Analog Devices Inc.

Category: Power Management ICs

The MAX17220–MAX17225 is a family of ultra-low quiescent current boost (step-up) DC-DC converters with a 225mA/0.5A/1A peak inductor current limit and True Shutdown™. True Shutdown disconnects the output from the input with no forward or reverse current. The output voltage is selectable using a single standard 1% resistor. The 225mA (MAX17220/MAX17221), 500mA (MAX17222/MAX17223), and 1A (MAX17224/MAX17225) peak inductor current limits allow flexibility when choosing inductors. The MAX17220/MAX17222/MAX17224 versions have post-startup enable transient protection (ETP), allowing the output to remain regulated for input voltages down to 400mV, depending on load current. The MAX17220–MAX17225 offer ultra-low quiescent current, small total solution size, and high efficiency throughout the entire load range. The MAX17220–MAX17225 are ideal for battery applications where long battery life is a must. Design Solution: Triple Punch Extends the Life of Your Smart Factory Indoor BLE Beacon › Design Solution: Make Your IoT Device Last Longer with a nanoPower Boost Converter › Design Solution: How to Maximize Your Wireless Sensor’s Runtime ›Also see: nanoPower TechnologynanoPower Boost Converter Demo Sometimes it’s Smart to Have a Low IQ Read white paper ›ApplicationsBattery-Powered Medical EquipmentLow-Power Wireless Communication ProductsOptical Heart-Rate Monitoring (OHRM) LED DriversPrimary-Cell Portable SystemsSecondary-Cell Portable SystemsSupercapacitor Backup for Real-Time Clock (RTC)/Alarm BuzzersTiny, Low-Power IoT SensorsWearable Devices

* $2.06 - $3.31
