The AD5412/AD5422 are low cost, precision, fully integrated12-/16-bit digital-to-analog converters (DAC) offering a programmable current source and programmable voltage output designed to meet the requirements of industrial process control applications.The output current range is programmable at 4 mA to 20 mA, 0 mA to 20 mA, or an overrange function of 0 mA to 24 mA.The LFCSP version of this product has a CAP2 pin so that the HART signals can be coupled onto the current output of the AD5412/AD5422.Voltage output is provided from a separate pin that can be configured to provide 0 V to 5 V, 0 V to 10 V, ?5 V, or ?10 V output ranges; an overrange of 10% is available on all ranges.Analog outputs are short and open-circuit protected and can drive capacitive loads of 1 ?F.The device operates with an AVDD power supply range from 10.8 V to 40 V. Current loop compliance voltage is 0 V to AVDD ? 2.5 V.The flexible serial interface is SPI- and MICROWIRE?-compatible and can be operated in 3-wire mode to minimize the digital isolation required in isolated applications.The device also includes a power-on-reset function, ensuring that the device powers up in a known state. The part also includes an asynchronous clear pin (CLEAR) that sets the outputs to zero-scale/midscale voltage output or the low end of the selected current range.The total output error is typically ?0.01% in current mode and ?0.01% in voltage mode.Applications Process controls Actuator controls PLC HART network connectivity (LFCSP package only)

The AD5512A?/ AD5542A are single, 12-/16-bit, serial input, unbuffered voltage output digital-to-analog converters (DAC) that operate from a single 2.7 V to 5.5 V supply. The DAC output range extends from 0 V to VREF?and is guaranteed monotonic, providing 1 LSB INL accuracy at 16 bits without adjustment over the full specified temperature range of ?40?C to +85?C (AD5542A) or ?40?C to +125?C (AD5512A).Offering unbuffered outputs, the AD5512A / AD5542A achieve a 1 ?s settling time with low offset errors ideal for high speed open loop control.The AD5512A / AD5542A incorporate a bipolar mode of operation that generates a ?VREF?output swing. The AD5512A / AD5542A also include Kelvin sense connections for the reference and analog ground pins to reduce layout sensitivity.The AD5512A / AD5542A are available in a 16-lead LFCSP with the AD5542A also available in a 10-lead LFCSP and a 16-lead TSSOP. The AD5512A / AD5542A use a versatile 3-wire interface that is compatible with 50 MHz SPI, QSPI?, MICROWIRE?, and DSP interface standards.APPLICATIONS Automatic test equipment Precision Source-measure Instruments Data Acquisition Systems Medical and aerospace Instrumentation Communications equipmentPRODUCT HIGHLIGHTS 16-bit performance without adjustment. 2.7 V to 5.5 V single supply operation. Low 11.8 nV/?Hz noise spectral density. Low 0.05 ppm/?C temperature drift. 3 mm ? 3 mm LFCSP and TSSOP packaging.

The AD5546 /?AD5556 are precision 16-/14-bit, multiplying, low power, current output, parallel input D/A converters. They operate from a single 2.7 V to 5.5 V supply with ?10 V multiplying references for 4-quadrant outputs. Built-in 4-quadrant resistors facilitate the resistance matching and temperaturetracking that minimize the number of components needed for multiquadrant applications. The feedback resistor (RFB) simplifies the I-V conversion with an external buffer. The AD5546/AD5556 are packaged in compact TSSOP-28 packages with operating temperatures from ?40?C to +125?C.APPLICATIONS Automatic test equipment Instrumentation Digitally controlled calibration Digital waveform generation?

The AD5758 is a single-channel, voltage and current output digital-to-analog converter (DAC) that operates with a power supply range from ?33 V (minimum) on AVSS to +33 V (maximum) on AVDD1 with a maximum operating voltage between the two rails of 60 V. On-chip dynamic power control (DPC) minimizes package power dissipation, which is achieved by regulating the supply voltage (VDPC+) to the VIOUT output driver circuitry from 5 V to 27 V using a buck dc-to-dc converter, optimized for minimum on-chip power dissipation. The CHART pin enables a HART? signal to be coupled onto the current output.The device uses a versatile 4-wire serial peripheral interface (SPI) that operates at clock rates of up to 50 MHz and is compatible with standard SPI, QSPI?, MICROWIRE?, DSP, and microcontroller interface standards. The interface also features an optional SPI cyclic redundancy check (CRC) and a watchdog timer (WDT). The AD5758 offers improved diagnostic features from its predecessors, such as an integrated 12-bit diagnostic analog-to-digital converter (ADC). Additional robustness is provided by the inclusion of a line protector on the VIOUT, +VSENSE, and ?VSENSE pins. When used with its companion power management unit (PMU)/isolator (ADP1031), the AD5758 is capable of enabling customers to develop an eight channel to channel isolated analog output module with less than 2 W power dissipation, while meeting CISPR 11 Class B. Product Highlights DPC, using an integrated buck dc-to-dc converter for thermal management. When used with the ADP1031, the AD5758 enables eight channel to channel isolated outputs at <2 W dissipated power. Range of advanced diagnostic features, including an integrated ADC for high reliability. Highly robust with output protection from miswire events (?38 V). HART compliant.Applications Process control Actuator control Channel isolated analog outputs Programmable logic controller (PLC) and distributed control systems (DCS) applications HART network connectivity

The AD5781 is a single 18-bit, unbuffered voltage-output DAC that operates from a bipolar supply of up to 33 V. The AD5781 accepts a positive reference input in the range 5V to VDD ? 2.5 V and a negative reference input in the range VSS?+ 2.5 V to 0 V. The AD5781 offers a relative accuracy specification of ?0.5 LSB max, and operation is guaranteed monotonic with a ?0.5 LSB DNL maximum specification.The part uses a versatile 3-wire serial interface that operates at clock rates up to 35 MHz and that is compatible with standard SPI?, QSPI?, MICROWIRE?, and DSP interface standards. The part incorporates a power-on reset circuit that ensures the DAC output powers up to 0 V and in a known output impedance state and remains in this state until a valid write to the device takes place. The part provides an output clamp feature that places the output in a defined load state.PRODUCT HIGHLIGHTS True 18-Bit Accuracy. Wide Power Supply Range of Up to ?16.5 V. ?40?C to +125?C Operating Temperature Range. Low 7.5 nV/?Hz Noise. Low 0.05 ppm/?C Temperature Drift.APPLICATIONS Medical Instrumentation Test and Measurement Industrial Control Scientific and Aerospace Instrumentation Data Acquisition Systems Digital Gain and Offset Adjustment Power Supply Control

The AD7091R-2 /?AD7091R-4?/?AD7091R-8 family is a multichannel12-bit, ultralow power, successive approximation analog-to-digitalconverter (ADC) that is available in two, four, or eightanalog input channel options. The AD7091R-2 / AD7091R-4 /AD7091R-8 operate from a single 2.7 V to 5.25 V power supplyand are capable of achieving a sampling rate of 1 MSPS.The AD7091R-2 / AD7091R-4 / AD7091R-8 family offers up to eightsingle-ended analog input channels with a channel sequencerthat allows a preprogrammed selection of channels to be convertedsequentially. The AD7091R-2 / AD7091R-4 / AD7091R-8 alsofeature an on-chip conversion clock, an on-chip accurate 2.5 Vreference, and a high speed serial interface.The AD7091R-2 / AD7091R-4 / AD7091R-8 have a serial portinterface (SPI) that allows data to be read after the conversionwhile achieving a 1 MSPS throughput rate. The conversion processand data acquisition are controlled using the CONVST pin.The AD7091R-2 / AD7091R-4 / AD7091R-8 use advanced designtechniques to achieve ultralow power dissipation at highthroughput rates. They also feature flexible power managementoptions. An on-chip configuration register allows the user to set updifferent operating conditions. These include power management,alert functionality, busy indication, channel sequencing, andgeneral-purpose output pins. The MUXOUT and ADCIN pinsallow signal conditioning of the multiplexer output prior toacquisition by the ADC.APPLICATIONS Battery powered systems Personal digital assistants Medical instruments Mobile communications Instrumentation and control systems Data acquisition systems Optical sensors Diagnostic/monitoring functions

The AD7124-4 is a low power, low noise, completely integrated analog front end for high precision measurement applications. The device contains a low noise, 24-bit ?-? analog-to-digital converter (ADC), and can be configured to have 4 differential inputs or 7 single-ended or pseudo differential inputs. The onchip low gain stage ensures that signals of small amplitude can be interfaced directly to the ADC.One of the major advantages of the AD7124-4 is that it gives the user the flexibility to employ one of three integrated power modes. The current consumption, range of output data rates, and rms noise can be tailored with the power mode selected. The device also offers a multitude of filter options, ensuring that the user has the highest degree of flexibility.The AD7124-4 can achieve simultaneous 50 Hz and 60 Hz rejection when operating at an output data rate of 25 SPS (single cycle settling), with rejection in excess of 80 dB achieved at lower output data rates.The AD7124-4 establishes the highest degree of signal chain integration. The device contains a precision, low noise, low drift internal band gap reference, and also accepts an external differential reference, which can be internally buffered. Other key integrated features include programmable low drift excitation current sources, burnout currents, and a bias voltage generator, which sets the common-mode voltage of a channel to AVDD/2. The low-side power switch enables the user to power down bridge sensors between conversions, ensuring the absolute minimal power consumption of the system. The device also allows the user the option of operating with either an internal clock or an external clock.The integrated channel sequencer allows several channels to be enabled simultaneously, and the AD7124-4 sequentially converts on each enabled channel, simplifying communication with the device. As many as 16 channels can be enabled at any time; a channel being defined as an analog input or a diagnostic such as a power supply check or a reference check. This unique feature allows diagnostics to be interleaved with conversions.The AD7124-4 also supports per channel configuration. The device allows eight configurations or setups. Each configuration consists of gain, filter type, output data rate, buffering, and reference source. The user can assign any of these setups on a channel by channel basis.The AD7124-4 also has extensive diagnostic functionality integrated as part of its comprehensive feature set. These diagnostics include a cyclic redundancy check (CRC), signal chain checks, and serial interface checks, which lead to a morerobust solution. These diagnostics reduce the need for external components to implement diagnostics, resulting in reduced board space needs, reduced design cycle times, and cost savings. The failure modes effects and diagnostic analysis (FMEDA) of a typical application has shown a safe failure fraction (SFF) greater than 90% according to IEC 61508.The device operates with a single analog power supply from 2.7 V to 3.6 V or a dual 1.8 V power supply. The digital supply has a range of 1.65 V to 3.6 V. It is specified for a temperature range of ?40?C to +105?C. The AD7124-4 is housed in a 32-lead LFCSP package or a 24-lead TSSOP package.Applications Temperature measurement? Pressure measurement? Industrial process control? Instrumentation Smart transmitters Smart transmitters

The AD7171 is a very low power, 16-bit, analog-to-digitalconverter (ADC). It contains a precision, 16-bit, ?-? ADC andan on-chip oscillator. Consuming only 135 ?A, the AD7171 isparticularly suitable for portable or battery operated productswhere very low power is a requirement. The AD7171 also has apower-down mode in which the device consumes 5 ?A, thusincreasing the battery life of the product.For ease of use, dedicated pins control all of the features of theAD7171. Each time a data read occurs, eight status bits areappended to the 16-bit conversion. These status bits contain apattern sequence that can be used to confirm the validity of theserial transfer.The output data rate of the AD7171 is 125 Hz, whereas the settlingtime is 24 ms. The AD7171 has one differential input and a gainof 1. This is useful in applications where the user needs to use anexternal amplifier to implement system-specific filtering or gainrequirements.The AD7171 operates with a power supply from 2.7 V to 5.25 V.It is available in a 10-lead LFCSP.The AD7170 is a 12-bit version of the AD7171. It has the samefeature set as the AD7171 and is pin-for-pin compatible.Applications Weigh scales Pressure measurement Industrial process control Portable instrumentation

The AD7192 is a low noise, complete analog front end for high precision measurement applications. It contains a low noise, 24-bit sigma-delta (?-?) analog-to-digital converter (ADC). The on-chip low noise gain stage means that signals of small amplitude can be interfaced directly to the ADC.The device can be configured to have two differential inputs or four pseudo differential inputs. The on-chip channel sequencer allows several channels to be enabled, and the AD7192 sequentially converts on each enabled channel. This simplifies communication with the part. The on-chip 4.92 MHz clock can be used as the clock source to the ADC or, alternatively, an external clock or crystal can be used. The output data rate from the part can be varied from 4.7 Hz to 4.8 kHz.The device has two digital filter options. The choice of filter affects the rms noise/noise-free resolution at the programmed output data rate, the settling time, and the 50 Hz/60 Hz rejection. For applications that require all conversions to be settled, the AD7192 includes a zero latency feature.The part operates with a power supply from 3 V to 5.25 V. It consumes a current of 4.35 mA. It is housed in a 24-lead TSSOP package.ApplicationsWeigh scalesStrain gage transducersPressure measurementPressure measurementTemperature measurementChromatographyPLC/DCS analog input modulesData acquisitionMedical and scientific instrumentation

The AD7380/AD7381 are a 16-bit and 14-bit pin-compatible family of dual simultaneous sampling, high speed, low power, successive approximation register (SAR) analog-to-digital converters (ADCs) that operate from a 3.0 V to 3.6 V power supply and feature throughput rates up to 4 MSPS. The analog input type is differential, accepts a wide common-mode input?voltage, and is sampled and converted on the falling edge of CS.An integrated on-chip oversampling block improves dynamic range and reduces noise at lower bandwidths. A buffered internal 2.5 V reference is included. Alternatively, an external?reference up to 3.3 V can be used.The conversion process and data acquisition use standard control?inputs allowing simple interfacing to microprocessors or digital signal processors (DSPs). The device is compatible with 1.8 V, 2.5 V, and 3.3 V interfaces using the separate logic supply.The AD7380/AD7381 are available in a 16-lead lead frame chip scale package (LFCSP) with operation specified from ?40?C to +125?C.Product highlights Dual simultaneous sampling and conversion with two complete ADC functions. Pin-compatible product family. High 4 MSPS throughput rate. Space saving 3 mm ? 3 mm LFCSP. An integrated oversampling block to increase dynamic range, reduce noise, and reduce SCLK speed requirements. Differential analog inputs with wide common-mode range. Small sampling capacitor reduces amplifier drive burden.Applications Motor control position feedback Motor control current sense Sonar Power quality Data acquisition systems Erbium doped fiber amplifier (EDFA) applications I and Q demodulation
