60V, 1.5A LED Driver with Internal Exponential Scale Dimming Features: Operates in Boost, SEPIC, Buck Mode and Buck-Boost Mode 128:1 Internal Exponential Scale PWM Dimming Wide Input Voltage Range (3V to 60V) 1.5A, 60V Internal Switch 20000:1 External PWM Dimming at 100Hz ±2% LED Current and Output Voltage Regulation PMOS Switch Driver for PWM Dimming LED Short/Open Protection and Indication Constant Voltage and Constant Current Regulation Adjustable 300kHz to 2MHz Switching Frequency Adjustable 100Hz to 1kHz PWM Generator Frequency Internal Spread Spectrum Frequency Modulation Easy Synchronization to External Clock Programmable VIN UVLO with Hysteresis Available in 16-Lead MSOP Package

Micropower Quad 10-Bit DAC Features: Tiny: 4 DACs in the Board Space of an SO-8 Micropower: 59µA per DAC Plus 1µA Sleep Mode for Extended Battery Life Wide 2.7V to 5.5V Supply Range Rail-to-Rail Voltage Outputs Drive 1000pF Reference Range Includes Supply for Ratiometric 0V to VCC Output Reference Input Impedance is Code-Independent —Eliminates External Reference Buffer Individually Addressable DACs Differential Nonlinearity: ≤ ±0.75LSB Max Pin-Compatible Octal Version Available (LTC1660)

Single Channel Transimpedance Amplifier with Output Multiplexing Features: 220MHz –3dB Bandwidth with 2pF Input Capacitance Single-Ended Output 74kΩ Transimpedance Gain 4.8pA/√Hz Input Current Noise Density at 200MHz (2pF) 64nARMS Integrated Input Current Noise Over 200MHz (2pF) Linear Input Range 0µA to 30µA Overload Current > ±400mA Peak Fast Overload Recovery: 1mA in 10ns Fast Output MUXing: <50ns Single 5V Supply 90mW Power Dissipation 2VP-P Output Swing on 100Ω Load 3mm × 3mm, 16-Lead QFN Package Output MUX Combines Multiple LTC6560 Devices AEC-Q100 Qualified for Automotive Applications

Low IQ Boost/SEPIC/Inverting Converter with 1.5A, 150V Switch Features: Wide Input Voltage Range: 2.8V to 60V Ultralow Quiescent Current and Low Ripple Burst Mode® Operation: IQ = 9µA 1.5A, 150V Power Switch Positive or Negative Output Voltage Programming with a Single Feedback Pin Programmable Frequency (100kHz to 500kHz) Synchronizable to an External Clock Spread Spectrum Frequency Modulation for Low EMI BIAS Pin for Higher Efficiency Programmable Undervoltage Lockout (UVLO) Thermally Enhanced 16-lead MSOP Package AEC-Q100 Qualified for Automotive Applications

15V, 2.5A Synchronous Buck-Boost DC/DC Converter Features:Regulated Output with VIN Above, Below or Equal to VOUT2.7V to 15V Input Voltage Range2.5V to 14V Output Voltage Range2.5A Continuous Output Current: VIN ≥ 5V, VOUT = 5V, PWM ModeOutput Current MonitorUp to 95% Efficiency750kHz Switching Frequency, Synchronizable Between 300kHz and 1.5MHzInternal N-Channel MOSFETsSelectable Burst Mode® Operation, IQ = 50μAShutdown Current < 1μAOvervoltage ProtectionOutput Disconnect in ShutdownInternal Soft-StartSmall, Thermally Enhanced 16-Lead (4mm × 5mm × 0.75mm) DFN and 20-Lead TSSOP Package

16-Channel 50mA LED Driver with Buck Controller Features: 6V to 55V Power Input Voltage Range 16 Independent LED Outputs Up to 75mA/36V ±3% LED Current Matching at 50mA (Typ ±1%) 6-Bit Dot Correction Current Adjustment 12-Bit Grayscale PWM Dimming 0.5μs Minimum LED On-Time Adaptive LED Bus Voltage for High Efficiency Cascadable 30MHz Serial Data Interface Full Diagnostic and Protection: Individual Open/Short LED and Overtemperature Fault 40-Lead 6mm × 6mm QFN Package

Dual Ideal Diode and Single Hot Swap Controller Features: Power Path and Inrush Current Control for Redundant Supplies Low Loss Replacement for Power Schottky Diodes Allows Safe Hot Swapping from a Live Backplane 2.9V to 18V Operating Range Controls N-Channel MOSFETs Limits Peak Fault Current in ≤1μs 0.5μs Ideal Diode Turn-On and Reverse Turn-Off Time Adjustable Current Limit with Circuit Breaker Smooth Switchover without Oscillation Adjustable Current Limit Fault Delay Fault and Power Status Output 20-Lead 4mm × 5mm QFN and 16-Lead SSOP Packages

Programmable Hex Voltage Supervisor with EEPROM Features: Supervises 6 Power Supplies I2C Adjustable UV and OV Trip Points Guaranteed Threshold Accuracy: ±1% I2C/SMBus Interface Internal EEPROM 256 Programmable Thresholds per Channel Up to Three Range Settings per Channel Two General Purpose Inputs Three General Purpose Inputs/Outputs Programmable Output Delays Supply Voltage Range, 3.4V to 13.9V Supply Voltage Power Sharing from V1 to V4 16-Lead 5mm × 4mm DFN and SSOP Packages

20V High Efficiency Nanopower Step-Down Regulator Features: 720nA Input IQ in Regulation (No Load), VIN = 4V 820nA Input IQ in Regulation (No Load), VIN = 20V 400nA Input IQ in UVLO 2.7V to 20V Input Operating Range Up to 50mA of Output Current Pin Selectable Output Voltages: 1.2V, 1.5V, 1.8V, 2.5V (LTC3388-1) 2.8V, 3.0V, 3.3V, 5.0V (LTC3388-3) High Efficiency Hysteretic Synchronous DC/DC Conversion Standby Mode Disables Buck Switching Available in 10-Lead MSE and 3mm × 3mm DFN Packages

J-FET Amplifier 2 Circuit 8-SO
