| Price | $3.01 | $3.58 | $2.84 | $2.66 | |||||||
| RoHS | Compliant | Compliant | Compliant | Compliant | Compliant | Compliant | Compliant | Compliant | Compliant | Compliant | |
| Lead Status | No | No | No | No | No | No | No | No | No | No | |
| Approx. Price (US$) | 1.80 | 1ku | 1.85 | 1ku | 2.10 | 1ku | 2.36 | 1ku | 2.00 | 1ku | 1.95 | 1ku | 2.00 | 1ku | 1.15 | 1ku | 1.15 | 1ku | 1.05 | 1ku | |
| Switching Frequency(Min)(kHz) | 100 | 500 | 100 | 100 | 500 | 100 | 200 | 2100 | 2100 | ||
| Control Mode | Current Mode | Voltage Mode | Current Mode | Current Mode | Voltage Mode | Current Mode | Current Mode | ||||
| Rating | Catalog | Catalog | Catalog | Automotive | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | |
| Iout(Max)(A) | 2.5 | 3 | 3.5 | 3.5 | 5 | 5 | 8 | 0.2 | |||
| Vout(Min)(V) | 0.8 | 1.23 | 0.8 | 0.8 | 1.22 | 0.8 | 0.6 | 5 | 2.5 | -9.75 | |
| Duty Cycle(Max)(%) | 98 | 87 | 98 | 98 | 89 | 98 | 98 | 100 | 100 | ||
| Iq(Typ)(mA) | 0.138 | 3 | 0.146 | 0.152 | 3 | 0.146 | 0.58 | 0.05 | 0.05 | 0.13 | |
| Operating Temperature Range(C) | -40 to 125 | -40 to 125 | -40 to 125 | -40 to 125 | -40 to 125 | -40 to 125 | -40 to 150 | -40 to 125 | |||
| Package Group | MSOP-PowerPAD,VSON | SO PowerPAD | SO PowerPAD | WSON | SO PowerPAD | SO PowerPAD | VQFN-HR | VQFN-HR | VQFN-HR | SOT,SOT-23 | |
| Type | Converter | Converter | Converter | Converter | Converter | Converter | Converter | Converter | Converter | ||
| Regulated Outputs(#) | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |||
| Special Features | Enable,Frequency Synchronization,Light Load Efficiency,Power Good,Tracking,UVLO Adjustable | Enable | Enable,Frequency Synchronization,Light Load Efficiency,UVLO Adjustable | Enable,Frequency Synchronization,Light Load Efficiency,Power Good,Tracking,UVLO Adjustable | Enable | Enable,Frequency Synchronization,Light Load Efficiency,UVLO Adjustable | Enable,Frequency Synchronization,Power Good,Pre-Bias Start-Up,Synchronous Rectification,Tracking | Dynamic Voltage Scaling,Enable,Frequency Synchronization,Light Load Efficiency,Load Disconnect,Output Discharge,Power Good,Synchronous Rectification,UVLO Fixed,Voltage Margining | Dynamic Voltage Scaling,Enable,Frequency Synchronization,Light Load Efficiency,Load Disconnect,Output Discharge,Power Good,Synchronous Rectification,UVLO Fixed,Voltage Margining | Enable | |
| Vin(Max)(V) | 60 | 36 | 60 | 60 | 36 | 42 | 17 | 16 | 16 | -2.7 | |
| Switching Frequency(Max)(kHz) | 2500 | 500 | 2500 | 2500 | 500 | 2500 | 1600 | 2800 | 2800 | ||
| Vin(Min)(V) | 3.5 | 5.5 | 4.5 | 4.5 | 5.5 | 4.5 | 4.5 | 2 | 2 | -10 | |
| Vout(Max)(V) | 58 | 31 | 58.8 | 59 | 31 | 41.1 | 12 | 5 | 9 | -1.2 | |
| Switching Frequency(Typ)(kHz) | 2400 | 2400 | |||||||||
| Topology | Buck/Boost | Buck/Boost | |||||||||
| Switch Current Limit(Min)(A) | 3.1 | 3.1 | |||||||||
| Switch Current Limit(Typ)(A) | 3.6 | 3.6 | |||||||||
| PSRR @ 100KHz(dB) | 48 | ||||||||||
| Fixed Output Options(V) | -2.5 | ||||||||||
| Vdo(Typ)(mV) | 280 | ||||||||||
| Output Options | Adjustable Output,Fixed Output,Negative Output | ||||||||||
| Noise(uVrms) | 60 | ||||||||||
| Output Capacitor Type | Ceramic | ||||||||||
| Accuracy(%) | 2 | ||||||||||
| Package Size | mm2 |
