Analog Devices Inc.

Category: Drivers and Interfaces

High Speed, High Voltage, High Side Gate Driver Features: Wide Operating VIN Range: Up to 80V Rugged Architecture Tolerant of 100V VIN Transients Powerful 1.85Ω Driver Pull-Down (with 6V Supply) Powerful 1.1A Peak Current Driver Pull-Up (with 6V Supply) 7ns Fall Time Driving 1000pF Load 10ns Rise Time Driving 1000pF Load Drives Standard Threshold MOSFETs TTL/CMOS Compatible Inputs with Hysteresis Input Thresholds are Independent of Supply Undervoltage Lockout Thermally Enhanced 8-Lead MSOP Package

$7.94
