Analog to Digital Converters - ADC 20-Bit, 40 MSPS SAR ADC

Analog Devices Inc. AD4080 Differential SAR ADCs

Features:

• High performance

  • Throughput of 40MSPS, 46.25ns conversion latency
  • INL of ±4ppm (typical), ±8ppm (maximum)
  • SNR/THD

    • 93.6dB (typical)/-110dB (typical) at fIN = 1kHz
    • 93.5dB (typical)/-104dB (typical) at fIN = 1MHz
  • Noise spectral density at -167.6dBFS/Hz
  • 20-bit resolution, no missing codes
• Low power

  • 79.3mW typical at 40MSPS with -0.5dBFS sine-wave input
• Easy Drive, fully differential Input

  • 6Vp-p differential input range
  • Continuous signal acquisition
  • Linearized, 5μA/MSPS input current
• Integrated, low-drift reference buffer and decoupling
• Integrated VCM generation
• Digital features and data interface

  • Conversion result FIFO, 16K sample depth
  • Digital averaging filter with up to 210 decimation
• SPI configuration
• Configurable data interface

  • Single lane, DDR, serial LVDS, 800MBPS per lane
  • Dual lane, DDR, serial LVDS, 400MBPS per lane
  • Single/quad lane SPI data interface
• Package

  • 49-ball, 5mm x 5mm CSP_BGA, 0.65mm pitch
  • Integrated supply decoupling capacitors
• Operating temperature range of -40°C to +85°C

Applications:

• Digital imaging
• Cell analysis
• Spectroscopy
• Automated test equipment
• High speed data acquisition
• Digital control loops, hardware in the loop
• Power quality analysis
• Source measurement units
• Electron and x-ray microscopy
• Radar level measurement
• Nondestructive test
• Predictive maintenance and structural health

Power Management IC Development Tools LTC4121EUD Demo Board - 400mA Synchronou

The AD22100 is a monolithic temperature sensor with on-chip signal conditioning. It can be operated over the temperature range -50°C to +150°C, making it ideal for use in numerous HVAC, instrumentation and automotive applications.The signal conditioning eliminates the need for any trimming, buffering or linearization circuitry, greatly simplifying the system design and reducing the overall system cost.The output voltage is proportional to the temperature times the supply voltage (ratiometric). The output swings from 0.25 V at -50°C to +4.75 V at +150°C using a single +5.0 V supply.Due to its ratiometric nature, the AD22100 offers a cost effective solution when interfacing to an analog-to-digital converter. This is accomplished by using the ADC's +5 V power supply as a reference to both the ADC and the AD22100 (See Figure 2 of the datasheet), eliminating the need for and cost of a precision reference to both the ADC and the AD22100 eliminating the need for and cost of a precision reference (see Figure 2).APPLICATIONS HVAC systems System temperature compensation Board level temperature sensing Electronic thermostatsMARKETS Industrial process control Instrumentation Automotive

RF Amplifier IC WiMAX / WiBro 2.3GHz ~ 2.7GHz 16-QFN (3x3)

RF Mixer IC Radar Up Converter 8.5GHz ~ 13.5GHz 24-QFN (4x4)

The AD5308 / AD5318 / AD5328 are octal 8-, 10-, and 12-bit buffered voltage output DACs in a 16-lead TSSOP. They operate from a single 2.5 V to 5.5 V supply, consuming 0.7 mA typical at 3 V. Their on-chipoutput amplifiers allow the outputs to swing rail-to-rail with a slew rate of 0.7 V/μs. The AD5308 / AD5318 / AD5328 use a versatile 3-wire serial interface that operates at clock rates up to 30 MHz and is compatible with standard SPI, QSPI, MICROWIRE, and DSP interface standards.The references for the eight DACs are derived from two reference pins (one per DAC quad). These reference inputs can be configured as buffered, unbuffered, or VDD inputs. The parts incorporate a power-on reset circuit, which ensures that the DAC outputs power up to 0 V and remain there until a valid write to the device takes place. The outputs of all DACs may be updated simultaneously using the asynchronous LDAC input. The parts contain a power-down feature that reduces the current consumption of the devices to 400 nA at 5 V (120 nA at 3 V). The eight channels of the DAC may be powered down individually.All three parts are offered in the same pinout, which allows users to select the resolution appropriate for their application without redesigning their circuit board.APPLICATIONS Portable battery-powered instruments Digital gain and offset adjustment Programmable voltage and current sources Optical networking Automatic test equipment Mobile communications Programmable attenuators Industrial process control

Delay Lines/Timing Elements Broadband Analog Time Delay to 24 GHz

The SSM2135 dual audio operational amplifier permits excel-lent performance in portable or low power audio systems, with an operating supply range of 4 V to 36 V or ±2 V to ±18 V. The unity-gain stable device has very low voltage noise of 5.2 nV/√Hz, and total harmonic distortion plus noise below 0.01% over normal signal levels and loads. Such characteristics are enhanced by wide output swing and load drive capability. A unique output stage1 permits output swing approaching the rail under moderate load conditions. Under severe loading, the SSM2135 still maintains a wide output swing with ultralow distortion. Particularly well suited for computer audio systems and portable digital audio units, the SSM2135 can perform preamplification, headphone and speaker driving, and balanced line driving and receiving. Additionally, the device is ideal for input signal conditioning in single-supply, Σ-Δ, analog-to-digital converter subsystems such as the AD1877. The SSM2135 makes an ideal single-supply stereo output amplifier for audio digital-to-analog converters (DACs) because of its low noise and distortion.The SSM2135 is available in an 8-lead plastic SOIC package and is guaranteed for operation over the extended industrial temperature range of −40°C to +85°C.

Clock & Timer Development Tools LTC6995-2 Demo Board - 1sec Power-on Res

RF Amplifier GaAs HEMT WBand lo Noise amp, 18-40 GHz
