LP2980IM5-3.0

Texas Instruments LP2980IM5-3.0

LP2981-28DBVR

Texas Instruments LP2981-28DBVR

LP2981-30DBVT

Texas Instruments LP2981-30DBVT

LP2981AIM5-3.0/NOPB

Texas Instruments LP2981AIM5-3.0/NOPB

ISO1540DR

Texas Instruments ISO1540DR

ISO7740FDWR

Texas Instruments ISO7740FDWR

ISO7820DWW

Texas Instruments ISO7820DWW

ISO7820FDWW

Texas Instruments ISO7820FDWW

LM1875T/NOPB

Texas Instruments LM1875T/NOPB

LM2575N-5.0/NOPB

Texas Instruments LM2575N-5.0/NOPB

Price $0.56 $0.65 $3.45 $6.28 $2.51
RoHS No Yes Compliant Compliant Compliant Compliant Yes Compliant Compliant Compliant
Lead Status No Yes No No No No Yes No No Yes
Accuracy(%) 2.5 2.5 2.5
Iout(Max)(A) 0.05 0.1 0.1 0.1 1
Vin(Min)(V) 2.1 2.2 2.2 2.7 4
Approx. Price (US$) 0.22 | 1ku 0.19 | 1ku 0.19 | 1ku 0.34 | 1ku 2.00 | 1ku 2.98 | 1ku 2.10 | 1ku 2.10 | 1ku 1.36 | 1ku 1.15 | 1ku
Package Size mm2 mm2 mm2 mm2 mm2 mm2 mm2 mm2 mm2
Vdo(Typ)(mV) 120 200 200 200
Vin(Max)(V) 16 16 16 16 40
Package Group SOT-23 SOT-23 SOT-23 SOT-23 SOIC SOIC SOIC SOIC TO-220 PDIP,DDPAK/TO-263,SOIC,TO-220
Rating Catalog Catalog Catalog Catalog Catalog Catalog Catalog Catalog Catalog
PSRR @ 100KHz(dB) 45 29 29
Fixed Output Options(V) 2.5,3,3.3,3.8,4.7,5 2.8 3 2.5,3,3.3,3.6,5
Vout(Min)(V) 2.5 2.8 3 2.5 3.3
Operating Temperature Range(C) -40 to 125 -40 to 125 -40 to 125 -40 to 125 -40 to 125 -55 to 125 -55 to 125 -55 to 125 0 to 70 -40 to 125
Output Options Fixed Output Fixed Output Fixed Output Fixed Output
Regulated Outputs(#) 1 1 1 1 1
Iq(Typ)(mA) 0.065 0.065 0.065 0.065 10
Vout(Max)(V) 5 2.8 3 5 37
Special Features Enable N/A N/A Enable Enable
Noise(uVrms) 160 160 160
Output Capacitor Type Ceramic Ceramic,Non-Ceramic Ceramic,Non-Ceramic Non-Ceramic
CSA 61010-1 Basic Working(Vrms) 300
DIN V VDE V 0884-10 Transient Overvoltage Rating(Vpk) 4242 7071 8000 8000
CSA 60950-1 Basic Working(Vrms) 390
VCC(Min)(V) 3 2.25 2.25 2.25
DIN V VDE V 0884-10 Working Voltage(Vpk) 566 1414 2121 2121
CSA 61010-1 Reinforced Working(Vrms) 150
Datarate(Mbps) 1
Serial Data Bi-directional
Serial Clock Bi-directional
CSA Isolation Rating(Vrms) 2800
Number of Channels(#) 2 4 2 2
VCC(Max)(V) 5.5 5.5 5.5 5.5
DIN V VDE V 0884-10 Surge Voltage Rating(Vpk) 4000 6000 8000 8000
UL 1577 Isolation Voltage (Single)(Vrms) 2500 5000 5700 5700
Default Output Low High Low
Speed(Max)(Mbps) 100 100 100
Propagation Delay(Typ)(ns) 11 10.7 10.7
Forward/Reverse Channels 4/0 2/0 2/0
TTL/CMOS Input Threshold TTL CMOS CMOS
Propagation Delay(ns) 11 10.7 10.7
Closed/Open Loop Open
Power Stage Supply(Min)(V) 16
Analog Supply (V)(Max) 60
Control Interface Hardware
Analog Supply (V)(Min) 16
Power Stage Supply(Max)(V) 60
Speaker Channels(Max) 1
Switching Frequency(Min)(kHz) 42
Duty Cycle(Max)(%) 98
Type Converter
Control Mode Voltage Mode
Switching Frequency(Max)(kHz) 63
