CONTROLLER TEMP VOLT; Thermocouple Type:B E J K L N R S T W PLII; Operating Temperature Max:55°C; Operating Temperature Min:-10°C; Temperature Accuracy ±:-; Output Voltage Max:10VDC; Output Voltage Min:0VDC; Product Range:-; Accuracy:0.1%; Approval Bodies:CE; Approval Category:UL Recognised; Colour:Black; External Depth:91mm; External Length / Height:48mm; External Width:48mm; Input:Thermocouple PRT Current or Voltage; No. of Inputs:2; No. of Outputs:3Outputs; Output:2 x Auxiliary; Output Type:Linear Voltage; Power Consumption:8.5VA; Storage Temperature Max:65°C; Storage Temperature Min:-25°C; Supply Voltage Max:240VAC; Supply Voltage Min:100VAC

OUTPUT UNIT 0-20MA OUTPUT; Current Rating:20mA; Product Range:-; Accessory Type:Output Unit - Linear 0-20 mA; For Use With:E5EN-H and E5AN-H Controllers; No. of Analogue Outputs:1

PSU DIN RAIL 50W 5V; No. of Outputs:1 Output; Output Power Max:50W; Output Voltage - Output 1:5VDC; Output Current - Output 1:10A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:85VAC; Input Voltage AC Max:264VAC; Power Supply Output Type:Fixed; Product Range:-; Approval Bodies:CSA EN UL; Approvals / Standards:EN 50178; Efficiency:80%; External Depth:124.5mm; External Length / Height:84.5mm; External Width:35.1mm; Frequency Max:60Hz; Frequency Min:50Hz; Height:84.5mm; Hold Up Time:20ms; Input Frequency:63Hz; Length:124.5mm; No. of Outputs:1Outputs; Operating Temperature Max:70°C; Operating Temperature Min:-10°C; Output Current:10A; Output Ripple and Noise Voltage pk-pk:3.20%; Output Voltage:5V; Power Rating:50W; Power Supply Type:Switch Mode; Supply Voltage:264V; Supply Voltage Max:240V; Supply Voltage Min:100V; Supply Voltage Typ:110V AC 230V AC

PSU DIN RAIL 240W 24V 3 PHASE; Power Supply Output Type:Fixed; No. of Outputs:1 Output; Input Voltage AC Min:400VAC; Input Voltage AC Max:500VAC; Output Power Max:240W; Output Voltage - Output 1:24VDC; Output Voltage - Output 2:-; Output Current - Output 1:10A; Output Current - Output 2:-; Product Range:-; Output Voltage - Output 3:-; Output Voltage - Output 4:-; Output Current - Output 3:-; Current Output 4:-; Approval Bodies:CSA UL; Approvals / Standards:EN 50178 EN 60204 UL 508; Efficiency:90%; External Depth:130mm; External Length / Height:170mm; External Width:45mm; Frequency Max:60Hz; Frequency Min:50Hz; Height:170mm; Hold Up Time:15ms; Input Current:1A; Input Frequency:60Hz; Input Voltage:500VAC; Length:130mm; No. of Outputs:1Outputs; Operating Temperature Max:70°C; Operating Temperature Min:-10°C; Output Current:10A; Output Ripple Voltage pk-pk:100mV; Output Voltage:24V; Power Rating:240W; Power Supply Type:Switch Mode; Storage Temperature Max:85°C; Storage Temperature Min:-45°C

PHOTOSWITCH THRU-BEAM; Sensor Output:NPN; Sensing Range Max:5mm; Supply Voltage DC Min:5V; Supply Voltage DC Max:24V; Output Current:100mA; Product Range:EE-SX67 Series; Current Consumption:35mA; External Depth:14.5mm; External Length / Height:15.5mm; External Width:26.2mm; Fixing Centres:19mm; Frequency Response Max:1kHz; IP / NEMA Rating:IP50; Lead Spacing:2.54mm; Material:Polybutylene phthalate (PBT); Operating Frequency:3kHz; Operating Temperature Max:55°C; Operating Temperature Min:-25°C; Output Current Max:100mA; Sensing Distance Max:5mm; Sensing Range:0mm to 5mm; Sensor Input:Optical; Slot Width:5mm; Supply Voltage Range DC:5V to 24V

INDUCTIVE PROXIMITY SENSOR; Sensing Range Max:8mm; Thread Size - Metric:M12; Sensor Output:SPST-NO; Supply Voltage DC Min:10V; Supply Voltage DC Max:30V; Product Range:-; Sensor Input:Inductive

COUPLING SHAFT FOR E6C SERIES 6H8; Rotational Speed Max:-; Bore Diameter Min:-; Torque:0.8N-m; Product Range:-; External Diameter:15mm

PROXIMITY SENSOR M18 PREWIRED NPN; Sensing Range Max:8mm; Thread Size - Metric:M18; Sensor Output:NPN; Supply Voltage DC Min:10V; Supply Voltage DC Max:32V; Product Range:-; Frequency Response Max:500Hz; Sensing Range:0mm to 8mm; Sensor Input:Inductive; Supply Voltage Range DC:10V to 32V

LEAD FIBRE OPTIC SEPARATE; Sensing Range Max:950mm; Fibre Optic Sensor Type:General Purpose; Product Range:E32 Series; Cable Assembly Type:Sensor; Cable Length:2m; External Diameter:2.2mm; Fibre Diameter:1mm; Fibre Type:Plastic Optical; Lead Length:2m; No. of Fibres:1Fibres; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Sensing Distance Max:270mm; Thread Size:M4 x 0.7

RELAY DPDT 250VAC 30VDC 10A; Contact Configuration:DPDT; Coil Voltage:24VAC; Contact Current:10A; Product Range:-; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30VDC; Contact Material:Silver Tin Indium; Coil Resistance:48.4ohm; Approvals & Standards:-; AC Coil Power:2.7VA; Coil Current:110mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:24V; Contact Current AC Max:10A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:30V; Contact Voltage DC Nom:30V; Dielectric Strength VDC:2500V; External Depth:34.5mm; External Height:52.5mm; External Length / Height:52.5mm; External Width:34.5mm; Nom Operating Power:2.7VA; Operating Temperature Max:60°C; Operating Temperature Min:-40°C; Operating Time:20ms; Relay Type:Power; Release Time:20ms
