Precision, Miniature MEMS IMU Features: Triaxial, digital gyroscope ±125°/sec, ±500°/sec, ±2000°/sec dynamic range models 2.3°/hr in-run bias stability (ADIS16507-1) 0.13°/√hr angular random walk, x-axis and y-axis, 1 σ (ADIS16507-1) ±0.25° axis to axis misalignment error Triaxial, digital accelerometer, ±392 m/sec2 dynamic range 125 μm/sec2 in-run bias stability, x-axis and y-axis, 1 σ Triaxial, delta angle and delta velocity outputs Factory calibrated sensitivity, bias, and axial alignment Calibration temperature range: −40°C to +85°C SPI compatible data communications Programmable operation and control Automatic and manual bias correction controls Data ready indicator for synchronous data acquisition External sync modes: direct, scaled, and output On demand self-test of inertial sensors On demand self-test of flash memory Single-supply operation (VDD): 3.0 V to 3.6 V 19,600 m/sec2 mechanical shock survivability Operating temperature range: −40°C to +105°C

3-Axis, 1.5g/3g/6g/12gDigital Accelerometer Features: Ultralow power: as low as 57 μA in measurement mode and 0.1 μA in standby mode at VS = 3.3 V (typical) Power consumption scales automatically with bandwidth User-selectable resolution Fixed 10-bit resolution Full resolution, where resolution increases with g range, up to 13-bit resolution at ±12 g (maintaining 2.9 mg/LSB scale factor in all g ranges) Embedded FIFO technology minimizes host processor load Supply and I/O voltage range: 2.0 V to 3.6 V Built-in motion detection functions for activity/inactivity monitoring SPI (3- and 4-wire) and I2C digital interfaces Flexible interrupt modes mappable to either interrupt pin Measurement ranges selectable via serial command Bandwidth selectable via serial command Wide temperature range (−40 to +105°C) 10,000 g shock survival Pb free/RoHS compliant Small and thin: 5 mm × 5 mm × 1.45 mm LFCSP package Qualified for automotive applications

3-Axis, 2 g/4 g/8 g/16 g Digital Accelerometer Features: Multipurpose accelerometer with 10- to 13-bit resolution for use in a wide variety of applications Digital output accessible via SPI (3- and 4-wire) and I2C Built-in motion detection features make tap, double-tap, activity, inactivity, and free-fall detection trivial User-adjustable thresholds Interrupts independently mappable to two interrupt pins Low power operation down to 23 μA and embedded FIFO for reducing overall system power Wide supply voltage range: 2.0 V to 3.6 V I/O voltage 1.7 V to VS Wide operating temperature range (−40°C to +85°C) 10,000 g shock survival Small, thin, Pb free, RoHS compliant 3 mm × 5 mm × 1 mm LGA package

3-Axis, 2 g/4 g/8 g/16 g Digital Accelerometer Features: Multipurpose accelerometer with 10- to 13-bit resolution for use in a wide variety of applications Digital output accessible via SPI (3- and 4-wire) and I2C Built-in motion detection features make tap, double-tap, activity, inactivity, and free-fall detection trivial User-adjustable thresholds Interrupts independently mappable to two interrupt pins Low power operation down to 23 μA and embedded FIFO for reducing overall system power Wide supply voltage range: 2.0 V to 3.6 V I/O voltage 1.7 V to VS Wide operating temperature range (−40°C to +85°C) 10,000 g shock survival Small, thin, Pb free, RoHS compliant 3 mm × 5 mm × 1 mm LGA package

3-Axis, 2 g/4 g/8 g/16 g Ultralow Power Digital Accelerometer Features: Multipurpose accelerometer with 10- to 13-bit resolution for use in a wide variety of applications Digital output accessible via SPI (3- and 4-wire) and I2C Built-in motion detection features make tap, double-tap, activity, inactivity, orientation, and free-fall detection trivial user-adjustable thresholds interrupts independently mappable to two interrupt pins Low power operation down to 23 μA and embedded FIFO for reducing overall system power Wide supply and I/O voltage range: 1.7 V to 2.75 V Wide operating temperature range (−40°C to +85°C) 10,000 g shock survival Small, thin Pb free, RoHS compliant 3 mm × 3 mm × 0.95 mm LGA package

Low Noise, Low Drift, Low Power, 3-Axis MEMS Accelerometers Features: Hermetic package offers excellent long-term stability 0 g offset vs. temperature (all axes): 0.15 mg/°C maximum Ultralow noise density (all axes): 22.5µg/√Hz Low power, VSUPPLY (LDO regulator enabled) ADXL354 in measurement mode: 150 μA ADXL355 in measurement mode: 200 μA ADXL354/ADXL355 in standby mode: 21 μA ADXL354 has user adjustable analog output bandwidth Electromechanical self test Integrated temperature sensor ADXL355 digital output features Digital SPI and I2C interfaces supported 20-bit ADC Data interpolation routine for synchronous sampling Programmable high- and low-pass digital filters Voltage range options VSUPPLY with internal regulators: 2.25 V to 3.6 V V1P8ANA, V1P8DIG with internal LDO regulator bypassed: 1.8 V typical ± 10% Operating temperature range: −40°C to +125°C 14-terminal, 6 mm × 5.6 mm × 2.2 mm, LCC package

Micropower, 3-Axis, 2 g/4 g/8 g Digital Output MEMS Accelerometer Features: Ultralow power Power can be derived from coin cell battery 1.8 μA at 100 Hz ODR, 2.0 V supply 3.0 μA at 400 Hz ODR, 2.0 V supply 270 nA motion activated wake-up mode 10 nA standby current High resolution: 1 mg/LSB Built-in features for system-level power savings: Adjustable threshold sleep/wake modes for motion activation Autonomous interrupt processing, without need for microcontroller intervention, to allow the rest of the system to be turned off completely Deep embedded FIFO minimizes host processor load Awake state output enables implementation of standalone, motion activated switch Low noise down to 175 μg/√Hz Wide supply and I/O voltage ranges: 1.6 V to 3.5 V Operates off 1.8 V to 3.3 V rails Acceleration sample synchronization via external trigger On-chip temperature sensor SPI digital interface Measurement ranges selectable via SPI command Small and thin 3 mm × 3.25 mm × 1.06 mm package

Micropower, 3-Axis, 200 g Digital Output, MEMS Features: ±200g measurement range 200 Hz to 3200 Hz user-selectable bandwidth with 4-pole anti-aliasing filter Selectable over-sampling ratio  Adjustable high-pass filter  Ultralow power Power can be derived from a coin cell battery 22 µA @ 3200 Hz ODR, 2.5 V supply Low power, wake-up mode for low g activity detection 1.4 μA instant on mode with adjustable threshold <0.1 μA standby mode Built-in features for system-level power savings Autonomous interrupt processing without processor intervention Deep embedded FIFO to minimize host processor load Ultralow power event monitoring detects impacts and wakes up fast enough to capture the transient events Ability to capture and store peak acceleration values of events  Adjustable, low g threshold activity/inactivity detection Wide supply range: 1.6 V to 3.5 V  Acceleration sample synchronization via external trigger SPI digital interface and limited 12C interface format support  12-bit output at 100 mg/LSB scale factor Wide temperature range: −40°C to 105°C Small, thin, 3 mm × 3.25 mm × 1.06 mm package

Micropower, 3-Axis, 400 g, Digital Output, MEMS Accelerometer Features: ±400 g measurement range 160 Hz to 2560 Hz user selectable bandwidth with 4-pole antialiasing filter Selectable oversampling ratio Adjustable high-pass filter Ultra Low power Power can be derived from a coin cell battery 19 μA at 2560 Hz ODR, 2.5 V supply Low power wake-up mode for low g activity detection 1.4 μA instant on mode with adjustable threshold 0.1 μA standby mode Built-in features for system level power savings Autonomous interrupt processing without processor intervention Ultra low power event monitoring: detects impacts and wakes up fast enough to capture the transient events Adjustable low g threshold activity and inactivity detection Wide operating voltage range: 1.6 V to 3.5 V Acceleration sample synchronization via external trigger SPI digital interface and I2C interface format support 12-bit output at 200 mg/LSB scale factor Wide temperature range: −40°C to +105°C Small, thin 3.00 mm × 3.25 mm × 1.06 mm package

Low Noise, Wide Bandwidth, MEMS Accelerometer Features: Single, in-plane axis accelerometer with analog output Full-scale range: ±200 g Linear frequency response range: dc to 15 kHz typical (3 dB point) Resonant frequency: 28 kHz typical Sensitivity performance Sensitivity stability over temperature within ± 5% Linearity to ±0.2% of full-scale range Cross-axis sensitivity ± 1%/± 0.8% (z-axis acceleration effect on x-axis, y-axis acceleration effect on x-axis) Ultralow noise density 45 μg/√Hz Overrange sensing plus dc coupling allows fast recovery time Complete electromechanical self test Single-supply operation Output voltage ratiometric to supply Low power consumption: 1.0 mA typical Power saving standby operation mode with fast recovery RoHS compliant −40°C to +125°C temperature range 32-lead, 5 mm × 5 mm × 1.8 mm LFCSP package
