DC to 1000 MHz IF Gain Block Features: Fixed gain of 16.5 dB Operation up to 1000 MHz 37 dBm Output Third-Order Intercept (OIP3) 3 dB noise figure Input/output internally matched to 50 Stable temperature and power supply 3 V or 5 V power supply 110 mA power supply current

Dual, Low Noise, Wideband Variable Gain Amplifier, 0 dB To +40 dB Gain Features: 2 channels with independent gain control Linear in dB gain response 2 gain ranges AD600: 0 dB to 40 dB AD602: -10 dB to +30 dB Accurate absolute gain: ±0.3 dB Low input noise: 1.4 nV/√Hz Low distortion: -60 dBc THD at ±1 V output High bandwidth: dc to 35 MHz (-3 dB) Stable group delay: ±2 ns Low power: 125 mW (maximum) per amplifier Signal gating function for each amplifier Drives high speed ADCs MIL-STD-883-compliant and DESC versions available

10 GHz, High Speed Window Comparator Features: Propagation delay: 88 ps Propagation delay at 50 mV overdrive: 20 ps Minimum detectable pulse width: 60 ps Differential latch control Power dissipation: 240 mW 16-terminal 2.9 mm × 2.9 mm LCC package

18 V, 725 A, 4 MHz CMOS RRIO Operational Amplifier Features: Low power at high voltage (18 V): 725 μA maximum Low offset voltage: 2.2 mV maximum over entire common-mode range Low input bias current: 15 pA maximum Gain bandwidth product: 4 MHz typical at Av = 100 Unity-gain crossover: 4 MHz typical −3 dB closed-loop bandwidth: 2.1 MHz typical Single-supply operation: 3 V to 18 V Dual-supply operation: ±1.5 V to ±9 V Unity-gain stable

General Purpose Amplifier 2 Circuit Rail-to-Rail 8-SO

Analog Comparators hi Speed Latched Comp-RSECL 10GHz

The AD8417 is a high voltage, high resolution current shunt amplifier. It features an initial gain of 60 V/V, with a maximum ±0.3% gain error over the entire temperature range. The buffered output voltage directly interfaces with any typical converter. The AD8417 offers excellent input common-mode rejection from −2 V to +70 V. The AD8417 performs bidirectional current measurements across a shunt resistor in a variety of automotive and industrial applications, including motor control, power management, and solenoid control.The AD8417 offers breakthrough performance throughout the −40°C to +150°C temperature range. It features a zero drift core, which leads to a typical offset drift of 0.1 µV/°C throughout the operating temperature range and the common-mode voltage range. The AD8417 is qualified for automotive applications. The device includes EMI filters and patented circuitry to enable output accuracy with pulse-width modulation (PWM) type input common-mode voltages. The typical input offset voltage is ±200 µV. The AD8417 is offered in 8-lead MSOP and SOIC packages.Applications High-side current sensing in Motor controls Solenoid controls Power management Low-side current sensing Diagnostic protection

The AD8429 is an ultralow noise, instrumentation amplifier designed for measuring extremely small signals over a wide temperature range (−40°C to +125°C).The AD8429 excels at measuring tiny signals. It delivers ultralow input noise performance of 1 nV/√Hz. The high CMRR of the AD8429 prevents unwanted signals from corrupting the acqui-sition. The CMRR increases as the gain increases, offering high rejection when it is most needed. The high performance pin configuration of the AD8429 allows it to reliably maintain high CMRR at frequencies well beyond those of typical instrumentation amplifiers.The AD8429 reliably amplifies fast changing signals. Its current feedback architecture provides high bandwidth at high gain, for example, 1.2 MHz at G = 100. The design includes circuitry to im-prove settling time after large input voltage transients. The AD8429 was designed for excellent distortion performance, allowing use in demanding applications such as vibration analysis.Gain is set from 1 to 10,000 with a single resistor. A reference pin allows the user to offset the output voltage. This feature can be useful to shift the output level when interfacing to a single supply signal chain.The AD8429 performance is specified over the extended industrial temperature range of −40°C to +125°C. It is available in an 8-lead plastic SOIC package.APPLICATIONSMedical instrumentationPrecision data acquisitionMicrophone preamplificationVibration analysis

The single ADA4077-1, dual ADA4077-2, and quad ADA4077-4amplifiers feature extremely low offset voltage and drift, and lowinput bias current, noise, and power consumption. Outputs are stable with capacitive loads of more than 1000 pF with no external compensation.Applications for this amplifier include sensor signal conditioning (such as thermocouples, resistance temperature detectors (RTDs),strain gages), process control front-end amplifiers, and precisiondiode power measurement in optical and wireless transmission systems. The ADA4077-1/ADA4077-2/ADA4077-4 are useful in line powered and portable instrumentation, precision filters,and voltage or current measurement and level setting.Unlike other amplifiers, the ADA4077-1/ADA4077-2/ADA4077-4 have an MSL1 rating that is compliant with the most stringent of assembly processes, and they are specified over theextended industrial temperature range from −40°C to +125°C for the most demanding operating environments.APPLICATIONS Process control front-end amplifiers  Optical network control circuits Instrumentation Precision sensors and controls Precision filters

The single ADA4077-1, dual ADA4077-2, and quad ADA4077-4amplifiers feature extremely low offset voltage and drift, and lowinput bias current, noise, and power consumption. Outputs are stable with capacitive loads of more than 1000 pF with no external compensation.Applications for this amplifier include sensor signal conditioning (such as thermocouples, resistance temperature detectors (RTDs),strain gages), process control front-end amplifiers, and precisiondiode power measurement in optical and wireless transmission systems. The ADA4077-1/ADA4077-2/ADA4077-4 are useful in line powered and portable instrumentation, precision filters,and voltage or current measurement and level setting.Unlike other amplifiers, the ADA4077-1/ADA4077-2/ADA4077-4 have an MSL1 rating that is compliant with the most stringent of assembly processes, and they are specified over theextended industrial temperature range from −40°C to +125°C for the most demanding operating environments.APPLICATIONS Process control front-end amplifiers  Optical network control circuits Instrumentation Precision sensors and controls Precision filters
