Texas Instruments
DLP780NEA0FYU
|
Texas Instruments
BQ296234DSGR
|
Texas Instruments
LMG3425R030RQZT
|
Texas Instruments
LP875230CRNFRQ1
|
Texas Instruments
TPS7A0218DBVR
|
Texas Instruments
TPS62824DMQR
|
Texas Instruments
TPS7B8601QKVURQ1
|
Texas Instruments
TMP126NDCKR
|
Texas Instruments
TPSM63603SRDHR
|
Texas Instruments
TPS7A1409PYBKR
|
| Price |
|
|
|
|
|
|
|
|
|
|
|
| RoHS |
|
Y |
Y |
Not Compliant |
Not Compliant |
Y |
Y |
Y |
Y |
Not Compliant |
Y |
| Lead Status |
|
Y |
Y |
Y |
Y |
Y |
Y |
Y |
Y |
Y |
Y |
| Array diagonal(in) |
|
0.78 |
|
|
|
|
|
|
|
|
|
| Chipset family |
|
DLPA300,DLPC4430 |
|
|
|
|
|
|
|
|
|
| Component type |
|
DMD |
|
|
|
|
|
|
|
|
|
| Display resolution(max) |
|
1080p (1920x1080) |
|
|
|
|
|
|
|
|
|
| Input frame rate(max)(Hz) |
|
120 |
|
|
|
|
|
|
|
|
|
| Micromirror array size |
|
1920x1080 |
|
|
|
|
|
|
|
|
|
| Micromirror pitch(mm) |
|
0.009 |
|
|
|
|
|
|
|
|
|
| Operating temperature range(C) |
|
0 |
-40 |
-40 to 150 |
-40 |
-40 |
-40 |
-40 |
-55 |
-40 |
-40 |
| Package area(mm^2) |
|
1127 |
4 |
|
18 |
8.12 |
2.25 |
66.726 |
4.2 |
24 |
0.8236 |
| Package size (L x W)(mm) |
|
35 x 32.2 |
2 x 2 |
|
4.5 x 4 |
2.9 x 2.8 |
1.5 x 1.5 |
6.6 x 10.11 |
2 x 2.1 |
6 x 4 |
1.16 x 0.71 |
| Package type |
|
DLP-S600 |
WSON |
|
VQFN-HR |
SOT-23 |
VSON-HR |
TO-252 |
SOT-SC70 |
B0QFN |
DSBGA |
| Pin count |
|
350 |
8 |
|
26 |
5.0 |
6 |
5 |
6 |
30 |
6 |
| Rating |
|
Catalog |
Catalog |
Catalog |
Automotive |
Catalog |
Catalog |
Automotive |
Catalog |
Catalog |
Catalog |
| System brightness(max)(lm) |
|
7000 |
|
|
|
|
|
|
|
|
|
| TI.com inventory |
|
21 |
26343 |
0 |
6162 |
532375 |
937950 |
9257 |
139077 |
3499 |
61197 |
| Approx. price(US$) |
|
210 | 1ku |
.091 | 1ku |
9.87 | 1ku |
2.139 | 1ku |
.212 | 1ku |
.3 | 1ku |
.885 | 1ku |
.489 | 1ku |
3.65 | 1ku |
.315 | 1ku |
| Battery overvoltage protection(max)(V) |
|
|
4.6 |
|
|
|
|
|
|
|
|
| Battery overvoltage protection(min)(V) |
|
|
3.85 |
|
|
|
|
|
|
|
|
| Features |
|
|
LDO output,Overvoltage,Single pin output drive,Undervoltage |
Cycle-by-cycle overcurrent protection,Latched overcurrent protection,PWM temperature reporting,Overtemperature protection,Ideal diode mode,Bottom-side cooled |
Diagnostics,Dynamic voltage scaling,Enable,Enable pin,I2C control,Overcurrent protection,Power good,Power sequencing,Power supply and system monitoring,Spread-Spectrum Clock (SSC) Generation,Thermal shutdown,UVLO fixed |
Enable,Output discharge |
Enable,Light load efficiency,Output discharge,Over Current Protection,Power good,Pre-Bias Start-Up,Soft Start Fixed,Synchronous Rectification,UVLO fixed |
Enable |
ALERT,CRC,NIST traceable,One-shot conversion,Slew Rate Warning |
EMI Tested,Enable,Frequency synchronization,Overcurrent protection,Power good,Spread Spectrum |
Enable,Output discharge |
| Function |
|
|
Protection |
|
|
|
|
|
|
|
|
| Number of series cells(max) |
|
|
3,4 |
|
|
|
|
|
|
|
|
| Number of series cells(min) |
|
|
2,3,4 |
|
|
|
|
|
|
|
|
| Operating current(typ)(A) |
|
|
1 |
|
|
|
|
|
|
|
|
| Overvoltage protection |
|
|
4.6 |
|
|
|
|
|
|
|
|
| TI functional safety category |
|
|
|
|
|
|
|
|
|
|
|
| Vin(max)(V) |
|
|
20 |
|
5.5 |
6 |
5.5 |
40 |
|
36 |
2.2 |
| RDS (on)(Milliohm) |
|
|
|
30 |
|
|
|
|
|
|
|
| ID(Max)(A) |
|
|
|
55 |
|
|
|
|
|
|
|
| Package Group |
|
|
|
VQFN|54 |
|
|
|
|
|
|
|
| VDS(Max)(V) |
|
|
|
600 |
|
|
|
|
|
|
|
| Package size |
|
|
|
mm2 |
|
|
|
|
|
|
|
| Configurability |
|
|
|
|
Factory programmable,Software configurable |
|
|
|
|
|
|
| Iout(max)(A) |
|
|
|
|
2 |
0.2 |
1 |
0.5 |
|
3 |
1 |
| Iq(typ)(mA) |
|
|
|
|
0.0067 |
0.000025 |
0.004 |
0.02 |
|
0.009 |
0.0056 |
| LDO |
|
|
|
|
0 |
|
|
|
|
|
|
| Pitch(mm) |
|
|
|
|
0.5 |
|
|
|
|
|
|
| Processor name |
|
|
|
|
Generic |
|
|
|
|
|
|
| Processor supplier |
|
|
|
|
Generic |
|
|
|
|
|
|
| Product type |
|
|
|
|
Processor and FPGA |
|
|
|
|
|
|
| Regulated outputs(#) |
|
|
|
|
3 |
1 |
1 |
1 |
|
1 |
1 |
| Shutdown current (ISD)(typ)(A) |
|
|
|
|
1.4 |
|
|
|
|
|
|
| Step-down DC/DC controller |
|
|
|
|
0 |
|
|
|
|
|
|
| Step-down DC/DC converter |
|
|
|
|
4 |
|
|
|
|
|
|
| Step-up DC/DC controller |
|
|
|
|
0 |
|
|
|
|
|
|
| Step-up DC/DC converter |
|
|
|
|
0 |
|
|
|
|
|
|
| Switching frequency(max)(kHz) |
|
|
|
|
2200 |
|
2200 |
|
|
2200 |
|
| Switching frequency(typ)(kHz) |
|
|
|
|
2000 |
|
|
|
|
|
|
| Vin(min)(V) |
|
|
|
|
2.8 |
1.5 |
2.4 |
3 |
|
3 |
0.7 |
| Vout(max)(V) |
|
|
|
|
3.36 |
5 |
4 |
18 |
|
16 |
2 |
| Vout(min)(V) |
|
|
|
|
0.6 |
0.8 |
0.6 |
1.2 |
|
1 |
0.5 |
| Accuracy(%) |
|
|
|
|
|
1.5 |
|
0.85 |
|
|
1 |
| Dropout voltage (Vdo)(typ)(mV) |
|
|
|
|
|
205 |
|
370 |
|
|
70 |
| Fixed output options(V) |
|
|
|
|
|
1.8 |
|
3.3,5 |
|
|
0.8,0.85,0.9,1,1.05,1.2,1.3,1.8 |
| Load capacitance(min)(F) |
|
|
|
|
|
1 |
|
2.2 |
|
|
1.5 |
| Maximum package height(mm) |
|
|
|
|
|
1.45 |
1 |
2.52 |
|
1.9 |
0.33 |
| Noise(Vrms) |
|
|
|
|
|
130 |
|
280 |
|
|
7.2 |
| Output options |
|
|
|
|
|
Fixed Output |
|
Adjustable Output |
|
|
Fixed Output |
| PSRR at 100 KHz(dB) |
|
|
|
|
|
35 |
|
65 |
|
|
43 |
| Thermal resistance JA(C/W) |
|
|
|
|
|
179.1 |
|
29.7 |
|
|
136.7 |
| Control mode |
|
|
|
|
|
|
DCS-Control |
|
|
current mode |
|
| Duty cycle(max)(%) |
|
|
|
|
|
|
100 |
|
|
98 |
|
| Switching frequency(min)(kHz) |
|
|
|
|
|
|
2200 |
|
|
200 |
|
| Type |
|
|
|
|
|
|
Converter |
|
Local |
Module |
|
| Addresses |
|
|
|
|
|
|
|
|
1 |
|
|
| Interface type |
|
|
|
|
|
|
|
|
SPI |
|
|
| Local sensor accuracy(max) |
|
|
|
|
|
|
|
|
0.8 |
|
|
| Remote channels(#) |
|
|
|
|
|
|
|
|
0 |
|
|
| Supply current(max)(A) |
|
|
|
|
|
|
|
|
1.2 |
|
|
| Supply voltage(max)(V) |
|
|
|
|
|
|
|
|
5.5 |
|
|
| Supply voltage(min)(V) |
|
|
|
|
|
|
|
|
1.62 |
|
|
| Temp resolution(max)(Bits) |
|
|
|
|
|
|
|
|
14 |
|
|
| EMI features |
|
|
|
|
|
|
|
|
|
Integrated capacitors,Low parasitic Hotrod packaging,Spread Spectrum |
|
| Soft start |
|
|
|
|
|
|
|
|
|
Fixed |
|
| Topology |
|
|
|
|
|
|
|
|
|
Buck,Inverting Buck-Boost,Synchronous Buck |
|
