SN74LVC1G06DBVRG4
Texas Instruments
Category: Logic
Buffer/Driver 1-CH Inverting Open Drain CMOS 5-Pin SOT-23 T/R
$0.05 - $0.80
Distributors
Currency:
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1000 | 10000 | Purchase | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 |
DigiKey | 296-46207-6-ND | 3461 | 1 | $0.47 | $0.38 | $0.35 | $0.26 | $0.15 | $0.06 | Buy |
|
 |
Arrow North American Components | SN74LVC1G06DBVRG4 | 0 | 3000 | $0.00 | Buy | |||||
|
|
AVNET Express | SN74LVC1G06DBVRG4 | 3000 | 8334 | $0.05 | Buy | |||||
|
|
Mouser Electronics | 595-SN74LVC1G06DBVG4 | 7963 | 1 | $0.48 | $0.38 | $0.38 | $0.26 | $0.15 | $0.12 | Buy |
|
|
Newark | SN74LVC1G06DBVRG4 | 6000 | $0.10 | $0.10 | $0.10 | $0.10 | $0.10 | $0.10 | Buy | |
|
 |
Quest Components | SN74LVC1G06DBVRG4 | 1344 | $0.50 | $0.50 | $0.26 | $0.26 | Buy | |||
|
|
Texas Instruments | SN74LVC1G06DBVRG4 | 168791 | 1 | $0.23 | $0.23 | $0.23 | $0.16 | $0.08 | $0.08 | Buy |
|
|
Verical Marketplace | SN74LVC1G06DBVRG4 | 9000 | 3000 | $0.08 | $0.08 | $0.08 | $0.08 | $0.08 | $0.05 | Buy |
|
|
Win Source | SN74LVC1G06DBVRG4 | 662000 | 880 | Buy |
Parts in family
Technical Specifications
| Lead Free Status | No |
| ROHS Compliance | Compliant |
| 3-State Output | No |
| Approx. Price (US$) | 0.05 | 1ku |
| Bits(#) | 1 |
| F @ Nom Voltage(Max)(Mhz) | 150 |
| Gate Type | OPEN DRAIN INVERTER BUFFER |
| ICC @ Nom Voltage(Max)(mA) | 0.01 |
| Logic | Inverting |
| Operating Temperature Range(C) | -40 to 125,-40 to 85 |
| Output Drive (IOL/IOH)(Max)(mA) | 32/-32 |
| Package Group | SC70,SOT-23,DSBGA,SOT-5X3,SON |
| Package Size | mm2 |
| Rating | Catalog |
| Schmitt Trigger | No |
| Special Features | Ioff,down translation to Vcc,Small DPW package,low power,open-drain |
| Sub-Family | Inverting Buffer/Driver |
| Technology Family | LVC |
| VCC(Max)(V) | 5.5 |
| VCC(Min)(V) | 1.65 |
| Voltage(Nom)(V) | 1.8,2.5,3.3,5 |
| tpd @ Nom Voltage(Max)(ns) | 6.5,4,3 |
