CMOS, 24-Bit Signal Conditioning ADC with Current Source Features: Charge Balancing ADC 24 Bits, No Missing Codes ±0.0015% Nonlinearity 2-Channel Programmable Gain Front End Gains from 1 to 128 Differential Inputs Low-Pass Filter with Programmable Filter Cutoffs Ability to Read/Write Calibration Coefficients Bidirectional Microcontroller Serial Interface Internal/External Reference Option Single- or Dual-Supply Operation Low Power (25 mW Typ) with Power-Down Mode (7 mW Typ)

20-Bit, Pin-Programmable, Ultralow Power Sigma-Delta ADC Features:Pin-programmable filter responseUpdate rate: 10 Hz or 16.7 HzPin-programmable in-amp gainPin-programmable power-down and resetStatus functionInternal clock oscillatorInternal bridge power-down switchCurrent:115 A typical (Gain = 1)330 A typical (Gain = 128)Simultaneous 50 Hz/60 Hz rejectionPlease see data sheet for additional features

Low Power, 2-Channel 24-Bit Sigma-Delta ADC Features: Power Supply: 2.5 V to 5.25 V current Normal: 75 µA max Power-down: 1 µA max RMS noise: 1.1 µV at 9.5 Hz update rate 19.5-bit p-p resolution (22 bits effective resolution) Integral nonlinearity: 3.5 ppm typical Simultaneous 50 Hz and 60 Hz rejection Internal clock oscillator Rail-to-rail input buffer VDD monitor channel Temperature range: –40°C to +105°C 10-lead MSOP Interface 3-wire serial  SPI®, QSPI™, MICROWIRE™ and DSP compatible Schmitt trigger on SCLK

10-Bit, 4-Channel, 350 kSPS, Serial A/D Converter Features: 10-Bit ADC with 2.3 µs Conversion Time Four Single-Ended Inputs to Configure as Three Pseudo Differential Inputs with Respect to a Common, or as Two Independent Pseudo Differential Channels Onboard Track and Hold Onboard Reference 2.5 V ± 2.5% Operating Supply Range: 2.7 V to 5.5 V Specifications at 2.7 V–3.6 V and 5 V ± 10% DSP-/Microcontroller-Compatible Serial Interface High Speed Sampling and Automatic  Power-Down Modes Package Address Pin on AD7811 and AD7812 Allows Sharing of Serial Bus in Multipackage Applications Input Signal Range: 0 V to VREF Reference Input Range: 1.2 V to VDD Qualified for Automotive Applications

High Speed , 8-Channel, 8-Bit CMOS ADC Features: 4 or 8 Analog Input Channels Built-In Track-and-Hold Function 10 kHz Signal Handling on Each Channel Fast Microprocessor Interface Single 5 V Supply Low Power: 50 mW Fast Conversion Rate: 2.5 µs/Channel Tight Error Specification: 1/2 LSB

16-/14-/11-Bit 2.7Gsps DACs Features:80dBc SFDR at 50MHz fOUT>68dBc SFDR from DC to 1080MHz fOUT40mA Nominal Full-Scale, ±1V Output Compliant10mA to 60mA Adjustable Full-Scale Current RangeSingle or Dual Port DDR LVDS and DHSTL InterfaceLow Latency (7.5 Cycles for Single Port, 11 Cycles for Dual Port)>78dBc 2-Tone IMD from DC to 1000MHz fOUT–156dBc/Hz Additive Phase Noise at 1MHz Offset for 65MHz fOUT170-Lead (9mm × 15mm) BGA Package

Octal 16-Bit/12-Bit 10V VOUT SoftSpan DACs with 10ppm/C Max Reference Features: Precision Reference 10ppm/°C Max Independently Programmable Output Ranges: 0V to 5V, 0V to 10V, ±2.5V, ±5V, ±10V Full 16-Bit/12-Bit Resolution at All Ranges Maximum INL Error: ±4LSB at 16 Bits A/B Toggle via Software or Dedicated Pin 8:1 Analog Multiplexer Guaranteed Monotonic Over Temperature Internal or External Reference Outputs Drive ±10mA Guaranteed 1.8V to 5V SPI Serial interface 32-Lead (5mm × 5mm) QFN Package

16-/14-/11-Bit 2.5Gsps DACs Features:80dBc SFDR at 70MHz fOUT>68dBc SFDR from DC to 1000MHz fOUT40mA Nominal Full-Scale, ±1V Output Compliant10mA to 60mA Adjustable Full-Scale Current RangeSingle or Dual Port DDR LVDS and DHSTL InterfaceLow Latency (7.5 Cycles for Single Port, 11 Cycles for Dual Port)>78dBc 2-Tone IMD from DC to 1000MHz fOUT–165dBc/Hz Additive Phase Noise at 1MHz Offset for 65MHz fOUT170-Lead (9mm × 15mm) BGA Package

Precision, Low Power Differential Amplifier/ADC Driver Family Features: Available with User Settable Gain or Fixed-Gain of 0.5V/V, 1V/V, or 2V/V 2.9nV/√Hz Input-Referred Noise 2mA Maximum Supply Current 45ppm Max Gain Error 0.5ppm/°C Max Gain Error Drift 94dB Min CMRR 100µV Max Offset Voltage 50nA Max Input Offset Current Fast Settling: 720ns to 18-Bit, 8VP-P Output 2.8V (±1.4V) to 11V (±5.5V) Supply Voltage Range Differential Rail-to-Rail Outputs Input Common Mode Range Includes Ground Low Distortion: 118dB SFDR at 2kHz, 18VP-P 500MHz Gain-Bandwidth Product 35MHz –3dB Bandwidth Low Power Shutdown: 20µA (VS = 3V) 8-Lead MSOP, 2mm × 3mm 8-Lead DFN and 3mm × 3mm 16-lead LFCSP Packages

Serial 14-Bit, 2.8Msps Sampling ADCs with Shutdown Features: 2.8Msps Conversion Rate Low Power Dissipation: 14mW 3V Single Supply Operation 2.5V Internal Bandgap Reference can be Overdriven 3-Wire Serial Interface Sleep (10μW) Shutdown Mode Nap (3mW) Shutdown Mode 80dB Common Mode Rejection ±1.25V Bipolar Input Range Tiny 10-Lead MSE Package
