The ADPD6000 is a highly integrated analog front end (AFE) designed for measuring various vital signals.The optical channel is designed as an optical transceiver, stimulating up to four light emitting diodes (LEDs) and measuring the return signal on up to four separate current inputs. The signal chain rejects signal offsets and corruption from asynchronous modulated interference, typically from ambient light, eliminating the need for optical filters or externally controlled dc cancellation circuitry.The electrocardiography (ECG) signal acquisition is designed to support low noise, diagnostic level measurement in the presence of a variety of interferers. The ECG signal chain has a number of complementary features supporting ECG measurement, such as driven reference for common-mode rejection and lead off detection to identify a fallen electrode.The body impedance analysis (BIA) signal chain is designed for body impedance measurement with a configurable excitation path and measurement path. A 12-bit digital-to-analog (DAC) is used in the excitation path to generate the sinusoid wave and high precision measurement, with configurable filters used to measure the body response of the stimulus.The data output and functional configuration use a serial port interface (SPI) on the ADPD6000. The control circuitry includes flexible LED signaling and synchronous detection, digital filters, digital wave generators, and configurable filters.The ADPD6000 is available in a 2.6 mm ? 2.6 mm, 0.4 mm pitch, 36-ball wafer level chip scale package (WLCSP).APPLICATIONS Wearable health and fitness monitors: heart rate, heart rate variability, SpO2, body impedance analysis, hydration, cuffless noninvasive blood pressure Home patient monitoring Industrial monitoring: particle and aerosol, gas, and conductivity detection

The AD5310R?/ AD5311R, members of the nanoDAC? family, are low power, single-channel, 10-bit buffered voltage-out DACs. The devices include a 2.5 V, 2 ppm/?C internal reference. The output span can be programmed to be 0 V to VREF or 0 V to 2 ? VREF. All devices operate from a single 2.7 V to 5.5 V supply and are guaranteed monotonic by design. The devices are available in 10-lead MSOP packages.The AD5310R / AD5311R also incorporate a power-on resetcircuit that ensures that the DAC output powers up to zeroscaleand remains there until a valid write takes place. Thedevice contains a power-down feature that reduces the currentconsumption of the device to 2 ?A at 5 V while in power-downmode.The AD5310R / AD5311R use a versatile SPI or I2C interface,including an asynchronous RESET pin and a VLOGIC pin, allowing 1.8 V compatibility.PRODUCT HIGHLIGHTS High Relative Accuracy (INL): ?0.5 LSB maximum. Low Drift 2.5 V On-Chip Reference: 5 ppm/?C maximum temperature coefficient.APPLICATIONS Process controls Data acquisition systems Digital gain and offset adjustment Programmable voltage sources Optical modules

The LTC2757 is an 18-bit multiplying parallel-input, current-output digital-to-analog converter that provides full 18-bit performance?INL and DNL of ?1LSB maximum?over temperature without any adjustments. 18-bit monotonicity is guaranteed in all performance grades. This SoftSpan? DAC operates from a single 3V to 5V supply and offers six output ranges (up to ?10V) that can be programmed through the parallel interface or pin-strapped for operation in a single range. In addition to its precision DC specifications, the LTC2757 also offers excellent AC specifications, including 2.1?s full-scale settling to 1LSB and 1.4nV?s glitch impulse. The LTC2757 uses a bidirectional input/output parallel interface that allows readback of any on-chip register, including DAC output-range settings; and a CLR pin and power-on reset circuit that each reset the DAC output to 0V regardless of output range.Applications Instrumentation Medical Devices Automatic Test Equipment Process Control and Industrial Automation

ADC 12BIT 80MSPS LFCSP-32; Resolution (Bits):12bit; Sampling Rate:80MSPS; Supply Voltage Type:Single; Supply Voltage Min:2.7V; Supply Voltage Max:3.6V; ADC / DAC Case Style:LFCSP; No. of Pins:32Pins; Input Channel Type:Differential Single Ended; Data Interface:-; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Cut Tape; Product Range:Single 12-Bit Pipelined ADCs; Automotive Qualification Standard:-; MSL:MSL 3 - 168 hours; SVHC:No SVHC (20-Jun-2016)

Digital to Analog Converters - DAC 3V/5V SINGLE 8 BIT DAC I.C.

ADC, 24BIT, 999KSPS, WSOIC-24 ROHS COMPLIANT: YES

2.7 V to 5.5 V, 140 A, Rail-to-Rail Voltage Output 12-Bit DAC in SOT-23 and MicroSOIC Packages Features: Micropower: 140 µA @ 5 V, 115 µA @ 3 V Power-Down to 200 nA @ 5 V, 50 nA @ 3 V Guaranteed Monotonic by design Power-On-Reset to Zero Volts Three Power-Down Functions SYNC (active low) Interrupt Facility Low Power, SPI™, QSPI™, MICROWIRE™ and DSP-Compatible 3-Wire Serial Interface Output Buffer Amplifier with Rail-to-Rail Operation Temperature Range: -40°C to 105°C Three Power-Down Functions

DAC 14BIT 400KSPS SSOP-24; Resolution (Bits):14bit; Sampling Rate:400kSPS; Input Channel Type:Parallel Serial; Supply Voltage Range:± 4.75V to ± 5.25V; ADC / DAC Case Style:SSOP; No. of Pins:24Pins; Data Interface:Parallel Serial; Operating Temperature Min:-25°C; Operating Temperature Max:85°C; Packaging:Cut Tape; Product Range:AD7840 Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016)

The AD9635 is a dual, 12-bit, 80 MSPS/125 MSPS analog-to-digital converter (ADC) with an on-chip sample-and-hold circuit designed for low cost, low power, small size, and ease of use. The product operates at a conversion rate of up to 125 MSPS and is optimized for outstanding dynamic performance and low power in applications where a small package size is critical.The ADC requires a single 1.8 V power supply and LVPECL-/ CMOS-/LVDS-compatible sample rate clock for full performanceoperation. No external reference or driver components arerequired for many applications.The ADC automatically multiplies the sample rate clock for theappropriate LVDS serial data rate. A data clock output (DCO) for capturing data on the output and a frame clock output (FCO) forsignaling a new output byte are provided. Individual channelpower-down is supported; the AD9635 typically consumes lessthan 2 mW in the full power-down state. The ADC providesseveral features designed to maximize flexibility and minimize system cost, such as programmable output clock and data alignment and digital test pattern generation. The available digital test patterns include built-in deterministic and pseudorandom patterns, along with custom user-defined test patterns entered via the serial port interface (SPI).The AD9635 is available in a RoHS-compliant, 32-lead LFCSP. It is specified over the industrial temperature range of ?40?Cto +85?C. PRODUCT HIGHLIGHTS Small Footprint. Two ADCs are contained in a small, spacesaving package. Low Power. The AD9635 uses 115 mW/channel at 125 MSPS with scalable power options. Pin Compatibility with the AD9645, a 14-Bit Dual ADC. Ease of Use. A data clock output (DCO) operates at frequencies of up to 500 MHz and supports double data rate (DDR) operation. User Flexibility. The SPI control offers a wide range of flexible features to meet specific system requirements. APPLICATIONS Communications Diversity radio systems Multimode digital receivers GSM, EDGE, W-CDMA, LTE, CDMA2000, WiMAX, TD-SCDMA I/Q demodulation systems Smart antenna systems Broadband data applications Battery-powered instruments Hand held scope meters Portable medical imaging and ultrasound Radar/LIDAR

The AD7686 is a 16-bit, charge redistribution, successive approximation, analog-to-digital converter (ADC) that operates from a single 5 V power supply, VDD. It contains a low power, high speed, 16-bit sampling ADC with no missing codes, an internal conversion clock, and a versatile serial interface port. The part also contains a low noise, wide bandwidth, short aperture delay track-and-hold circuit. On the CNV rising edge, the AD7686 samples an analog input IN+ between 0 V to REF with respect to a ground sense IN?. The reference voltage, REF, is applied externally and can be set up to the supply voltage.Power dissipation scales linearly with throughput.The SPI-compatible serial interface also features the ability, using the SDI input, to daisy-chain several ADCs on a single, 3-wire bus or provides an optional busy indicator. This device is compatible with 1.8 V, 2.5 V, 3 V, or 5 V logic, using the separate supply VIO.The AD7686 is housed in a 10-lead MSOP or a 10-lead QFN (LFCSP) with operation specified from ?40?C to +85?C.APPLICATIONS Battery-powered equipment Data acquisitions Instrumentation Medical instruments Process controls
