The ADT74701 controller is a multichannel temperature sensor and PWM fan controller and fan speed monitor for systems requiring active cooling. It is designed to interface directly to an I2C? bus. The ADT7470 can monitor up to 10 daisy-chained TMP05?temperature sensors. It can also monitor and control the speed of four fans, in automatic or in manual control loops.A FULL_SPEED input is provided to allow the fans to be blasted to maximum speed, via external hardware control, under extreme thermal conditions or on system startup. An SMBALERT interrupt communicates error conditions such as fan under speed and over temperature measurements to the system service processor. Individual error conditions can then be read from status registers over the I2C bus.APPLICATIONS Servers Networking and telecommunications equipment Desktops

The AD9119/AD9129 are high performance, 11-/14-bit RF digital-to-analog converters (DACs) supporting data rates up to 2.85 GSPS. The DAC core is based on a quad-switch architecture that enables dual-edge clocking operation, effectively increasing the DAC update rate to 5.7 GSPS when configured for Mix-Mode? or 2? interpolation. The high dynamic range and bandwidth enable multicarrier generation up to 4.2 GHz.In baseband mode, wide bandwidth capability combines with high dynamic range to support from 1 to 158 contiguous carriers for CATV infrastructure applications. A choice of two optional 2? interpolation filters is available to simplify the postreconstruction filter by effectively increasing the DAC update rate by a factor of 2. In Mix-Mode operation, the AD9119/AD9129 can reconstruct RF carriers in the second and third Nyquist zone while still maintaining exceptional dynamic range up to 4.2 GHz. The high performance NMOS DAC core features a quad-switch architecture that enables industry-leading direct RF synthesis performance with minimal loss in output power. The output current can be programmed over a range of 9.5 mA to 34.4 mA.The AD9119/AD9129 include several features that may further simplify system integration. A dual-port, source synchronous LVDS interface simplifies the data interface to a host FPGA/ASIC. A differential frame/parity bit is also included to monitor the integrity of the interface. On-chip delay locked loops (DLLs) optimize timing between different clock domains.A serial peripheral interface (SPI) configures the AD9119/ AD9129 and monitors the status of readback registers. The AD9119/AD9129 are manufactured on a 0.18 ?m CMOS process and operates from +1.8 V and ?1.5 V supplies. It is supplied in a 160-ball chip scale package ball grid array.Product Highlights High dynamic range and signal reconstruction bandwidth support RF signal synthesis of up to 4.2 GHz. Dual-port interface with double data rate (DDR) LVDS data receivers supports 2850 MSPS maximum conversion rate. Manufactured on a CMOS process; a proprietary switching technique enhances dynamic performance.Applications Broadband communications systems CMTS/VOD Wireless infrastructure: W-CDMA, LTE, point-to-point Instrumentation, automatic test equipment (ATE) Radar, jammers

Demonstration circuit 995A is an adjustable 1.1A linear regulator featuring the LT3080. Architected as a precision current source and voltage follower, it allows this new regulator to be used in many applications requiring high current, adjustability to zero output, and no heat sink. The device brings out the collector of the pass transistor to allow low dropout operation when used with multiple supplies. The demo board's input supply voltage range is 2.3V to 25V. For proper regulation, the LT3080 has a control pin; the voltage on this pin must be 1.2V to 1.35V higher than the output voltage.The output voltage is jumper selectable and can be set to 1.8V, a value between 0V and 5V (using trimpot R2) or a user-defined value. A key feature of the LT3080 is its wide output voltage range. By using a reference current through a single resistor, the output voltage can be programmed to any level between zero and 36V. The DC995A has a reduced input voltage 25V due to input capacitor voltage rating. The DC995A can be used as a high current linear regulator, a post regulator for switching supply,a  variable voltage supply or a low output voltage power supply.

The AD9763/AD9765/AD9767 are dual-port, high speed, 2-channel, 10-/12-/14-bit CMOS DACs. Each part integratestwo high quality TxDAC+? cores, a voltage reference, and digital interface circuitry into a small 48-lead LQFP. The AD9763/AD9765/AD9767 offer exceptional ac and dc performancewhile supporting update rates of up to 125 MSPS.The AD9763/AD9765/AD9767 have been optimized forprocessing I and Q data in communications applications. Thedigital interface consists of two double-buffered latches as well as control logic. Separate write inputs allow data to be written to the two DAC ports independent of one another. Separate clocks control the update rate of the DACs.A mode control pin allows the AD9763/AD9765/AD9767 to interface to two separate data ports, or to a single interleavedhigh speed data port. In interleaving mode, the input datastream is demuxed into its original I and Q data and then latched. The I and Q data is then converted by the two DACsand updated at half the input data rate.The GAINCTRL pin allows two modes for setting the full-scale current (IOUTFS) of the two DACs. IOUTFS for each DAC can be set independently using two external resistors, or IOUTFS for both DACs can be set by using a single external resistor. See theGain Control Mode section for important date codeinformation on this feature.The DACs utilize a segmented current source architecturecombined with a proprietary switching technique to reduce glitch energy and maximize dynamic accuracy. Each DAC providesdifferential current output, thus supporting single-ended or differential applications. Both DACs of the AD9763, AD9765, or AD9767 can be simultaneously updated and can provide anominal full-scale current of 20 mA. The full-scale currentsbetween each DAC are matched to within 0.1%.The AD9763/AD9765/AD9767 are manufactured on anadvanced, low cost CMOS process. They operate from a singlesupply of 3.3 V to 5 V and consume 380 mW of power.Product HighlightsThe AD9763/AD9765/AD9767 are members of a pin-compatible family of dual TxDACs providing 8-, 10-, 12-, and 14-bit resolution.Dual 10-/12-/14-Bit, 125 MSPS DACs. A pair of high performance DACs for each part is optimized for low distortion performance and provides flexible transmission of I and Q information.Matching. Gain matching is typically 0.1% of full scale, and offset error is better than 0.02%.Low Power. Complete CMOS dual DAC function operates on 380 mW from a 3.3 V to 5 V single supply. The DAC full-scalecurrent can be reduced for lower power operation, and a sleepmode is provided for low power idle periods.On-Chip Voltage Reference. The AD9763/AD9765/AD9767each include a 1.20 V temperature-compensated band gapvoltage reference.Dual 10-/12-/14-Bit Inputs. The AD9763/AD9765/AD9767each feature a flexible dual-port interface, allowing dual orinterleaved input data.ApplicationsCommunicationsBase stationsDigital synthesisQuadrature modulation3D ultrasound

The LTC2378-20 is a low noise, low power, high speed 20-bit successive approximation register (SAR) ADC. Operating from a 2.5V supply, the LTC2378-20 has a ?VREF fully differential input range with VREF ranging from 2.5V to 5.1V. The LTC2378-20 consumes only 21mW and achieves ?2ppm INL maximum, no missing codes at 20 bits with 104dB SNR.The LTC2378-20 has a high speed SPI-compatible serial interface that supports 1.8V, 2.5V, 3.3V and 5V logic while also featuring a daisy-chain mode. The fast 1Msps throughput with no cycle latency makes the LTC2378-20 ideally suited for a wide variety of high speed applications. An internal oscillator sets the conversion time, easing external timing considerations. The LTC2378-20 automatically powers down between conversions, leading to reduced power dissipation that scales with the sampling rate.The LTC2378-20 features a unique digital gain compression (DGC) function, which eliminates the driver amplifier?s negative supply while preserving the full resolution of the ADC. When enabled, the ADC performs a digital scaling function that maps zero-scale code from 0V to 0.1 ? VREF and full-scale code from VREF to 0.9 ? VREF. For a typical reference voltage of 5V, the full-scale input range is now 0.5V to 4.5V, which provides adequate headroom for powering the driving amplifier from a single 5.5V supply.Applications Medical Imaging High Speed Data Acquisition Portable or Compact Instrumentation Industrial Process Control Low Power Battery-Operated Instrumentation ATE

The LTC6905-X series of parts are precision, fixed frequency, silicon oscillators designed to minimize board space while maximizing accuracy and ease of use.Programmed at the factory to a fixed frequency, the LTC6905-X series of parts need no external trim components. An internal three-state divider allows for division of the master clock by 1, 2 or 4, providing 3 frequencies (for each device).The LTC6905-X series operate with a single 2.7V to 5.5V power supply and provide a rail-to-rail, 50% duty cycle, square wave output. The OE pin will disable the output when brought low and synchronously enable the output when brought high, avoiding pulse slivers.The four products of the LTC6905-X family are: LTC6905-133: fOSC = 133MHz, 66.7MHz, 33.3MHz LTC6905-100: fOSC = 100MHz, 50MHz, 25MHz LTC6905-96: fOSC = 96MHz, 48MHz, 24MHz LTC6905-80: fOSC = 80MHz, 40MHz, 20MHz?The LTC6905-X series of parts are designed with a factory trim option to modify the divider ratios from 1, 2, 4 to 8, 16, 32. A second trim option allows for additional master clock frequencies. For the alternate divider ratios and unlisted frequencies, contact LTC marketing.Protected by U.S. Patents, including 6614313, 6342817.Applications Data Clocks for High Reliability Applications High Vibration, High Acceleration Environments Replacement for Fixed Crystal and Ceramic Oscillators

Demonstration Circuit 1754A features the LTC3104, a high efficiency, monolithic synchronous step-down converter using a current mode architecture capable of supplying 300mA of output current. The IC operates with a fixed frequency oscillator at 1.2MHz. The LTC3104 also incorporates a programmable LDO which can be operated from VIN, VOUT or an independent supply. The LDO can also be independently turned off or on. The LTC3104 operates with a 2.5V to 15V input voltage range. The demo board has been designed with the main output set to 3.3V and the LDO output (VLDO) to 1.8V.

The ADP7112 is a CMOS, low dropout (LDO) linear regulator that operates from 2.7 V to 20 V and provides up to 200 mA of output current. This high input voltage LDO is ideal for the regulation of high performance analog and mixed signal circuits operating from 20 V down to 1.2 V rails. Using an advanced proprietary architecture, the device provides high power supply rejection, low noise, and achieves excellent line and load transient response with a small 2.2 ?F ceramic output capacitor. The ADP7112?regulator output noise is 11 ?V rms independent of the output voltage for the fixed options of 5 V or less.The ADP7112?is available in 16 fixed output voltage options. The following voltages are available from stock: 1.2 V (adjustable), 1.8 V, 2.5 V, 3.3 V, and 5.0 V. Additional voltages available by special order are 1.5 V, 1.85 V, 2.0 V, 2.2 V, 2.75 V, 2.8 V, 2.85 V, 3.8 V, 4.2 V, and 4.6 V.Each fixed output voltage can be adjusted above the initial set point with an external feedback divider. This allows the ADP7112?to provide an output voltage from 1.2 V to VIN ? VDO with high PSRR and low noise.User programmable soft start with an external capacitor is available in the?ADP7112. The ADP7112?is available in a 6-ball 1 mm ? 1.2mm WLCSP, making it a very compact solution.Applications Regulation to noise sensitive applications ADC, DAC circuits, precision amplifiers, power for VCO VTUNE control Communications and infrastructure Medical and healthcare Industrial and instrumentation

The ADP5075 is a high performance dc-to-dc inverting regulator used to generate negative supply rails.The input voltage range of 2.85 V to 15 V supports a wide variety of applications. The integrated main switch enables the generation of an adjustable negative output voltage down to 39 V below the input voltage.The ADP5075 operates at a pin selected 1.2 MHz/2.4 MHz switching frequency. The ADP5075 can synchronize with an external oscillator from 1.0 MHz to 2.6 MHz to ease noise filtering in sensitive applications. The regulator implements programmable slew rate control circuitry for the MOSFET driver stage to reduce electromagnetic interference (EMI).The ADP5075 includes a fixed internal or resistor programmable soft start timer to prevent inrush current at power-up. During shutdown, the regulator completely disconnects the load from the input supply to provide a true shutdown.Other key safety features in the ADP5075 include overcurrent protection (OCP), overvoltage protection (OVP), thermal shutdown (TSD), and input undervoltage lockout (UVLO).The ADP5075 is available in a 12-ball WLCSP and is rated for a ?40?C to +125?C junction temperature range.Applications Bipolar amplifiers, analog-to-digital converters (ADCs), ?digital-to-analog converters (DACs), and multiplexers Charge coupled device (CCD) bias supplies Optical module supplies Radio Frequency (RF) power amplifier (PA) bias

The ADRF5141 is a reflective, single pole double-throw (SPDT) switch manufactured in the silicon process. It is used in transmit-receive (T/R) applications with an integrated power limiter at the receive side. The ADRF5141 operates from 8 GHz to 12 GHz. The RX arm with the integrated power limiter has a limiting capability of 18 dBm output power (TBC) with a low insertion loss of 1.3 dB at 10 GHz while the TX arm has an insertion loss of 0.9 dB at 10 GHz. The ADRF5141 draws a low current of 13 ?A on the positive supply of +3.3 V and 360 ?A on negative supply of ?3.3 V. The device employs complementary metal-oxide semiconductor (CMOS)-/low voltage transistor to transistor logic (LVTTL)-compatible controls. The ADRF5141 requires no additional driver circuitry, making it an ideal alternative to GaN and PIN diode-based switches. The ADRF5141 comes in a 20-lead, 3.0 mm ? 3.0 mm, RoHS-compliant, land grid array (LGA) package and can operate from ?40?C to +85?.APPLICATIONSElectronic warfareMilitary radios, radars, and electronic counter measuresGaN and PIN diode replacement
