Analog Devices Inc.

Category: Power Management ICs

The Himalaya series of voltage regulator ICs, power modules, and chargers enable cooler, smaller, and simpler power supply solutions. The MAXM17544 is an easy-to- use, Himalaya step-down power module that combines a switching power supply controller, dual n-channel MOSFET power switches, fully shielded inductor, and the compensation components in a low-profile, thermally-efficient, system-in-package (SiP). The device operates over a wide input voltage range of 4.5V to 42V and delivers up to 3.5A continuous output current with excellent line and load regulation over an output voltage range of 0.9V to 12V. The device only requires five external components to complete the total power solution. The high level of integrationsignificantly reduces design complexity, manufacturing risks, and offers a true plug-and-play power supply solution,reducing time-to-market.The device can be operated in the pulse-width modulation (PWM), pulse-frequency modulation (PFM), or discontinuous conduction mode (DCM) control schemes.The MAXM17544 is available in a low-profile, highlythermal-emissive, compact, 29-pin 9mm x 15mm x 2.8mm SiP package that reduces power dissipation in the package and enhances efficiency. The package iseasily soldered onto a printed circuit board and suitable for automated circuit board assembly.The device can operate over wide industrial temperature range from -40°C to +125°C.ApplicationsBase Station Point-of-Load RegulatorDistributed Supply RegulationFPGA and DSP Point-of-Load RegulatorHVAC and Building ControlIndustrial Power Supplies

* $43.38 - * $46.63
