Analog Devices Inc.

Category: Power Management ICs

5-Bit Programmable Synchronous Switching Regulator Controller for Pentium III Processor Features: 5-Bit Digitally Programmable 1.3V to 3.5V Fixed Output Voltage, VRM 8.4 Compliant Fast Transient Response: 0% to 100% Duty Cycle Phase Lead Compensation for Remote Sensing Overtemperature Protection Flags for Power Good and Overvoltage Fault 19A Output Current Capability from a 5V Supply Dual N-Channel MOSFET Synchronous Driver Initial Output Accuracy: ±1.5% Excellent Output Accuracy: ±2% Typ Over Line, Load and Temperature Variations High Efficiency: Over 95% Possible Adjustable Current Limit Without External Sense Resistors Available in 2O-Lead SSOP and SW Packages

$5.81
