DC851A-H: Demo Board for the LTC2294 Dual 12-Bit, 80Msps Low Power 3V ADC.

The ADPD4100/ADPD4101 operate as a complete multimodal sensor front end, stimulating up to eight light emitting diodes (LEDs) and measuring the return signal on up to eight separate current inputs. Twelve time slots are available, enabling 12 separate measurements per sampling period. The data output and functional configuration utilize an I2C interface on the ADPD4101 or a serial port interface (SPI) on the ADPD4100. The control circuitry includes flexible LED signaling and synchronous detection. The devices use a 1.8 V analog core and 1.8 V/3.3 V compatible digital input/output (I/O). The analog front end (AFE) rejects signal offsets and corruption from asynchronous modulated interference, typically from ambient light, eliminating the need for optical filters or externally controlled dc cancellation circuitry. Multiple operating modes are provided, enabling the ADPD4100/ADPD4101 to be a sensor hub for synchronous measurements of photodiodes, biopotential electrodes, resistance, capacitance, and temperature sensors. The multiple operation modes accommodate various sensor measurements, including, but not limited to, photoplethysmography (PPG), electrocardiography (ECG), electrodermal activity (EDA), impedance, capacitance, temperature, gas detection, smoke detection, and aerosol detection for various healthcare, industrial, and consumer applications. The ADPD4100/ADPD4101 are available in a 3.11 mm ? 2.14 mm, 0.4 mm pitch, 33-ball WLCSP and 35-ball WLCSPApplications Wearable health and fitness monitors: heart rate monitors (HRMs), heart rate variability (HRV), stress, blood pressure estimation, SpO2, hydration, body composition Industrial monitoring: CO, CO2, smoke, and aerosol detection Home patient monitoring

AD CONVERTOR;

Dual 12-Bit, 105Msps Low Power 3V ADC Features: Integrated Dual 12-Bit ADCs Rate: 105Msps Single 3V Supply (2.85V to 3.4V) Low Power: 540mW 70.1dB SNR, 88dB SFDR 110dB Channel Isolation at 100MHz Flexible Input: 1VP-P to 2VP-P Range 575MHz Full Power Bandwidth S/H Clock Duty Cycle Stabilizer Shutdown and Nap Modes Pin Compatible Family 105Msps: LTC2282 (12-Bit), LTC2284 (14-Bit) 80Msps: LTC2294 (12-Bit), LTC2299 (14-Bit) 65Msps: LTC2293 (12-Bit), LTC2298 (14-Bit) 40Msps: LTC2292 (12-Bit), LTC2297 (14-Bit) 25Msps: LTC2291 (12-Bit), LTC2296 (14-Bit) 10Msps: LTC2290 (12-Bit), LTC2295 (14-Bit) 64-Pin (9mm × 9mm) QFN Package

The AD7194 is a low noise, complete analog front end for high precision measurement applications. It contains a low noise, 24-bit sigma-delta (?-?) analog-to-digital converter (ADC). The on-chip low noise gain stage means that signals of small amplitude can interface directly to the ADC.The device can be configured to have eight differential inputs or sixteen pseudo differential inputs. The on-chip 4.92 MHz clock can be used as the clock source to the ADC or, alternatively, an external clock or crystal can be used. The output data rate from the part can be varied from 4.7 Hz to 4.8 kHz.The device has a very flexible digital filter, including a fast settling option. Variables such as output data rate and settling time are dependent on the option selected. For applications that require all conversions to be settled, the AD7194 includes zero latency.The part operates with a power supply from 3 V to 5.25 V. It consumes a current of 4.65 mA, and it is housed in a 32-lead LFCSP package.Applications PLC/DCS analog input modules Data acquisition Strain gage transducers Pressure measurement Temperature measurement Flow measurement Weigh scales Chromatography Medical and scientific instrumentation

Data Conversion IC Development Tools EVAL BRD AD5379

Data Conversion IC Development Tools EVAL BRD AD5680

Data Conversion IC Development Tools LTC2654-L12 Demo Board - Quad SPI 12-bit

Data Conversion IC Development Tools LTC2257-12: 12-bit 40Msps ADC, CMOS Outp

Data Conversion IC Development Tools LTC1668 with LT6600 Demo Board 16-Bit, 50Msps DAC, Differential +/-0.25V outputs
