The ADuM160N/ADuM161N/ADuM162N/ADuM163N are 6-channel digital isolators based on Analog Devices, Inc., iCoupler? technology. Combining high speed, complementary metal-oxide semiconductor (CMOS) and monolithic air core transformer technology, these isolation components provide outstanding performance characteristics superior to alternatives such as optocoupler devices and other integrated couplers. The maximum propagation delay is 13 ns with a pulse width distortion of less than 4.5 ns at 5 V operation. Channel to channel matching of propagation delay is tight at 4.0 ns maximum.The ADuM160N/ADuM161N/ADuM162N/ADuM163N data channels are independent and are available in a variety of configurations with a withstand voltage rating of 3.0 kV rms (see the Ordering Guide). The devices operate with the supply voltage on either side ranging from 1.7 V to 5.5 V, providing compatibility with lower voltage systems as well as enabling voltage translation functionality across the isolation barrier.Unlike other optocoupler alternatives, dc correctness is ensured in the absence of input logic transitions. Two different fail-safe options are available by which the outputs transition to a predetermined state when the input power supply is not applied.Applications General-purpose multichannel isolation Serial peripheral interface (SPI)/data converter isolation Industrial field bus isolation

The ADuM3123 is a 4.0 A isolated, single channel driver that employs Analog Devices, Inc.?s?iCoupler? technology to provide precision isolation. The ADuM3123 provides 3000 VRMS isolation in the narrow body 8-lead SOIC package. ?Combining high speed CMOS and monolithic transformer technology, these isolation components provide outstanding performance characteristics superior to alternatives such as the combination of pulse transformers and gate drivers. ?The ADuM3123 operate with an input supply ranging from 3.0 V to 5.5 V, providing compatibility with lower voltage systems. ?In comparison to gate drivers employing high voltage level translation methodologies, the ADuM3123 offer the benefit of true, galvanic isolation between the input and the output. The output may be continuously operated up to 380 V rms relative to the input.?As a result, the ADuM3123 provide reliable control over the switching characteristics of IGBT/MOSFET configurations over a wide range of positive or negative switching voltages.??Applications Switching power supplies? Isolated IGBT/MOSFET gate drives? Industrial inverters?

The ADuM3154 is an SPIsolator? digital isolator optimized for a serial peripheral interface (SPI) that includes support for up to four slave devices. Based on the Analog Devices, Inc., iCoupler? chip scale transformer technology, the low propagation delay and jitter in the CLK, MO/SI, MI/SO, and SS SPI bus signals support SPI clock rates of up to 17 MHz.The ADuM3154 isolator also provides a slave select multiplexing system that allows up to four slave devices to be serviced from one isolator. When a target slave is selected, the slave select signal propagates to the desired output with low propagation delay, allowing tight timing control. The isolated SSx is addressed through a 250 kbps low speed, 2-channel address bus, allowing the target slave device to be changed in as little as 2.5 ?s.Applications Industrial programmable logic controllers (PLCs) Sensor isolation

The ADuM3480 / ADuM3481 / ADuM3482 are quad-channel digital isolators based on the Analog Devices, Inc.,iCoupler? technology. Combining high speed CMOS and monolithic air core transformer technology, these isolation components provide outstanding performance characteristics superior to alternatives such as optocoupler devices and other integrated couplers. With typical propagation delay reduced to 25 ns, pulse width distortion is also halved.The four channels of the ADuM3480 / ADuM3481 / ADuM3482 are available in a variety of channel configurations with two data rate grades up to 25 Mbps (see the Ordering Guide section). All models use separate core and I/O power supplies. The core operates between 3.0 V and 5.5 V, whereas the I/O supply can range from 1.8 V to 5.5 V. If operation is required within the range of the core supply, the two supplies can be tied together to allow single-supply operation. When the I/O must interface with logic levels that are different from the core supply voltage, then the I/O supply can be operated independently of the core supply over a wider range. The minimum I/O supply voltage is 1.8 V, allowing compatibility with low voltage logic. Both core and I/O supplies are required for proper operation.APPLICATIONS General-purpose multichannel isolation SPI interface/data converter isolation Industrial field bus isolation

The ADuM4120/ADuM4120-1 are 2 A isolated, single-channel drivers that employ Analog Devices, Inc., iCoupler? technology to provide precision isolation. The ADuM4120/ADuM4120-1provide 5 kV rms isolation in the 6-lead wide body SOIC package with increased creepage. Combining high speed CMOS and monolithic transformer technology, these isolation components provide outstanding performance characteristics, such as the combination of pulse transformers and gate drivers.The ADuM4120/ADuM4120-1 operate with input supplies ranging from 2.5 V to 6.5 V, providing compatibility with lowervoltage systems. In comparison to gate drivers employing high voltage level translation methodologies, the ADuM4120/ADuM4120-1 offer the benefit of true, galvanic isolation betweenthe input and the output.Options exist for models with and without an input glitch filter. The glitch filter helps reduce the chance of noise on the input pintriggering an output.As a result, the ADuM4120/ADuM4120-1 provide reliable control over the switching characteristics of insulated gatebipolar transistor (IGBT)/metal-oxide semiconductor field effect transistor (MOSFET) configurations over a wide range of switching voltages.Applications Switching power supplies? IGBT/MOSFET gate drivers Industrial inverters? Gallium nitride (GaN)/silicon carbide (SiC) power devices

The ADuM4136 is a single-channel gate driver specifically optimized for driving insulated gate bipolar transistors (IGBTs). Analog Devices, Inc., iCoupler? technology provides isolation between the input signal and the output gate drive.Operation with unipolar or bipolar secondary supplies is possible, allowing negative gate drive if needed.The Analog Devices chip scale transformers also provide isolated communication of control information between the high voltage and low voltage domains of the chip. Information on the status of the chip can be read back from dedicated outputs. Control of resetting the device after a fault on the secondary side is performed on the primary side of the device.Integrated onto the ADuM4136 is a desaturation detection circuit that provides protection against high voltage short-circuit IGBT operation. The desaturation protection contains noise reducing features such as a 312 ns (typical) masking time after a switching event to mask voltage spikes due to initial turn-on. An internal 537 ?A (typical) current source allows low device count, and the internal blanking switch allows the addition of an external current source if more noise immunity is needed.The secondary UVLO is set to 12 V with common IGBT threshold levels taken into consideration.Applications MOSFET/IGBT gate drivers Photovoltaic (PV) inverters Motor drives Power supplies

The ADuM4221/ADuM4221-1/ADuM4221-2 are 4 A isolated, half bridge gate drivers that employ the Analog Devices, Inc., iCoupler? technology to provide independent and isolated high-side and low-side outputs. The ADuM4221/ADuM4221-1/ADuM4221-2 provide 5700 V rms isolation in an increased creepage wide body, 16-lead SOIC_IC. Combining high speed CMOS and monolithic transformer technology, these isolation components provide outstanding performance characteristics superior to the alternatives, such as the combination of pulse transformers and gate drivers.The isolators operate with a logic input voltage ranging from 2.5 V to 6.5 V, providing compatibility with lower voltage systems. In comparison to gate drivers employing high voltage level translation methodologies, the ADuM4221/ADuM4221-1/ADuM4221-2 offer the benefit of true, galvanic isolation between the input and each output.The ADuM4221/ADuM4221-1/ADuM4221-2 each have built in overlap protection and allow dead time adjustment. A single resistor between the dead time pin (DT) and the GND1 pin sets the dead time on the secondary side between the high-side and the low-side outputs.An internal thermal shutdown (TSD) sets outputs low if the internal temperature on the ADuM4221/ADuM4221-1/ADuM4221-2 exceeds the TSD temperature. As a result, the ADuM4221/ADuM4221-1/ADuM4221-2 provide reliable control over the switching characteristics of the insulated gate bipolar transistor (IGBT)/metal-oxide semiconductor field effect transistor (MOSFET) configurations over a wide range of positive or negative switching voltages.Applications Switching power supplies Isolated IGBT/MOSFET gate drives Industrial inverters Gallium nitride (GaN)/silicon carbide (SiC) compatible1 Protected by U.S. Patents 5,952,849; 6,873,065; 7,075,239. Other patents pending.

The ADuM5020 is an isoPower?, integrated, isolated dc-to-dc converter. Based on the Analog Devices, Inc., iCoupler? technology, the dc-to-dc converter provides regulated, isolated power that is below CISPR22 Class B limits at full load on a 2-layer printed circuit board (PCB) with ferrites. The ADuM5020 eliminates the need to design and build an isolated dc-to-dc converter in 500 mW applications. The iCoupler chip scale transformer technology is used for the magnetic components of the dc-to-dc converter. The result is a small form factor, isolated solution.The ADuM5020 isolated dc-to-dc converter is available in a wide-body 16-lead SOIC package.Applications RS-485/RS-422/CAN transceiver power Power supply startup bias and gate drives Isolated sensor interfaces Industrial PLCs

The ADuM5410/ADuM5411/ADuM5412 are quad-channel digital isolators with isoPower?, integrated, isolated dc-to-dcconverters. Based on the Analog Devices, Inc., iCoupler? technology, the dc-to-dc converters provide regulated, isolated power that is adjustable between 3.15 V and 5.25 V.The ADuM5410/ADuM5411/ADuM5412 eliminate the need for a separate, isolated dc-to-dc converter in low power, isolated designs. The iCoupler chip scale transformer technology is used for isolated logic signals and for the magnetic components of the dc-to-dc converters. The result is a small form factor, total isolation solution.The ADuM5410/ADuM5411/ADuM5412 isolators provide fourindependent isolation channels in a variety of channel configurations and data rates (see the Ordering Guide for more information).Applications RS-232 transceivers Power supply startup bias and gate drives Isolated sensor interfaces Industrial PLCs

The ADV7181D is a high quality, single-chip, multiformat videodecoder and graphics digitizer. This multiformat decoder supportsthe conversion of PAL, NTSC, and SECAM standards in the formof composite or S-Video into a digital ITU-R BT.656 format.The ADV7181D also supports the decoding of a componentRGB/YPrPb video signal into a digital YCrCb or RGB pixeloutput stream. Support for component video includes standardssuch as 525i, 625i, 525p, 625p, 720p, 1080i, and many other HDand SMPTE standards.Graphics digitization is also supported by the ADV7181D; it iscapable of digitizing RGB graphics signals from VGA to XGArates and converting them into a digital DDR RGB or YCrCbpixel output stream. SCART and overlay functionality are enabledby the ability of the ADV7181D to simultaneously process CVBSand standard definition RGB signals. The mixing of these signalsis controlled by the fast blank (FB) pin.The ADV7181D contains two main processing sections. Thefirst section is the standard definition processor (SDP), whichprocesses all PAL, NTSC, and SECAM signal types. The secondsection is the component processor (CP), which processes YPrPband RGB component formats, including RGB graphics.The ADV7181D has unique software and hardware configurationrequirements. Applications Automotive entertainment HDTVs LCD/DLP? projectors HDTV STBs with PVR DVD recorders with progressive scan input support AVR receivers
