for use with standalone optocouplers.Based on the Analog Devices, Inc., isoPower technology, theon-chip isolated dc-to-dc converter provides a regulated, isolatedvoltage of 3.15 V to 5.25 V with up to 150 mW of output power.With the ADM3260, the iCoupler and isoPower channels, alongwith the I2C transceivers, can be integrated with semiconductorcircuitry, which enables a complete isolated I2C interface andallows the power converter to be implemented in a small formfactor. The ADM3260 is available in 20-lead SSOP package andhas an operating temperature range of ?40?C to+105?C.isoPower uses high frequency switching elements to transfer powerthrough its transformer. Special care must be taken during printedcircuit board (PCB) layout to meet emissions standards. See theAN-0971 Application Note for board layout recommendationsApplications Isolated I2C, SMBus, and PMBus interfaces Multilevel I2C interfaces Central office switching Telecommunication and data communication equipment ?48 V distributed power systems ?48 V power supply modules Networking

The ADN2816 provides the receiver functions of quantization and clock and data recovery for continuous data rates from 10 Mb/s to 675 Mb/s. The ADN2816 automatically locks to all data rates without the need for an external reference clock or programming. All SONET jitter requirements are met, including jitter transfer, jitter generation, and jitter tolerance. All specifications are quoted for ?40?C to +85?C ambient temperature, unless otherwise noted.The ADN2816 is available in a compact 5 mm ? 5 mm 32-lead chip scale package.ApplicationsSONET OC-1/3/12 and all associated FEC rates Fibre Channel, ESCON, Fast Ethernet, SDI, etc. WDM transpondersRegenerators/repeatersTest equipmentBroadband cross-connects and routers

The ADN4620/ADN4621 are dual-channel, signal isolated, low voltage differential signaling (LVDS) buffers that operate at up to 2.5 Gbps with very low jitter. The devices integrate Analog Devices, Inc., iCoupler? technology, enhanced for high speed operation to provide drop-in galvanic isolation of LVDS signal chains. AC coupling and/or level shifting to the LVDS receivers and from the LVDS drivers allows isolation of other high speed signals, such as current mode logic (CML).The ADN4620/ADN4621 include a refresh mechanism to monitor the input and output states and ensure that they remain the same in the absence of data transitions (for example, at power-on). For lower power consumption and high speed operation with low jitter, the isolator circuits rely on 1.8 V supplies, while 3.3 V supplies are used for LVDS receivers to support the full common-mode range with an input voltage range (input common mode plus differential input voltage) of 0 V to 2.4 V per Table 2 in the data sheet.The devices are fully specified over a wide industrial temperature range and are available in a compact SSOP package with 5.3 mm creepage (for reinforced insulation at ac mains voltages).APPLICATIONS Analog front-end isolation Data plane isolation Isolated high speed clock and data links Multigigabit serialization/deserialization (SERDES) PCB-to-PCB optical replacement (for example, short reach fiber)Protected by U.S. Patents 7,075,329; 9,941,565; and 10,205,442. Other patents are pending.

The ADN4654/ADN4655/ADN46561? are signal isolated, low voltage differential signaling (LVDS) buffers that operate at up to 1.1 Gbps with low jitter. The devices integrate Analog Devices, Inc., iCoupler? technology, enhanced for high speed operation to provide galvanic isolation of the TIA/EIA-644-A compliant LVDS drivers and receivers. This integration allows drop-in isolation of an LVDS signal chain.The ADN4654/ADN4655/ADN4656 comprise multiple channel configurations, and the LVDS receivers on the ADN4655 and ADN4656 include a fail-safe mechanism to ensure a Logic 1 on the corresponding LVDS driver output when the inputs are floating, shorted, or terminated but not driven.For high speed operation with low jitter, the LVDS and isolator circuits rely on a 2.5 V supply. An integrated on-chip low dropout (LDO) regulator can provide the required 2.5 V from an external 3.3 V power supply. The devices are fully specified over a wide industrial temperature range and come in a 20-lead, wide body SOIC_W package with 5 kV rms isolation or in a 20-lead SSOP package with 3.75 kV rms isolation.Applications Isolated video and imaging data Analog front-end isolation Data plane isolation Isolated high speed clock and data links1 Protected by U.S. Patents 5,952,849; 6,873,065; 6,903,578; and 7,075,329. Other patents are pending.

The ADN4654/ADN4655/ADN46561? are signal isolated, low voltage differential signaling (LVDS) buffers that operate at up to 1.1 Gbps with low jitter. The devices integrate Analog Devices, Inc., iCoupler? technology, enhanced for high speed operation to provide galvanic isolation of the TIA/EIA-644-A compliant LVDS drivers and receivers. This integration allows drop-in isolation of an LVDS signal chain.The ADN4654/ADN4655/ADN4656 comprise multiple channel configurations, and the LVDS receivers on the ADN4655 and ADN4656 include a fail-safe mechanism to ensure a Logic 1 on the corresponding LVDS driver output when the inputs are floating, shorted, or terminated but not driven.For high speed operation with low jitter, the LVDS and isolator circuits rely on a 2.5 V supply. An integrated on-chip low dropout (LDO) regulator can provide the required 2.5 V from an external 3.3 V power supply. The devices are fully specified over a wide industrial temperature range and come in a 20-lead, wide body SOIC_W package with 5 kV rms isolation or in a 20-lead SSOP package with 3.75 kV rms isolation.Applications Isolated video and imaging data Analog front-end isolation Data plane isolation Isolated high speed clock and data links1 Protected by U.S. Patents 5,952,849; 6,873,065; 6,903,578; and 7,075,329. Other patents are pending.
