Real Time Clock I2C Serial RTC

Delay Line IC Nonprogrammable 5 Tap 500ns 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)

The AD9510 provides a multi-output clock distribution functionalong with an on-chip phase-locked loop (PLL) core. The designemphasizes low jitter and phase noise to maximize data converterperformance. Other applications with demanding phase noiseand jitter requirements also benefit from this device.The PLL section consists of a programmable reference divider(R); a low noise, phase frequency detector (PFD); a precisioncharge pump (CP); and a programmable feedback divider (N).By connecting an external voltage-controlled crystal oscillator(VCXO) or voltage-controlled oscillator (VCO) to the CLK2and CLK2B pins, frequencies of up to 1.6 GHz can be synchronizedto the input reference.There are eight independent clock outputs. Four outputs are lowvoltage positive emitter-coupled logic (LVPECL) at 1.2 GHz,and four are selectable as either LVDS (800 MHz) or CMOS(250 MHz) levels.Each output has a programmable divider that can be bypassedor set to divide by any integer up to 32. The phase of one clockoutput relative to another clock output can be varied by meansof a divider phase select function that serves as a coarse timingadjustment. Two of the LVDS/CMOS outputs feature programmabledelay elements with full-scale ranges up to 8 ns of delay.This fine tuning delay block has 5-bit resolution, giving 25possible delays from which to choose for each full-scale setting(Register 0x36 and Register 0x3A = 00000b to 11000b).The AD9510 is ideally suited for data converter clockingapplications where maximum converter performance isachieved by encode signals with subpicosecond jitter.The AD9510 is available in a 64-lead LFCSP and can be operatedfrom a single 3.3 V supply. An external VCO, which requires anextended voltage range, can be accommodated by connectingthe charge pump supply (VCP) to 5.5 V. The temperature rangeis −40°C to +85°C.Applications Low jitter, low phase noise clock distribution Clocking high speed ADCs, DACs, DDSs, DDCs, DUCs, and mixed-signal front ends (MxFEs) High performance wireless transceivers High performance instrumentation Broadband infrastructure

The ADF4360-2 is a fully integrated integer-N synthesizerand voltage-controlled oscillator (VCO). The ADF4360-2 isdesigned for a center frequency of 2000 MHz. In addition, adivide-by-2 option is available, whereby the user gets an RFoutput of between 925 MHz and 1085 MHz.Control of all the on-chip registers is through a simple 3-wireinterface. The device operates with a power supply rangingfrom 3.0 V to 3.6 V and can be powered down when not in use.Applications Wireless handsets (DECT, GSM, PCS, DCS, WCDMA) Test equipment Wireless LANs CATV equipment

The AD9531 provides a multioutput clock generator function and three on-chip phase-locked loop (PLL) cores with SPI programmable output frequencies and formats.PLL1 provides two reference inputs and 10 outputs and includes four user selectable loop configurations. The PLL has a fully integrated loop filter requiring only a single external capacitor (or a series RC network). PLL1 provides a wide range of output frequencies up to 400 MHz and is capable of operating with an external voltage controlled crystal oscillator (VCXO) and loop filter, instead of the integrated voltage controlled oscillator (VCO) and loop filter.PLL2 is an integer-N PLL providing a single reference input and 12 outputs. PLL2 synthesizes output frequencies up to 400 MHz from the REF2_x source and synchronizes the output clocks to the input reference.PLL3 provides a single reference input and two outputs. PLL3 synthesizes output frequencies up to 400 MHz from the REF3_x source and synchronizes the output clocks to input reference.The AD9531 is available in an 88-lead LFCSP and is specified over the −40°C to +85°C operating temperature range.Throughout this data sheet, multifunction pins, such as LOR/M4, are referred to either by the entire pin name or by a single function of the pin (for example, LOR, when only that function is relevant). In other cases, the text and figures of this data sheet contain references to a channel rather than a pin. For example, REF_A refers to the REF_A channel rather than the REF_AP and REF_AN pins. Likewise, OUT3_1 refers to Channel 1 of PLL3 rather than the OUT3_1P and OUT3_1N pins. Additionally, an abbreviated notation for a pin pair replaces an explicit reference to a each pin (for example, REF_Ax signifies the REF_AN and REF_AP pins.).Applications Radio equipment controller clocking Low jitter/phase noise clock generation and distribution Clock generation and translation for SONET, 10GE, 10G FC, and other 10 Gbps protocols 40 Gbps/100 Gbps networking line cards, including SONET, synchronous ethernet, OTU2/3/4 Forward error correction (G.710) High performance wireless transceivers ATE and high performance instrumentation Broadband infrastructures Ethernet line cards, switches, and routers SATA and PCI-express

Delay Lines/Timing Elements Broadband Analog Time Delay to 24 GHz

Real Time Clock Real-Time Event Recorder

The HMC582LP5(E) is a GaAs InGaP Herterojunction Bipolar Transistor (HBT) MMIC VCOs. The HMC582LP5(E) integrates resonators, negative resistance devices, varactor diodes and feature half frequency and divide-by-4 outputs. The VCO's phase noise performance is excellent over temperature, shock and process due to the oscillator's monolithic structure.Power output is +9 dBm typical from a +5V supply voltage. The prescaler and RF/2 functions can be disabled to conserve current if not required. The voltage controlled oscillator is packaged in a leadless QFN 5×5 mm surface mount package, and requires no external matching components.APPLICATIONS Point-to-Point Radios Point-to-Multi-Point Radios Test Equipment & Industrial Controls SATCOM Military End-Use

The HMC513LP5(E) is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC VCOs. The HMC513LP5(E) integrates resonators, negative resistance devices, varactor diodes and feature half frequency and divide-by- 4 outputs. The VCO’s phase noise performance is excellent over temperature, shock, and process due to the oscillator’s monolithic structure. Power output is +7 dBm typical from a +3V supply voltage. The prescaler function can be disabled to conserve current if not required. The voltage controlled oscillator is packaged in a leadless QFN 5×5 mm surface mount package, and requires no external matching components.APPLICATIONS VSAT Radio Point-to-Point/Multi-Point Radio  Test Equipment & Industrial Controls  Military End-Use

The ADF4368 is a high performance, ultralow jitter, integer-N and fractional-N phase-locked loop (PLL) with integrated VCO ideally suited for frequency conversion applications.The high performance PLL has a figure of merit of -239dBc/Hz, very low 1/f Noise of normalized -287dBc/Hz and high PFD frequency that can achieve ultralow in-band noise and integrated jitter. The ADF4368 can generate any frequency from 800 MHz to 12.8 GHz without an internal doubler, thereby eliminating the need for sub-harmonic filters. Σ-Δ modulator includes a 25-bit fixed modulus which allows hertz frequency resolution and an additional 24-bit variable modulus which allows even finer resolution and flexibility for frequency planning. 9 dBm output power at 12.8 GHz in single ended configuration with 16 step power adjust feature makes it very useful for any application.For multiple frequency conversion applications such as phase array radar or massive MIMO systems, the outputs of multiple ADF4368 can be aligned by using SYNC input or EZSync. EZSync method is used when it is difficult to distribute the SYNC signal to all parts precisely. For applications that require deterministic delay or delay adjustment capability, a programmable reference to output delay with The simplicity of the ADF4368 block diagram eases development time with a simplified SPI register map, external SYNC input and repeatable multi-chip phase alignment both in integer and fractional mode.APPLICATIONSWireless infrastructure (MC-GSM, 5G)Test and MeasurementAerospace and Defense
