Instrumentation Amplifier 3 Circuit 16-LFCSP-VQ (4x4)

Analog to Digital Converters - ADC 12 bit 105msps low pwr quad ADC

IC D/A CONVERTER SINGLE 14-BIT CMOS TSSOP 28PIN

Analog to Digital Converters - ADC CMOS CONVERTER IC

Phase Locked Loops - PLL 1000-2500MHz Frac-N PLL

Linear Voltage Regulator IC Positive Fixed 1 Output 200mA 4-WLCSP (0.76x0.76)

Supervisory Circuits 5V CMOS PROCESS I.C.

Analog to Digital Converters - ADC IC, MONO 12-BIT ADC IC

Precision Analog Microcontroller, 12-Bit Analog I/O, ARM7TDMI MCU Features: Analog I/O Multichannel, 12-bit, 1 MSPS ADC Up to 16 ADC channels Fully differential and single-ended modes 0 V to VREF analog input range12-bit voltage output DACs Up to 4 DAC outputs available On-chip voltage reference On-chip temperature sensor (±3°C) Voltage comparator Microcontroller ARM7TDMI core, 16-bit/32-bit RISC architecture JTAG port supports code download and debug Clocking options Trimmed on-chip oscillator (±3%) External watch crystal External clock source up to 44 MHz 41.78 MHz PLL with programmable divider See datasheet for additional features

Very Low Quiescent Current, 150 mA, with Output Discharge LDO Regulator Features: Very low quiescent current IQ = 590 nA with 0 µA load IQ = 890 nA with 1 µA load Maintains very low quiescent current in dropout (pass through mode): IQ_DROP = 720 nA with 0 µA load IQ_DROP = 1200 nA with 1 µA load Stable with 1 µF ± 30% ceramic input and output capacitors Maximum load current: ILOAD_MAX: 150 mA Input voltage range: 2.2 V to 5.5 V Low shutdown current: 50 nA typical Low dropout voltage: 120 mV at 150 mA load Initial output voltage accuracy: ±1% Accuracy over line, load, and temperature: ±3.5% 7 fixed output voltage options: 1.2 V to 3.3 V Adjustable output option can be set from 1.2 V to 4.2 V See data sheet for additional features
