3.3V Single Supply Video Difference Amplifier Features: Differential or Single-Ended Gain Block Wide Supply Range 3V to 12.6V Output Swings Rail-to-Rail Input Common Mode Range Includes Ground 600V/µs Slew Rate –3dB Bandwidth = 75MHz, AV = ±2 CMRR at 10MHz: >60dB Specified on 3.3V, 5V and ±5V Supplies High Output Drive: ±70mA Power Shutdown to 300µA Operating Temperature Range: –40°C to 85°C Available in 8-Lead SO and Tiny 3mm x 3mm x 0.8mm DFN Packages

Dual 14-Bit, 65Msps Low Power 3V ADCs Features: Integrated Dual 14-Bit ADCs Sample Rate: 65Msps/40Msps/25Msps Single 3V Supply (2.7V to 3.4V) Low Power: 400mW/235mW/150mW 74.3dB SNR 90dB SFDR 110dB Channel Isolation at 100MHz Multiplexed or Separate Data Bus Flexible Input: 1VP-P to 2VP-P Range 575MHz Full Power Bandwidth S/H Clock Duty Cycle Stabilizer Shutdown and Nap Modes Pin Compatible Family 105Msps: LTC2282 (12-Bit), LTC2284 (14-Bit) 80Msps: LTC2294 (12-Bit), LTC2299 (14-Bit) 65Msps: LTC2293 (12-Bit), LTC2298 (14-Bit) 40Msps: LTC2292 (12-Bit), LTC2297 (14-Bit) 25Msps: LTC2291 (12-Bit), LTC2296 (14-Bit) 64-Pin (9mm × 9mm) QFN Package

Dual 12-Bit, 65Msps Low Power 3V ADCs Features: Integrated Dual 12-Bit ADCs Sample Rate: 65Msps/40Msps/25Msps Single 3V Supply (2.7V to 3.4V) Low Power: 400mW/235mW/150mW 71.3 dB SNR 90dB SFDR 110dB Channel Isolation at 100MHz Multiplexed or Separate Data Bus Flexible Input: 1VP-P to 2VP-P Range 575MHz Full Power Bandwidth S/H Clock Duty Cycle Stabilizer Shutdown and Nap Modes Pin Compatible Family 105Msps: LTC2282 (12-Bit), LTC2284 (14-Bit) 80Msps: LTC2294 (12-Bit), LTC2299 (14-Bit) 65Msps: LTC2293 (12-Bit), LTC2298 (14-Bit) 40Msps: LTC2292 (12-Bit), LTC2297 (14-Bit) 25Msps: LTC2291 (12-Bit), LTC2296 (14-Bit) 10Msps: LTC2290 (12-Bit), LTC2295 (14-Bit) 64-Pin (9mm × 9mm) QFN Package

Dual 10-Bit, 25Msps Low Noise 3V ADCs Features: Integrated Dual 10-Bit ADCs Sample Rate: 65Msps/40Msps/25Msps Single 3V Supply (2.7V to 3.4V) Low Power: 400mW/235mW/150mW 61.8dB SNR 85dB SFDR 110dB Channel Isolation at 100MHz Multiplexed or Separate Data Bus Flexible Input: 1VP-P to 2VP-P Range 575MHz Full Power Bandwidth S/H Clock Duty Cycle Stabilizer Shutdown and Nap Modes Pin Compatible Family 105Msps: LTC2282 (12-Bit), LTC2280 (10-Bit) 80Msps: LTC2294 (12-Bit), LTC2289 (10-Bit) 65Msps: LTC2293 (12-Bit), LTC2288 (10-Bit) 40Msps: LTC2292 (12-Bit), LTC2287 (10-Bit) 25Msps: LTC2291 (12-Bit), LTC2286 (10-Bit) 64-Pin (9mm × 9mm) QFN Package

Single Switch Synchronous Forward Controller Features: Synchronous Rectifier Control for High Efficiency Programmable Volt-Second Clamp Output Power Levels from 25W to 500W Low Current Start-Up (LT1952: 460µA; VIN On/Off = 14.25V/8.75V) (LT1952-1: 400µA; VIN On/Off = 7.75V/6.5V) True PWM Soft-Start Low Stress Short Circuit Protection Precision 107mV Current Limit Threshold Adjustable Delay for Synchronous Timing Accurate Shutdown Threshold with Programmable Hysteresis Programmable Slope Compensation Programmable Leading Edge Blanking Programmable Frequency (100kHz to 500kHz) Synchronizable to an External Clock up to 1.5 • fOSC Internal 1.23V Reference 2.5V External Reference Current Mode Control Small 16-Pin SSOP Package

1.5GHz - 2.4GHz High Linearity Direct Quadrature Modulator Features: High Input Impedance Version of the LT5528 Direct Conversion to 1.5GHz - 2.4GHz High OIP3: 22.8dBm at 2GHz Low Output Noise Floor at 20MHz Offset: No RF: -158.2dBm/Hz POUT = 4dBm: -152.5dBm/Hz 4-Ch W-CDMA ACPR: -64dBc at 2.14GHz Integrated LO Buffer and LO Quadrature Phase Generator 50Ω AC-Coupled Single-Ended LO and RF Ports Low Carrier Leakage: -49dBm at 2GHz High Image Rejection: 40dB at 2GHz 16-Lead QFN 4mm × 4mm Package

14-Bit, 130Msps ADC Features: Sample Rate: 130Msps 77.1dBFS Noise Floor 98dB SFDR SFDR >81dB at 250MHz (1.5VP-P Input Range) PGA Front End (2.25VP-P or 1.5VP-P Input Range) 700MHz Full Power Bandwidth S/H Optional Internal Dither Optional Data Output Randomizer LVDS or CMOS Outputs Single 3.3V Supply Power Dissipation: 1.32W Clock Duty Cycle Stabilizer Pin Compatible 16-Bit Version 130Msps: LTC2208 (16-Bit) 64-Pin (9mm × 9mm) QFN Package

16-Bit, 105Msps Low Noise ADC Features: Sample Rate: 105Msps 81.3dBFS Noise Floor 100dB SFDR SFDR > 90dB at 70MHz 85fsRMS Jitter 2.75VP-P Input Range 400MHz Full Power Bandwidth S/H Optional Internal Dither Optional Data Output Randomizer LVDS or CMOS Outputs Single 3.3V Supply Power Dissipation: 1.19W Clock Duty Cycle Stabilizer Pin Compatible with LTC2208 64-Pin (9mm × 9mm) QFN Package

Micropower, Regulated Charge Pump in 2 x 2 DFN Features: Ultralow Power: 8μA Quiescent Current Regulated Output Voltages: 3.3V ±4%, 5V ±4%, ADJ VIN Range: 1.8V to 4.4V (LTC3221-3.3) 2.7V to 5.5V (LTC3221-5) Output Current: Up to 60mA No Inductors Needed Very Low Shutdown Current: <1μA Shutdown Disconnects Load from VIN Burst Mode Control Short-Circuit Protected Solution Profi le < 1mm Tiny 2mm × 2mm 6-Pin DFN Package

60V Low IQ, Dual, 2-Phase Synchronous Step-Down DC/DC Controller Features: Wide VIN Range: 4.5V to 60V (65V Abs Max) Wide Output Voltage Range: 0.8V ≤ VOUT ≤ 99% • VIN Adjustable Gate Drive Level 5V to 10V (OPTI-DRIVE) No External Bootstrap Diodes Required Low Operating IQ: 29μA (One Channel On) Selectable Gate Drive UVLO Thresholds Out-of-Phase Operation Reduces Required Input Capacitance and Power Supply Induced Noise Phase-Lockable Frequency: 75kHz to 850kHz Selectable Continuous, Pulse Skipping or Low Ripple Burst Mode® Operation at Light Loads Selectable Current Limit (LTC3892/LTC3892-2) Very Low Dropout Operation: 99% Duty Cycle Power Good Output Voltage Monitors (LTC3892/LTC3892-2) Low Shutdown IQ: 3.6μA Small 32-Lead 5mm × 5mm QFN Package (LTC3892/LTC3892-2) or TSSOP Package (LTC3892-1)
