Analog Devices Inc.

Category: Power Management ICs

The MAX705–MAX708/MAX813L microprocessor (µP) supervisory circuits reduce the complexity and number of components required to monitor power-supply and battery functions in µP systems. These devices significantly improve system reliability and accuracy compared to separate ICs or discrete components.The MAX705/MAX706/MAX813L provide four functions:A reset output during power-up, power-down, and brownout conditions.An independent watchdog output that goes low if the watchdog input has not been toggled within 1.6 seconds.A 1.25V threshold detector for power-fail warning, low-battery detection, or for monitoring a power supply other than +5V.An active-low manual-reset input.The MAX707/MAX708 are the same as the MAX705/MAX706, except an active-high reset is substituted for the watchdog timer. The MAX813L is the same as the MAX705, except RESET is provided instead of active-low RESET.Two supply-voltage monitor levels are available: The MAX705/MAX707/MAX813L generate a reset pulse when the supply voltage drops below 4.65V, while the MAX706/MAX708 generate a reset pulse below 4.40V. All four parts are available in 8-pin DIP, SO and µMAX® packages.ApplicationsComputersControllersCritical µP Power MonitoringIntelligent Instruments

$3.91 - * $13.36
