The AD5233 is a quad-channel nonvolatile memory,1 digitally controlled potentiometer2 with a 64-step resolution. The device performs the same electronic adjustment function as a mechanical potentiometer with enhanced resolution, solid-state reliability, and remote controllability. The AD5233 has versatile programming using a serial peripheral interface (SPI) for 16 modes of operation and adjustment, including scratchpad programming, memory storing and restoring, increment/decrement, ?6 dB/step log taper adjustment, wiper setting readback, and extra EEMEM for user-defined information such as memory data for other components, look-up tables, or system identification information.In the scratchpad programming mode, a specific setting can be programmed directly to the RDAC register, which sets the resistance between Terminal W to Terminal A and Terminal W to Terminal B. This setting can be stored into the EEMEM and is transferred automatically to the RDAC register during system power-on.The EEMEM content can be restored dynamically or through external PR strobing. A WP function protects EEMEM contents. To simplify the programming, independent or simultaneous increment or decrement commands can be used to move the RDAC wiper up or down, one step at a time. For logarithmic ?6 dB step changes in wiper settings, the left or right bit shift command can be used to double or halve the RDAC wiper setting.The AD5233 is available in a thin 24-lead TSSOP package. The part is guaranteed to operate over the extended industrial temperature range of ?40?C to +85?C.APPLICATIONS Mechanical potentiometer replacement Instrumentation: gain, offset adjustment Programmable voltage-to-current conversion Programmable filters, delays, time constants Programmable power supply Sensor calibration

The AD5235 is a dual-channel, nonvolatile memory, digitallycontrolled potentiometer with 1024-step resolution, offeringguaranteed maximum low resistor tolerance error of ?8%.The device performs the same electronic adjustment functionas a mechanical potentiometer with enhanced resolution, solidstate reliability, and superior low temperature coefficient performance.The versatile programming of the AD5235 via anSPI?-compatible serial interface allows 16 modes of operationand adjustment including scratchpad programming, memorystoring and restoring, increment/decrement, ?6 dB/step log taperadjustment, wiper setting readback, and extra EEMEM for user-definedinformation such as memory data for other components,look-up table, or system identification information.In the scratchpad programming mode, a specific setting canbe programmed directly to the RDAC register, which sets theresistance between Terminal W and Terminal A and Terminal Wand Terminal B. This setting can be stored into the EEMEMand is restored automatically to the RDAC register duringsystem power-on.The EEMEM content can be restored dynamically or throughexternal PR strobing, and a WP function protects EEMEMcontents. To simplify the programming, the independent orsimultaneous linear-step increment or decrement commandscan be used to move the RDAC wiper up or down, one step ata time. For logarithmic ?6 dB changes in the wiper setting, theleft or right bit shift command can be used to double or halve theRDAC wiper setting.The AD5235 patterned resistance tolerance is stored in theEEMEM. The actual end-to-end resistance can, therefore, beknown by the host processor in readback mode. The host canexecute the appropriate resistance step through a softwareroutine that simplifies open-loop applications as well asprecision calibration and tolerance matching applications.The AD5235 is available in a thin, 16-lead TSSOP package.The part is guaranteed to operate over the extended industrialtemperature range of ?40?C to +85?C.Applications DWDM laser diode driver, optical supervisory systems Mechanical potentiometer replacement Instrumentation: gain, offset adjustment Programmable voltage-to-current conversion Programmable filters, delays, time constants Programmable power supply Low resolution DAC replacement Sensor calibration

The AD5258 provides a compact, nonvolatile 3 mm ? 4.9 mm packaged solution for 64-position adjustment applications. These devices perform the same electronic adjustment function as mechanical potentiometers?or variable resistors, but with enhanced resolution and solid-state reliability.The wiper settings are controllable through an I2C-compatible digital interface that is also used to read back the wiper register and EEPROM content in addition, resistor tolerance is stored within EEPROM, providing an end-to-end tolerance accuracy of 0.1%. There is also a software write protection function that ensures data cannot be written to the EEPROM register.A separate VLOGIC pin delivers increased interface flexibility. For users who need multiple parts on one bus, Address Bit AD0 and Address Bit AD1 allow up to four devices on the same bus.APPLICATIONS LCD panel VCOM adjustment LCD panel brightness and contrast control Mechanical potentiometer replacement in new designs Programmable power supplies RF amplifier biasing Automotive electronics adjustment Gain control and offset adjustment Fiber to the home systems Electronics level settings

The AD5270 /?AD5271 are single-channel, 1024-/256-position digital rheostats that combine industry leading variable resistor performance with nonvolatile memory (NVM) in a compact package.The AD5270 / AD5271 ensure less than 1% end-to-end resistor tolerance error and offer 50-times programmable (50-TP) memory.The guaranteed industry leading low resistor tolerance error feature simplifies open-loop applications as well as precision calibration and tolerance matching applications.The AD5270 / AD5271 device wiper settings are controllable through the SPI digital interface. Unlimited adjustments are allowed before programming the resistance value into the 50-TP memory. The AD5270/AD5271 do not require any external voltage supply to facilitate fuse blow and there are 50 opportunities for permanent programming. During 50-TP activation, a permanent blow fuse command freezes the resistance position (analogous to placing epoxy on a mechanical trimmer).The AD5270 / AD5271 are available in a 3 mm x 3 mm, 10-lead LFCSP package and in a 10-lead MSOP package. The parts are guaranteed to operate over the extended industrial temperature range of ?40?C to +125?C.APPLICATIONS Mechanical potentiometer replacements Op-amp: variable gain control Instrumentation: gain, offset adjustment Programmable voltage-to-current conversions Programmable filters, delays, time constants Programmable power supply Sensor calibration

The AD5310R?/ AD5311R, members of the nanoDAC? family, are low power, single-channel, 10-bit buffered voltage-out DACs. The devices include a 2.5 V, 2 ppm/?C internal reference. The output span can be programmed to be 0 V to VREF or 0 V to 2 ? VREF. All devices operate from a single 2.7 V to 5.5 V supply and are guaranteed monotonic by design. The devices are available in 10-lead MSOP packages.The AD5310R / AD5311R also incorporate a power-on resetcircuit that ensures that the DAC output powers up to zeroscaleand remains there until a valid write takes place. Thedevice contains a power-down feature that reduces the currentconsumption of the device to 2 ?A at 5 V while in power-downmode.The AD5310R / AD5311R use a versatile SPI or I2C interface,including an asynchronous RESET pin and a VLOGIC pin, allowing 1.8 V compatibility.PRODUCT HIGHLIGHTS High Relative Accuracy (INL): ?0.5 LSB maximum. Low Drift 2.5 V On-Chip Reference: 5 ppm/?C maximum temperature coefficient.APPLICATIONS Process controls Data acquisition systems Digital gain and offset adjustment Programmable voltage sources Optical modules

The ADAR4002 is a very low power broadband bi-directional single channel true time delay unit (TDU) and a digital step attenuator (DSA). The IC has 18.5 GHz of bandwidth over a frequency range of 0.5 GHz to 19 GHz with 50 ? input impedance at both RF ports. The TDU has two programmable maximum time delays, each with 7-bit control: Range 0 has a maximum delay of 508ps with a resolution of 4ps. This range is used at lower frequencies and where the ADAR4002 has less loss. Range 1 has a maximum delay of 254ps and a resolution of 2ps. This range has less loss compared to Range 0 and is useful at higher frequencies. The DSA has 6-bit resolution with an attenuation range of 0 dB to 31.5 dB and a step size of 0.5 dB. The ADAR4002 is designed to provide flexible digital control through either a SPI interface or a shift register to allow daisy chaining multiple chips together. The ADAR4002 contains register memory for 32 TDU+DSA states. The memory combined with on-chip sequencers, allows a fast memory advance via the UPDATE pin.The ADAR4002 is available in a 2 mm ? 3 mm 14-lead LFCSP package and is specified from -40?C to 85?C.APPLICATIONSElectronic steerable antenna arraysMulti-Function ArraysSATCOMRADARData LinksTest Equipment

The ADCLK905 (one input, one output), ADCLK907 (dual oneinput, one output), and ADCLK925 (one input, two outputs) areultrafast clock/data buffers fabricated on the Analog Devices, Inc.,proprietary XFCB3 silicon germanium (SiGe) bipolar process.The ADCLK905/ADCLK907/ADCLK925 feature full-swing emitter coupled logic (ECL) output drivers. For PECL (positive ECL) operation, bias VCC to the positive supply and VEE to ground. For NECL (negative ECL) operation, bias VCC to ground and VEE to the negative supply.The buffers offer 95 ps propagation delay, 7.5 GHz toggle rate, 10 Gbps data rate, and 60 fs random jitter (RJ).The inputs have center tapped, 100 ?, on-chip termination resistors. A VREF pin is available for biasing ac-coupled inputs.The ECL output stages are designed to directly drive 800 mV each side into 50 ? terminated to VCC ? 2 V for a total differential output swing of 1.6 V.The ADCLK905/ADCLK907/ADCLK925 are available in 16-lead LFCSP packages.Applications Clock and data signal restoration and level shifting Automated test equipment (ATE) High speed instrumentation High speed line receivers Threshold detection Converter clocking

The ADD5211 is a four-string, white LED driver for backlight applications based on high efficiency, current mode, step-up converter technology. The boost controller drives an external MOSFET switch for step-up regulation from an input voltage of 4.5 V to 40 V and a pin adjustable operating frequency from 200 kHz to 1.2 MHz. An adjustable UVLO function is implemented to reduce input current during power-off.The ADD5211 provides four regulated current sinks for uniform brightness intensity. Each current sink can be driven from 40 mA to 200 mA; the LED driving current is pin adjustable using an external resistor. With an input PWM interface, the ADD5211 drives up to four parallel strings of multiple series connected LEDs.Additional features include LED short protection, LED open protection, boost output short protection, overvoltage protection, cycle-by-cycle current limit, and thermal shutdown for both the IC and the LED array. An open-drain fault output is also included. A programmable soft start is implemented to reduce inrush current during startup. Applications LCD monitor and TV LED backlights Industrial lighting

The ADF7030-1 is a fully integrated, radio transceiver achieving high performance at very low power. The ADF7030-1 is ideally suited for applications that require long range, network robustness, and long battery life. It is suitable for applications that operate in the ISM, SRD, and licensed frequency bands at 169.4 MHz to 169.6 MHz, 426 MHz to 470 MHz, and 863 MHz to 960 MHz. It provides extensive support for standards-based protocols like IEEE802.15.4g while also providing flexibility to support a wide range of proprietary protocols.The highly configurable low intermediate frequency (IF) receiver supports a large range of receiver channel bandwidths from 2.6 kHz to 406 kHz. This range of receiver channel bandwidths allows the ADF7030-1 to support ultranarrow-band, narrow-band, and wideband channel spacing.The ADF7030-1 features two independent PAs supporting output power ranges of ?20 dBm to +13 dBm and ?20 dBm to +17 dBm. The PAs support ultrafine adjustment of the power with a step resolution of 0.1 dB. The PA output power is exceptionally robust over temperature and voltage. The PAs have an automatic power ramp control to limit spectral splatter to meet regulatory standards.The ADF7030-1 features an on-chip ARM??Cortex?-M0 processor that performs radio control, radio calibration, and packet management. Cortex-M0 eases the processing burden of the host processor because the ADF7030-1 integrates the lower layers of a typical communication protocol stack. This internal processor also permits the download and execution of Analog Devices, Inc., provided firmware modules that can extend the functionality of the ADF7030-1.The ADF7030-1 has two packet modes: generic packet mode and IEEE802.15.4g mode. In generic packet mode, the packet format is highly flexible and fully programmable, thereby ensuring its compatibility with proprietary packet formats. In IEEE802.15.4g packet mode, the packet format conforms to the?IEEE802.15.4g standard. FEC, as per the IEEE802.15.4g standard, is also supported.The ADF7030-1 operates with a power supply range of 2.2 V to 3.6 V and has very low power consumption in both Tx and Rx modes, enabling long lifetimes in battery-operated systems. An ultralow power deep sleep mode achieves a typical current of 10 nA with the configuration memory retained.A complete wireless solution can be built using a small number of external discrete components and a host processor (typically a microcontroller). The host processor can configure the ADF7030-1 using a simple command-based protocol over a standard 4-wire SPI interface. A single-byte command transitions the radio between states or performs a radio function.The ADF7030-1 is available in two package types: a 6 mm ? 6 mm, 40-lead LFCSP and a 7 mm ? 7 mm, 48-lead LQFP. Both package types use NiPdAu plating to mitigate against silver migration in high humidity applications. The ADF7030-1 operating temperature range is ?40?C to +85?C.For Figure 13 to Figure 19, Figure 30, Figure 42, Figure 60, Figure 61, and Figure 75 in the Typical Performance Characteristics section, PA_COARSE is a programmable value that provides a coarse adjustment of the PA output power. This value can be programmed in the range of 1 to 6 for PA1, and from 1 to 10 for PA2. PA_FINE is a programmable value that provides a fine adjustment of the PA output power. This value can be programmed in the range of 3 to 127 for both PA1 and PA2. PA_MICRO is a programmable value that provides a microadjustment (typically <0.1 dB) of the PA output power. This value can be programmed in the range of 1 to 31 for both PA1 and PA2. PAOLDO_VOUT_CON is a programmable value that configures the internal LDO voltage that provides bias for the PA. For additional information on these bit settings, see the ADF7030-1 Software Reference Manual, which is the detailed programming guide for the device.Applications IEEE 802.15.4g (MR-FSK PHY)? Wireless M-Bus (EN 13757-4) Smart metering Security and building automation? Active tag asset tracking Industrial control Wireless sensor networks (WSNs)

The ADIS16507 is a precision, miniature microelectromechanical?system (MEMS) inertial measurement unit (IMU) that includes?a triaxial gyroscope and a triaxial accelerometer. Each inertial?sensor in the ADIS16507 combines with signal conditioning?that optimizes dynamic performance. The factory calibration?characterizes each sensor for sensitivity, bias, alignment,?linear acceleration (gyroscope bias), and point of percussion?(accelerometer location). As a result, each sensor has dynamic?compensation formulas that provide accurate sensor?measurements over a broad set of conditions.The ADIS16507 provides a simplified, cost effective method for?integrating accurate, multiaxis inertial sensing into industrial?systems, especially when compared with the complexity and?investment associated with discrete designs. All necessary motion?testing and calibration are part of the production process at the?factory, greatly reducing system integration time. Tight orthogonal?alignment simplifies inertial frame alignment in navigation?systems. The serial peripheral interface (SPI) and register?structure provide a simple interface for data collection and?configuration control.The ADIS16507 is available in a 100-ball, ball grid array (BGA)?package that is approximately 15 mm ? 15 mm ? 5 mm.Applications Navigation, stabilization, and instrumentation Unmanned and autonomous vehicles Smart agriculture and construction machinery Factory/industrial automation, robotics Virtual/augmented reality Internet of Moving Things
