Texas Instruments
TPS6521845RSLR
|
Texas Instruments
TPS6591104DA2NMA
|
Texas Instruments
TPS659112A2NMAR
|
Texas Instruments
TPS65994ADRSLR
|
Texas Instruments
TPS74510PQWDRBRQ1
|
Texas Instruments
TPS74613PQWDRBRQ1
|
Texas Instruments
TPS74634PQWDRBRQ1
|
Texas Instruments
TPS784105QWDRBRQ1
|
Texas Instruments
TPS78412QDBVRQ1
|
Texas Instruments
TPS78425QWDRBRQ1
|
| Price |
|
|
|
|
|
|
|
|
|
|
|
| RoHS |
|
Y |
Y |
Y |
Y |
Y |
Y |
Y |
Y |
Y |
Y |
| Lead Status |
|
Y |
Y |
Y |
Y |
Y |
Y |
Y |
Y |
Y |
Y |
| Configurability |
|
Factory programmable,Software configurable |
Factory programmable |
Factory programmable |
|
|
|
|
|
|
|
| Features |
|
Dynamic voltage scaling,Eco-mode,I2C control,Overcurrent protection,Power good,Power sequencing,Power supply and system monitoring,Thermal shutdown,UVLO adjustable |
Comm control,Dynamic voltage scaling,Enable,I2C control,Overcurrent protection,Power sequencing,Synchronous rectification,Thermal shutdown |
Comm Control,Dynamic Voltage Scaling,Enable,I2C Control,Over Current Protection,Power Sequencing,Synchronous Rectification,Thermal Shutdown |
|
Enable,Foldback Overcurrent protection,Output discharge,Power good,Soft start,Wettable flanks package |
Enable,Foldback Overcurrent protection,Power good,Wettable flanks package |
Enable,Foldback Overcurrent protection,Power good,Wettable flanks package |
Enable,Wettable flanks package |
Enable,Wettable flanks package |
Enable,Wettable flanks package |
| Iout(max)(A) |
|
1.8 |
|
|
|
0.5 |
1 |
1 |
0.3 |
0.3 |
0.3 |
| Iq(typ)(mA) |
|
0.025 |
0.29 |
|
|
0.025 |
0.025 |
0.025 |
0.025 |
0.025 |
0.025 |
| LDO |
|
1 |
9 |
9 |
|
|
|
|
|
|
|
| Operating temperature range(C) |
|
-40 |
-40 |
-40 to 85 |
-40 |
-40 |
-40 |
-40 |
-40 |
-40 |
-40 |
| Package area(mm^2) |
|
36 |
54 |
|
36 |
9 |
9 |
9 |
9 |
8.12 |
9 |
| Package size (L x W)(mm) |
|
6 x 6 |
9 x 6 |
|
6 x 6 |
3 x 3 |
3 x 3 |
3 x 3 |
3 x 3 |
2.9 x 2.8 |
3 x 3 |
| Package type |
|
VQFN |
NFBGA |
|
VQFN |
VSON |
VSON |
VSON |
VSON |
SOT-23 |
VSON |
| Pin count |
|
48 |
98 |
|
48.0 |
8.0 |
8.0 |
8.0 |
8.0 |
5.0 |
8.0 |
| Pitch(mm) |
|
0.4 |
0.65 |
|
|
|
|
|
|
|
|
| Processor name |
|
i.MX 6Solo/6DualLite,i.MX 6SoloX/SoloLite |
66AK2G02,66AK2G12,DM81x,Jacinto DRA6x,Sitara AM38x,i.MX 6Dual/Quad |
DM812x,DM813x,DM814x,AM387x,C6A814x,TNETV813x,TNETV814x,DRA64x,DRA65x,TDA1Mx,i.MX6,66AK2G02,66AK2G12 |
|
|
|
|
|
|
|
| Processor supplier |
|
NXP/Freescale |
NXP/Freescale,Texas Instruments |
Texas Instruments,Freescale |
|
|
|
|
|
|
|
| Product type |
|
Processor and FPGA |
Processor and FPGA |
|
|
|
|
|
|
|
|
| Rating |
|
Catalog |
Catalog |
Catalog |
Catalog |
Automotive |
Automotive |
Automotive |
Automotive |
Automotive |
Automotive |
| Regulated outputs(#) |
|
7 |
13 |
13 |
|
1 |
1 |
1 |
1 |
1 |
1 |
| Step-down DC/DC controller |
|
0 |
1 |
1 |
|
|
|
|
|
|
|
| Step-down DC/DC converter |
|
5 |
3 |
3 |
|
|
|
|
|
|
|
| Step-up DC/DC controller |
|
0 |
0 |
0 |
|
|
|
|
|
|
|
| Step-up DC/DC converter |
|
1 |
0 |
0 |
|
|
|
|
|
|
|
| Switching frequency(max)(kHz) |
|
2400 |
3300 |
|
|
|
|
|
|
|
|
| Switching frequency(typ)(kHz) |
|
2400 |
3000 |
|
|
|
|
|
|
|
|
| TI functional safety category |
|
|
|
|
|
|
Functional Safety-Capable |
Functional Safety-Capable |
Functional Safety-Capable |
Functional Safety-Capable |
Functional Safety-Capable |
| Vin(max)(V) |
|
5.5 |
5.5 |
|
|
6 |
6 |
6 |
6 |
6 |
6 |
| Vin(min)(V) |
|
2.2 |
2.7 |
|
|
1.5 |
1.5 |
1.5 |
1.65 |
1.65 |
1.65 |
| Vout(max)(V) |
|
3.4 |
3.3 |
|
|
5.5 |
5.5 |
5.5 |
5.5 |
5.5 |
5.5 |
| Vout(min)(V) |
|
0.85 |
-0.3 |
|
|
0.55 |
0.55 |
0.55 |
0.75 |
0.75 |
0.75 |
| TI.com inventory |
|
7375 |
3644 |
5954 |
64903 |
67965 |
101500 |
56500 |
51978 |
11299 |
80705 |
| Approx. price(US$) |
|
1.04 | 1ku |
3.63 | 1ku |
3.63 | 1ku |
1.99 | 1ku |
.398 | 1ku |
.398 | 1ku |
.398 | 1ku |
.248 | 1ku |
.248 | 1ku |
.248 | 1ku |
| Shutdown current (ISD)(typ)(A) |
|
|
0.016 |
|
|
|
|
|
|
|
|
| Package Group |
|
|
|
NFBGA|98 |
|
|
|
|
|
|
|
| Iq(Typ)(mA) |
|
|
|
0.29 |
|
|
|
|
|
|
|
| Vin(Min)(V) |
|
|
|
2.7 |
|
|
|
|
|
|
|
| Vin(Max)(V) |
|
|
|
5.5 |
|
|
|
|
|
|
|
| Switching frequency(Min)(kHz) |
|
|
|
2700 |
|
|
|
|
|
|
|
| Switching frequency(Typ)(kHz) |
|
|
|
3000 |
|
|
|
|
|
|
|
| Package size |
|
|
|
mm2 |
|
|
|
|
|
|
|
| Shutdown current (ISD)(Typ)(uA) |
|
|
|
0.016 |
|
|
|
|
|
|
|
| Switching frequency(Max)(kHz) |
|
|
|
3300 |
|
|
|
|
|
|
|
| Alternate mode |
|
|
|
|
Yes |
|
|
|
|
|
|
| Data role |
|
|
|
|
DFP,DRD,UFP |
|
|
|
|
|
|
| Dead battery support |
|
|
|
|
Yes |
|
|
|
|
|
|
| External power-path control |
|
|
|
|
NFET |
|
|
|
|
|
|
| Function |
|
|
|
|
Type-C |
|
|
|
|
|
|
| Internal power path |
|
|
|
|
5 V 3 A |
|
|
|
|
|
|
| Power role |
|
|
|
|
DRP,Sink,Source |
|
|
|
|
|
|
| Type |
|
|
|
|
PD controller |
|
|
|
|
|
|
| Accuracy(%) |
|
|
|
|
|
2 |
0.85 |
0.85 |
0.5 |
0.5 |
0.5 |
| Dropout voltage (Vdo)(typ)(mV) |
|
|
|
|
|
225 |
190 |
190 |
115 |
115 |
115 |
| Fixed output options(V) |
|
|
|
|
|
1 |
1.3 |
3.4 |
1.05 |
1.2 |
2.5 |
| Load capacitance(min)(F) |
|
|
|
|
|
1 |
1 |
1 |
1 |
1 |
1 |
| Maximum package height(mm) |
|
|
|
|
|
1.0 |
1.0 |
1.0 |
1.0 |
1.45 |
1.0 |
| Noise(Vrms) |
|
|
|
|
|
53 |
53 |
53 |
30 |
30 |
30 |
| Output options |
|
|
|
|
|
Fixed Output |
Fixed Output |
Fixed Output |
Fixed Output |
Fixed Output |
Fixed Output |
| PSRR at 100 KHz(dB) |
|
|
|
|
|
45 |
45 |
45 |
45 |
45 |
45 |
| Thermal resistance JA(C/W) |
|
|
|
|
|
55.5 |
55 |
55 |
61.8 |
184.3 |
61.8 |
