DC847A: Demo Board for the LTC2446 24-Bit High Speed 8-Channel Delta Sigma ADCs with Selectable Multiple Reference Inputs.

The AD9625 is a 12-bit monolithic sampling analog-to-digital converter (ADC) that operates at conversion rates of up to 2.6 giga samples per second (GSPS). This product is designed for sampling wide bandwidth analog signals up to the second Nyquist zone. The combination of wide input bandwidth, high sampling rate, and excellent linearity of the AD9625 is ideally suited for spectrum analyzers, data acquisition systems, and a wide assortment of military electronics applications, such as radar and jamming/antijamming measures.The analog input, clock, and SYSREF? signals are differential inputs. The JESD204B-based high speed serialized output is configurable in a variety of one-, two-, four-, six-, or eight-lane configurations. The product is specified over the industrial temperature range of ?40?C to +85?C.PRODUCT HIGHLIGHTS High performance: exceptional SFDR in high sample rate applications, direct RF sampling, and on-chip reference. Flexible digital data output formats based on the JESD204B specification. Control path SPI interface port that supports various product features and functions, such as data formatting, gain, and offset calibration values.APPLICATIONS Spectrum analyzers Military communications Radar High performance digital storage oscilloscopes Active jamming/antijamming Electronic surveillance and countermeasures

The AD7124-8 is a low power, low noise, completely integratedanalog front end for high precision measurement applications.The device contains a low noise, 24-bit ?-? analog-to-digitalconverter (ADC), and can be configured to have 8 differentialinputs or 15 single-ended or pseudo differential inputs. The onchiplow gain stage ensures that signals of small amplitude canbe interfaced directly to the ADC.One of the major advantages of the AD7124-8 is that it gives theuser the flexibility to employ one of three integrated powermodes. The current consumption, range of output data rates,and rms noise can be tailored with the power mode selected.The device also offers a multitude of filter options, ensuring thatthe user has the highest degree of flexibility.The AD7124-8 can achieve simultaneous 50 Hz and 60 Hzrejection when operating at an output data rate of 25 SPS (singlecycle settling), with rejection in excess of 80 dB achieved at loweroutput data rates.The AD7124-8 establishes the highest degree of signal chainintegration. The device contains a precision, low noise, lowdrift internal band gap reference and accepts an externaldifferential reference, which can be internally buffered. Otherkey integrated features include programmable low drift excitationcurrent sources, burnout currents, and a bias voltage generator,which sets the common-mode voltage of a channel to AVDD/2.The low-side power switch enables the user to power downbridge sensors between conversions, ensuring the absoluteminimal power consumption of the system. The device alsoallows the user the option of operating with either an internalclock or an external clock.The integrated channel sequencer allows several channels to beenabled simultaneously, and the AD7124-8 sequentially convertson each enabled channel, simplifying communication with thedevice. As many as 16 channels can be enabled at any time, achannel being defined as an analog input or a diagnostic suchas a power supply check or a reference check. This uniquefeature allows diagnostics to be interleaved with conversions.The AD7124-8 also supports per channel configuration. Thedevice allows eight configurations or setups. Each configurationconsists of gain, filter type, output data rate, buffering, andreference source. The user can assign any of these setups on achannel by channel basis.The AD7124-8 also has extensive diagnostic functionalityintegrated as part of its comprehensive feature set. Thesediagnostics include a cyclic redundancy check (CRC), signalchain checks, and serial interface checks, which lead to a morerobust solution. These diagnostics reduce the need for externalcomponents to implement diagnostics, resulting in reducedboard space needs, reduced design cycle times, and cost savings.The failure modes effects and diagnostic analysis (FMEDA) of atypical application has shown a safe failure fraction (SFF) greaterthan 90% according to IEC 61508.The device operates with a single analog power supply from 2.7 Vto 3.6 V or a dual 1.8 V power supply. The digital supply has arange of 1.65 V to 3.6 V. It is specified for a temperature rangeof ?40?C to +125?C. The AD7124-8 is housed in a 32-leadLFCSP package.Note that, throughout this data sheet, multifunction pins, suchas DOUT/RDY, are referred to either by the entire pin name orby a single function of the pin, for example, RDY, when onlythat function is relevant.Applications Temperature measurement Pressure measurement Industrial process control Instrumentation Smart transmitters

The AD9635 is a dual, 12-bit, 80 MSPS/125 MSPS analog-to-digital converter (ADC) with an on-chip sample-and-hold circuit designed for low cost, low power, small size, and ease of use. The product operates at a conversion rate of up to 125 MSPS and is optimized for outstanding dynamic performance and low power in applications where a small package size is critical.The ADC requires a single 1.8 V power supply and LVPECL-/ CMOS-/LVDS-compatible sample rate clock for full performanceoperation. No external reference or driver components arerequired for many applications.The ADC automatically multiplies the sample rate clock for theappropriate LVDS serial data rate. A data clock output (DCO) for capturing data on the output and a frame clock output (FCO) forsignaling a new output byte are provided. Individual channelpower-down is supported; the AD9635 typically consumes lessthan 2 mW in the full power-down state. The ADC providesseveral features designed to maximize flexibility and minimize system cost, such as programmable output clock and data alignment and digital test pattern generation. The available digital test patterns include built-in deterministic and pseudorandom patterns, along with custom user-defined test patterns entered via the serial port interface (SPI).The AD9635 is available in a RoHS-compliant, 32-lead LFCSP. It is specified over the industrial temperature range of ?40?Cto +85?C. PRODUCT HIGHLIGHTS Small Footprint. Two ADCs are contained in a small, spacesaving package. Low Power. The AD9635 uses 115 mW/channel at 125 MSPS with scalable power options. Pin Compatibility with the AD9645, a 14-Bit Dual ADC. Ease of Use. A data clock output (DCO) operates at frequencies of up to 500 MHz and supports double data rate (DDR) operation. User Flexibility. The SPI control offers a wide range of flexible features to meet specific system requirements. APPLICATIONS Communications Diversity radio systems Multimode digital receivers GSM, EDGE, W-CDMA, LTE, CDMA2000, WiMAX, TD-SCDMA I/Q demodulation systems Smart antenna systems Broadband data applications Battery-powered instruments Hand held scope meters Portable medical imaging and ultrasound Radar/LIDAR

The AD7986 is an 18-bit, 2 MSPS successive approximation, analog-to-digital converter (ADC). It contains a low power,high speed, 18-bit sampling ADC, an internal conversion clock, an internal reference (and buffer), error correction circuits, anda versatile serial interface port. On the rising edge of CNV, the AD7986 samples the voltage difference between the IN+ andIN− pins. The voltages on these pins usually swing in opposite phases between 0 V and VREF. It features a very high samplingrate turbo mode (TURBO = high) and a reduced power normal mode (TURBO = low) for low power applications where thepower is scaled with the throughput.In normal mode (TURBO = low), the SPI-compatible serial interface also features the ability, using the SDI input, to daisychainseveral ADCs on a single 3-wire bus and provide an optional busy indicator. It is compatible with 1.8 V, 2.5 V, and 2.7 V using theseparate VIO supply.The AD7986 is available in a 20-lead LFCSP with operationspecified from −40°C to +85°C. Applications Battery-powered equipment Data acquisition systems Medical instruments Seismic data acquisition systems

DC1369A-G: Demo Board for the LTC2261-12 12-Bit, 125Msps Ultralow Power 1.8V ADCs

16-Bit DAC in SOIC-8 Package Features: 16-bit resolution ±1 LSB DNL ±1 LSB INL Low noise: 12 nV/√Hz Low power: IDD = 10 μA 0.5 μs settling time 4-quadrant multiplying reference input 2 mA full-scale current ± 20%, with VREF= 10 V Built-in RFB facilitates voltage conversion 3-wire interface Ultracompact 8-lead MSOP and 8-lead SOIC packagesAD5543-EP supports defense and aerospace applications (AQEC standard) Download AD5543-EP Data Sheet (pdf) Military temperature range (−55°C to +125°C) Controlled manufacturing baseline One assembly/test site One fabrication site Enhanced product change notification Qualification data available on request

DA CONVERTOR;

24BIT ADC 3CH SD PGA SMD 7799; Resolution (Bits):24bit; Sampling Rate:470SPS; Supply Voltage Type:Single; Supply Voltage Min:2.7V; Supply Voltage Max:5.25V; ADC / DAC Case Style:TSSOP; No. of Pins:16Pins; Input Channel Type:Differential; Data Interface:Serial; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Packaging:Each; Product Range:Triple 24-Bit Sigma-Delta ADCs; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016); A/D / D/A Features:3-Wire Serial SPI QSPI Interface Microwire DSP Compatible On-Chip In-Amp Low Noise Low Power; Base Number:7799; Conversion Time:2000µs; Data Rate:500bps; IC Case Style:TSSOP; IC Generic Number:7799; Logic Function Number:7799; No. of Bits:24bit; No. of Channels:3Channels; Operating Temperature Range:-40°C to +105°C; Supply Current:440µA; Supply Voltage Range:2.7V to 5.25V; Supply Voltage Range - Analogue:2.7V to 5.25V; Supply Voltage Range - Digital:2.7V to 5.25V; Termination Type:Surface Mount Device

16BIT ADC SIGMA-DELTA SMD TSSOP24; Resolution (Bits):16bit; Sampling Rate:-; Supply Voltage Type:-; Supply Voltage Min:2.7V; Supply Voltage Max:5.25V; ADC / DAC Case Style:TSSOP; No. of Pins:24Pins; Input Channel Type:Differential Single Ended; Data Interface:Serial; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Each; Product Range:Quad 16-Bit Sigma-Delta ADCs; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016); Base Number:7709; IC Case Style:TSSOP; No. of Bits:16bit; No. of Channels:4Channels; Operating Temperature Range:-40°C to +85°C; Supply Current:1.75mA; Supply Voltage Range - Analogue:2.7V to 3.6V 4.75V to 5.25V; Termination Type:Surface Mount Device
