MAX1483ESA+
Analog Devices Inc.
Category: Drivers and Interfaces
The MAX1482 and MAX1483 are low-power transceiversfor RS-485 and RS-422 communication. Bothfeature slew-rate-limited drivers that minimize EMI andreduce reflections caused by improperly terminatedcables. Data rates are guaranteed up to 250kbps.The MAX1482/MAX1483 draw only 20µA of supply current.Additionally, they have a low-current shutdownmode that consumes only 0.1µA. Both parts operatefrom a single +5V supply.Drivers are short-circuit current limited and are protectedagainst excessive power dissipation by thermalshutdown circuitry that places the driver outputs into ahigh-impedance state. The receiver input has a fail-safefeature that guarantees a logic-high output if the inputis open circuit.The MAX1482 is full duplex and the MAX1483 is halfduplex. Both parts have a 1/8-unit-load input impedancethat guarantees up to 256 transceivers on the bus.ApplicationsIndustrial Control Local Area NetworksLarge 256-Node LANsLow-Power RS-485/RS-422 NetworksTransceivers for EMI-Sensitive Applications
* $6.86 - * $6.95
Distributors
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1000 | 10000 | Purchase | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 |
element14 APAC | MAX1483ESA+ | 162 | 1 | * $6.95 | * $5.33 | * $4.93 | * $4.48 | * $4.24 | * $4.24 | Buy |
|
 |
Farnell | MAX1483ESA+ | 175 | 1 | * $6.86 | * $4.87 | * $4.64 | * $4.40 | * $4.17 | * $4.17 | Buy |
|
 |
Mouser Electronics | 700-MAX1483ESA | 176 | 1 | $7.94 | $4.87 | $4.87 | $4.13 | $3.38 | $3.37 | Buy |
Technical Specifications
| ROHS Compliance | Compliant |
