MKS2PIDC24
Omron Automation and Safety
RELAY DPDT 250VAC 30VDC 10A; Contact Configuration:DPDT; Coil Voltage:24VDC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30VDC; Contact Material:Silver Tin Indium; Coil Resistance:430ohm; Approvals & Standards:-; Coil Current:55.8mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VDC Nom:24V; Contact Current AC Max:10A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:250V; Contact Voltage DC Nom:30V; Dielectric Strength VDC:2500V; External Depth:34.5mm; External Height:52.5mm; External Length / Height:52.5mm; External Width:34.5mm; Nom Operating Power:1.4W; Operating Temperature Max:60°C; Operating Temperature Min:-40°C; Relay Type:Power
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | MKS2PIDC24 | 42 | 1 | $18.84 | $16.78 | $15.47 | $14.94 | $13.78 | $13.78 |
| element14 APAC | MKS2PIDC24 | 4 | 1 | * $10.30 | * $10.30 | * $9.89 | * $9.89 | * $9.89 | * $9.89 |
| Farnell | MKS2PIDC24 | 4 | 1 | * $9.16 | * $8.49 | * $8.32 | * $8.32 | * $8.32 | * $8.32 |
MKS3PI5AC24
Omron Automation and Safety
RELAY 3PDT 250VAC 30VDC 10A; Contact Configuration:3PDT; Coil Voltage:24VAC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30VDC; Contact Material:Silver Tin Indium; Coil Resistance:62ohm; Approvals & Standards:-; Coil Current:110mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:24V; Contact Current AC Max:10A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:250V; Contact Voltage DC Nom:30V; Dielectric Strength VDC:2500V; External Depth:34.5mm; External Height:52.5mm; External Length / Height:52.5mm; External Width:34.5mm; Nom Operating Power:2.7VA; Operating Temperature Max:60°C; Operating Temperature Min:-40°C; Relay Type:Power
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | MKS3PI5AC24 | 2 | 1 | $20.87 | $18.59 | $17.14 | $16.55 | $14.82 | $14.82 |
| element14 APAC | MKS3PI5AC24 | 7 | 1 | * $22.03 | * $18.06 | * $17.14 | * $17.14 | * $17.14 | * $17.14 |
| Farnell | MKS3PI5AC24 | 7 | 1 | * $15.13 | * $14.27 | * $13.50 | * $13.50 | * $13.50 | * $13.50 |
MKS3PI5AC230
Omron Automation and Safety
RELAY 3PDT 250VAC 30VDC 10A; Contact Configuration:3PDT; Coil Voltage:230VAC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30VDC; Contact Material:Silver Tin Indium; Coil Resistance:6.17kohm; Approvals & Standards:-; Coil Current:11.5mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:230V; Contact Current AC Max:10A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:250V; Contact Voltage DC Nom:30V; Dielectric Strength VDC:2500V; External Depth:34.5mm; External Height:52.5mm; External Length / Height:52.5mm; External Width:34.5mm; Nom Operating Power:2.7VA; Operating Temperature Max:60°C; Operating Temperature Min:-40°C; Relay Type:Power
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | MKS3PI5AC230 | 0 | 1 | $26.32 | $26.32 | $26.32 | $26.32 | $26.32 | $26.32 |
| element14 APAC | MKS3PI5AC230 | 18 | 1 | * $14.30 | * $14.30 | * $14.06 | * $14.06 | * $14.06 | * $14.06 |
| Farnell | MKS3PI5AC230 | 20 | 1 | * $20.86 | * $17.04 | * $16.37 | * $13.69 | * $13.69 | * $13.69 |
MKS3PI5DC24
Omron Automation and Safety
RELAY 3PDT 250VAC 30VDC 10A; Contact Configuration:3PDT; Coil Voltage:24VDC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30VDC; Contact Material:Silver Tin Indium; Coil Resistance:430ohm; Approvals & Standards:-; Coil Current:55.8mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VDC Nom:24V; Contact Current AC Max:10A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:250V; Contact Voltage DC Nom:30V; Dielectric Strength VDC:2500V; External Depth:34.5mm; External Height:52.5mm; External Length / Height:52.5mm; External Width:34.5mm; Nom Operating Power:1.4W; Operating Temperature Max:60°C; Operating Temperature Min:-40°C; Relay Type:Power
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | Z3218-ND | 11 | 1 | $20.87 | $18.59 | $17.14 | $16.55 | $15.26 | $15.26 |
| element14 APAC | MKS3PI5DC24 | 22 | 1 | * $17.42 | * $17.42 | * $17.17 | * $17.17 | * $17.17 | * $17.17 |
| Farnell | MKS3PI5DC24 | 36 | 1 | * $10.91 | * $10.91 | * $10.91 | * $10.91 | * $10.91 | * $10.91 |
S8VTF24024E
Omron Automation and Safety
PSU DIN RAIL 240W 24V 3 PHASE; Power Supply Output Type:Fixed; No. of Outputs:1 Output; Input Voltage AC Min:400VAC; Input Voltage AC Max:500VAC; Output Power Max:240W; Output Voltage - Output 1:24VDC; Output Voltage - Output 2:-; Output Current - Output 1:10A; Output Current - Output 2:-; Product Range:-; Output Voltage - Output 3:-; Output Voltage - Output 4:-; Output Current - Output 3:-; Current Output 4:-; Approval Bodies:CSA UL; Approvals / Standards:EN 50178 EN 60204 UL 508; Efficiency:90%; External Depth:130mm; External Length / Height:170mm; External Width:45mm; Frequency Max:60Hz; Frequency Min:50Hz; Height:170mm; Hold Up Time:15ms; Input Current:1A; Input Frequency:60Hz; Input Voltage:500VAC; Length:130mm; No. of Outputs:1Outputs; Operating Temperature Max:70°C; Operating Temperature Min:-10°C; Output Current:10A; Output Ripple Voltage pk-pk:100mV; Output Voltage:24V; Power Rating:240W; Power Supply Type:Switch Mode; Storage Temperature Max:85°C; Storage Temperature Min:-45°C
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | S8VTF24024E | 0 | $428.89 | $428.89 | $428.89 | $428.89 | $428.89 | $428.89 | |
| element14 APAC | S8VTF24024E | 0 | 1 | * $266.39 | * $265.19 | * $265.19 | * $265.19 | * $265.19 | * $265.19 |
| Farnell | S8VTF24024E | 0 | * $280.43 |
E5AN-R3HMTD-500N
Omron Automation and Safety
CONTROLLER TEMP 1/4 DIN RELAY O/P; Thermocouple Type:B E J K L N R S T U W PLII; Operating Temperature Max:55°C; Operating Temperature Min:-10°C; Temperature Accuracy ±:1%; Output Voltage Max:250VAC; Output Voltage Min:-; Product Range:-; Current Rating:20mA; External Depth:85.2mm; External Width:96mm; Length:96mm; Voltage Rating:24V
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | E5AN-R3HMTD-500N | 0 | |||||||
| Farnell | E5AN-R3HMTD-500N | 0 | 1 | * $280.26 | * $280.26 | * $280.26 | * $280.26 | * $280.26 | * $280.26 |
E5EN-Q3HMTD-500N
Omron Automation and Safety
CONTROLLER TEMP 1/8 DIN 12 VDC O/P; Thermocouple Type:B E J K L N R S T U W PLII; Operating Temperature Max:55°C; Operating Temperature Min:-10°C; Temperature Accuracy ±:1%; Output Voltage Max:12VDC; Output Voltage Min:-; Product Range:-; Current Rating:20mA; External Depth:85.2mm; External Width:48mm; Length:96mm; Voltage Rating:24V
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | E5EN-Q3HMTD-500N | 0 | |||||||
| element14 APAC | E5EN-Q3HMTD-500N | 0 | 1 | * $376.53 | * $376.53 | * $376.53 | * $376.53 | * $376.53 | * $376.53 |
| Farnell | E5EN-Q3HMTD-500N | 0 | 1 | * $158.93 | * $158.93 | * $158.93 | * $158.93 | * $158.93 | * $158.93 |
E5CN-Q2MTD-500
Omron Automation and Safety
CONTROLLER TEMP 1/16 DIN 12 VDC O/P; Thermocouple Type:B E J K L N R S T U W PLII; Operating Temperature Max:55°C; Operating Temperature Min:-10°C; Temperature Accuracy ±:-; Output Voltage Max:-; Output Voltage Min:-; Product Range:-; Approval Bodies:CE; Approval Category:UL Recognised; Colour:Black; External Depth:91mm; External Length / Height:48mm; External Width:48mm; Output:2 x Auxiliary; Output Type:Voltage; Supply Voltage:24V
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | E5CN-Q2MTD-500 | 0 | |||||||
| element14 APAC | E5CN-Q2MTD-500 | 0 | 1 | * $299.51 | * $288.82 | * $269.56 | * $269.56 | * $269.56 | * $269.56 |
| Farnell | E5CN-Q2MTD-500 | 0 | 1 | * $265.31 | * $249.40 | * $244.09 | * $244.09 | * $244.09 | * $244.09 |
P7MF-06
Omron Automation and Safety
SOCKET RELAY FOR MKS-X; Socket Mounting:DIN Rail Panel; Socket Terminals:Screw; No. of Pins:6Pins; Current Rating:15A; Voltage Rating:250VAC; Product Range:POWER RELAYS MKS-X Series; Accessory Type:Relay Socket; For Use With:Omron MKS-X Series General Purpose Relays
ZEN-20C1DR-D-V2
Omron Automation and Safety
RELAY PROGRAM 24VDC 12 IN 8 OUT; Product Range:-; Relay Mounting:DIN Rail
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1,000 | 10,000 |
|---|---|---|---|---|---|---|---|---|---|
| DigiKey | ZEN-20C1DR-D-V2 | 0 | 1 | $355.76 | $355.76 | $355.76 | $355.76 | $355.76 | $355.76 |
| element14 APAC | ZEN-20C1DR-D-V2 | 1 | 1 | * $576.89 | * $576.89 | * $576.89 | * $576.89 | * $576.89 | * $576.89 |
| Farnell | ZEN-20C1DR-D-V2 | 1 | 1 | * $406.72 | * $406.72 | * $406.72 | * $406.72 | * $406.72 | * $406.72 |
