SN74LV4T08QWBQARQ1

Texas Instruments SN74LV4T08QWBQARQ1

SN74LV4T32QPWRQ1

Texas Instruments SN74LV4T32QPWRQ1

SN74LV595ABQBR

Texas Instruments SN74LV595ABQBR

SN74LV8T245QDGSRQ1

Texas Instruments SN74LV8T245QDGSRQ1

SN74LV8T245QPWRQ1

Texas Instruments SN74LV8T245QPWRQ1

SN75ALS192PWR

Texas Instruments SN75ALS192PWR

SN75LVPE3410RNQR

Texas Instruments SN75LVPE3410RNQR

TAS2505ATRGERQ1

Texas Instruments TAS2505ATRGERQ1

TAS2781RYYR

Texas Instruments TAS2781RYYR

TCA39306DDFR

Texas Instruments TCA39306DDFR

Price
RoHS Y Y Y Y Y Y Y Y Y Y
Lead Status Y Y Y Y Y Y Y Y Y Y
Data rate(max)(MBits) 150 150
Data rate(max)(Mbps) 150 150
Features Over-voltage tolerant inputs,Single supply Balanced outputs,Over-voltage tolerant inputs Balanced outputs,Output register,Over-voltage tolerant inputs,Partial power down (Ioff),Very high speed (tpd 5-10ns) Balanced outputs,Over-voltage tolerant inputs,Very high speed (tpd 5-10ns) Balanced outputs,Over-voltage tolerant inputs,Very high speed (tpd 5-10ns) Enable pin
IOH(max)(mA) -8 -8 -16 -8 -8
IOL(max)(mA) 8 8 16 8 8
Input type Standard CMOS,TTL-Compatible CMOS Standard CMOS,TTL-Compatible CMOS Standard CMOS TTL/CMOS TTL/CMOS
Number of channels 4 4 8 8 4
Operating temperature range(C) -40 -40 -40 -40 -40 0 -40 -40 -40
Output type Balanced CMOS,Push-Pull Push-Pull 3-State CMOS CMOS
Package area(mm^2) 7.5 32 8.75 24.99 41.6 32 24 16 14 8.12
Package size (L x W)(mm) 3 x 2.5 5 x 6.4 3.5 x 2.5 5.1 x 4.9 6.5 x 6.4 5 x 6.4 6 x 4 4 x 4 3.5 x 4 2.9 x 2.8
Package type WQFN TSSOP WQFN VSSOP TSSOP TSSOP WQFN VQFN VQFN-HR SOT-23-THN
Pin count 14 14 16 20 20 16.0 40.0 24 30 8
Supply current(max)(A) 20 20 20 45000
Technology family LVxT LVxT LV-A LV-A LV-A
Vout(max)(V) 5.5 5.5
Vout(min)(V) 1.65 1.65
TI.com inventory 209500 5500 267085 19880 3500 0 5253 3435 6557 141856
Approx. price(US$) .318 | 1ku .118 | 1ku .115 | 1ku .472 | 1ku .472 | 1ku .826 | 1u 2.97 | 1ku .792 | 1ku 1.131 | 1ku .3 | 1ku
Bits(#) 8
Clock frequency(MHz) 95
Configuration Serial-in, Parallel-out
Rating Catalog Automotive Automotive Catalog Catalog Automotive Catalog Catalog
Supply voltage(max)(V) 5.5 5.5 5.5
Supply voltage(min)(V) 2 1.65 1.65
Common-mode range(V) -3 to 3
Fault protection(V) -12 to 12
IEC 61000-4-2 contact(V) None
Isolated No
Number of nodes 32
Number of receivers 0
Number of transmitters 4
Signaling rate(max)(MBits) 20
Supply voltage(nom)(V) 5
TI functional safety category
Applications Backplane,CXL,PCIE,PCIe,SAS,SATA
Protocols CXL,PCI/PCIe,PCIe,PCIe1,PCIe2,PCIe3 I2C,I3C
Speed(max)(Gbps) 0.8
Supply voltage(V) 3.3
Type Redriver
Analog supply voltage(max)(V) 1.95 1.95
Analog supply voltage(min)(V) 1.5 1.65
Analog supply(max)(V) 1.95 1.95
Analog supply(min)(V) 1.5 1.65
Architecture Class-D Class-D,Smart Amp
Audio input type Analog Input,Digital Input Digital Input
Closed/open loop Closed Closed
Control interface I2C,SPI I2C,SPI,Shutdown Mode
Iq(typ)(mA) 0.002 15
Load(min)() 4 3.2
Output power(W) 2.6 25
PSRR(dB) 47.2 110
Power stage supply(max)(V) 5.5 23
Power stage supply(min)(V) 2.7 4.5
SNR(dB) 94 110
Sampling rate(max)(kHz) 96 192
Speaker channels(max) Mono Mono
THD + N at 1 kHz(%) 0.02 0.006
Frequency(max)(MHz) 12.5
Supply restrictions VCCA <= VCCB
VCCA(max)(V) 5.5
VCCA(min)(V) 0.85
VCCB(max)(V) 5.5
VCCB(min)(V) 1.65
