MAX892LEUA+
Analog Devices Inc.
Category: Power Management ICs
The MAX891L/MAX892L smart, low-voltage, P-channel, MOSFET power switches are intended for high-side load-switching applications. These switches operate with inputs from 2.7V to 5.5V, making them ideal for both 3V and 5V systems. Internal current-limiting circuitry protects the input supply against overload. Thermal-overload protection limits power dissipation and junction temperatures.The MAX891L/MAX892L's maximum current limits are 500mA and 250mA, respectively. The current limit through the switch is programmed with a resistor from SET to ground. When the switch is on, the quiescent supply current is a low 13µA. When the switch is off, the quiescent current decreases to 0.1µA.The MAX891L/MAX892L are available in 8-pin µMAX® packages.ApplicationsAccess Bus SlotsPCMCIA SlotsPortable Equipment
$1.90 - $7.36
Distributors
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1000 | 10000 | Purchase | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 |
Analog Devices Inc | MAX892LEUA+ | $1.90 | $1.90 | Buy | ||||||
|
 |
element14 APAC | MAX892LEUA+ | 393 | 1 | * $5.74 | * $4.39 | * $3.84 | * $3.68 | * $3.50 | * $3.50 | Buy |
|
 |
Farnell | MAX892LEUA+ | 393 | 1 | * $5.90 | * $4.51 | * $3.94 | * $3.71 | * $3.48 | * $3.48 | Buy |
|
|
Mouser Electronics | 700-MAX892LEUA | 294 | 1 | $5.10 | $4.34 | $4.34 | $3.77 | $2.70 | $2.53 | Buy |
Technical Specifications
| ROHS Compliance | Compliant |
