Precision Wide-range (3 nA - 3 mA) High-Side Current Mirror Features: Accurately mirrors input current (1:1 ratio) over 6 decades - enables monitoring at low signal levels  Linearity 1% from 3 nA to 3 mA Stable mirror input voltage Voltage held 1 V below supply using internal reference or may be set externally providing greater flexibility in design Adjustable input current limit provides protection to the connected photodiode 2.7 V to 8 V single-supply operation Miniature 8-lead chip scale package (LFCSP 2 mm × 3 mm) saves valuable board space

Hot Swap Controller and Digital Power and Energy Monitor with PMBus Interface Features: ±0.3% accurate, 12-bit ADC for IOUT, VIN, VOUT, and temperature 320 ns response time to short circuit Shutdown on detection of FET health fault Constant power foldback for tighter FET SOA protection Remote temperature sensing with programmable warning and shutdown thresholds Resistor-programmable 5 mV to 25 mV VSENSE current limit Programmable start-up current limit 1% accurate UV, OV, and PWRGD thresholds Split hot swap and power monitor inputs to allow additional external ADC filtering Reports power and energy consumption over time Peak detect registers for current, voltage, and power PROCHOT power throttling capability PMBus fast mode compliant interface 5 mm × 5 mm, 32-lead LFCSP

Three-Channel, Isolated Micropower Management Unit with Seven Digital Isolators Features: Wide input supply voltage range: 4.5 V to 60 V Integrated flyback power switch Generates isolated, independent bipolar outputs and factory programmable buck output VOUT1: 21 V, 24 V or 6 V to 28 V VOUT2: 5.15 V, 5.0 V, or 3.3 V VOUT3: −24 V to −5 V Uses a 1:1 ratio transformer for simplified transformer design Peak current limiting and OVP for flyback, buck, and inverting regulators Precision enable input and power-good output Adjustable switching frequency via SYNC input Internal compensation and soft start control per regulator High speed, low propagation delay, SPI signal isolation channels Three, 100 kbps general-purpose isolated data channels 9 mm × 7 mm LFCSP form factor enables small overall solution size −40°C to +125°C operating junction temperature range Conforms to CISPR11 Class B radiated emission limits Safety and regulatory approvals (pending) UL recognition: 2500 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A 300 V rms basic insulation between slave, master, and field power domains (IEC 61010-1, pending) VDE certificate of conformity DIN V VDE 0884-10 (VDE 0884-10):2006-12 VIORM = 565 VPEAK

Three-Channel, Isolated Micropower Management Unit with Seven Digital Isolators Features: Wide input supply voltage range: 4.5 V to 60 V Integrated flyback power switch Generates isolated, independent bipolar outputs and factory programmable buck output VOUT1: 21 V, 24 V or 6 V to 28 V VOUT2: 5.15 V, 5.0 V, or 3.3 V VOUT3: −24 V to −5 V Uses a 1:1 ratio transformer for simplified transformer design Peak current limiting and OVP for flyback, buck, and inverting regulators Precision enable input and power-good output Adjustable switching frequency via SYNC input Internal compensation and soft start control per regulator High speed, low propagation delay, SPI signal isolation channels Three, 100 kbps general-purpose isolated data channels 9 mm × 7 mm LFCSP form factor enables small overall solution size −40°C to +125°C operating junction temperature range Conforms to CISPR11 Class B radiated emission limits Safety and regulatory approvals (pending) UL recognition: 2500 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A 300 V rms basic insulation between slave, master, and field power domains (IEC 61010-1, pending) VDE certificate of conformity DIN V VDE 0884-10 (VDE 0884-10):2006-12 VIORM = 565 VPEAK

Three-Channel, Isolated Micropower Management Unit with Seven Digital Isolators Features: Wide input supply voltage range: 4.5 V to 60 V Integrated flyback power switch Generates isolated, independent bipolar outputs and factory programmable buck output VOUT1: 21 V, 24 V or 6 V to 28 V VOUT2: 5.15 V, 5.0 V, or 3.3 V VOUT3: −24 V to −5 V Uses a 1:1 ratio transformer for simplified transformer design Peak current limiting and OVP for flyback, buck, and inverting regulators Precision enable input and power-good output Adjustable switching frequency via SYNC input Internal compensation and soft start control per regulator High speed, low propagation delay, SPI signal isolation channels Three, 100 kbps general-purpose isolated data channels 9 mm × 7 mm LFCSP form factor enables small overall solution size −40°C to +125°C operating junction temperature range Conforms to CISPR11 Class B radiated emission limits Safety and regulatory approvals (pending) UL recognition: 2500 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A 300 V rms basic insulation between slave, master, and field power domains (IEC 61010-1, pending) VDE certificate of conformity DIN V VDE 0884-10 (VDE 0884-10):2006-12 VIORM = 565 VPEAK

Isolated, Synchronous Forward Controller with Active Clamp and iCoupler Features: Current mode controller for active clamp forward topology Integrated 5 kV (wide body SOIC package) or 3.0 kV (LGA package) rated dielectric isolation voltage with Analog Devices, Inc., patented iCoupler technology Wide voltage supply range Primary VIN: up to 60 V Secondary VDD2: up to 36 V Integrated 1 A primary side MOSFET driver for power switch and active clamp reset switch Integrated 1 A secondary side MOSFET drivers for synchronous rectification Integrated error amplifier and <1% accurate reference voltage Programmable slope compensation Programmable frequency range: 50 kHz to 600 kHz typical Frequency synchronization Programmable maximum duty cycle limit Programmable soft start Smooth soft start from precharged load Programmable dead time Power saving light load mode using MODE pin Protection features such as short circuit, output overvoltage, and overtemperature protection Cycle-by-cycle input overcurrent protection Precision enable UVLO with hysteresis PGOOD pin for system flagging Tracking function from secondary side Remote (secondary side) shutdown/reset function Safety and regulatory approvals (pending) UL recognition 5000 V rms for 1 minute per UL 1577 (for wide body SOIC package) 3000 V rms for 1 minute per UL 1577 (for LGA package) CSA component acceptance notice 5A VDE certificate of conformity DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 849 V peak (for wide body SOIC package) VIORM = 560 V peak (for LGA package) CQC certification per GB4943.1-2011 Available in 24-lead SOIC_W package and 24-terminal LGA package AEC-Q100 Qualified for Automotive Applications

1 A/0.6 A, DC-to-DC Switching Regulator with Independent Positive and Negative Outputs Features: Wide input supply voltage range: 2.85 V to 15 V Generates well regulated, independently resistor programmable VPOS and VNEG outputs Boost regulator to generate VPOS output Adjustable positive output to 39 V Integrated 1.0 A main switch Optional single-ended primary-inductor converter (SEPIC) configuration for automatic step-up/step-down Inverting regulator to generate VNEG output Adjustable negative output to VIN − 39 V Integrated 0.6 A main switch True shutdown for both positive and negative outputs 1.2 MHz/2.4 MHz switching frequency with optional external frequency synchronization from 1.0 MHz to 2.6 MHz Resistor programmable soft start timer Slew rate control for lower system noise Individual precision enable and flexible start-up sequence control for symmetric start, VPOS first, or VNEG first Out-of-phase operation UVLO, OCP, OVP, and TSD protection 4 mm × 4 mm, 20-lead LFCSP and 20-lead TSSOP −40°C to +125°C junction temperature range Supported by the ADIsimPower tool set

50 mA/500 mA, High Efficiency, Ultralow Power Step-Down Regulator Features: Input supply voltage range: 2.15 V to 6.50 V Operates down to 2.00 V voltage Ultralow 180 nA quiescent current Selectable output voltage of 0.8 V to 5.0V ±1.5% output accuracy over full temperature range in PWM mode Selectable hysteresis mode or PWM operation mode Output current Up to 50 mA in hysteresis mode Up to 500 mA in PWM mode VOUTOK flag monitors the output voltage Ultrafast stop switching control 100% duty cycle operation mode 2.0 MHz typical switching frequency in PWM mode with optional SYNC clock range from 1.5 MHz to 2.5 MHz See data sheet for additional features

20 V, 200 mA, Low Noise, CMOS LDO Linear Regulator Features: Low noise: 11 μV rms independent of fixed output voltage PSRR of 88 dB at 10 kHz, 68 dB at 100 kHz, 50 dB at 1 MHz, VOUT ≤ 5 V, VIN = 7 V Input voltage range: 2.7 V to 20 V Maximum output current: 200 mA Initial accuracy: ±0.8% Accuracy over line, load, and temperature −1.2% to +1.5%, TJ = −40°C to +85°C ±1.8%, TJ = −40°C to +125°C Low dropout voltage: 200 mV (typical) at a 200 mA load,  VOUT = 5 V User programmable soft start (LFCSP and SOIC only) Low quiescent current, IGND = 50 μA (typical) with no load Low shutdown current: 1.8 μA at VIN = 5 V, 3.0 μA at VIN = 20 V Stable with a small 2.2 μF ceramic output capacitor Fixed output voltage options: 1.8 V, 2.5 V, 3.3 V, 4.5 V, and 5.0 V 16 standard voltages between 1.2 V and 5.0 V are available Adjustable output from 1.2 V to VIN – VDO, output can be adjusted above initial set point Precision enable 2 mm × 2 mm, 6-lead LFCSP, 8-Lead SOIC, 5-Lead TSOT AEC-Q100 qualified for automotive applications

40 V, 200 mA, Low Noise, CMOS LDO Linear Regulator Features: Low noise: 11 μV rms independent of fixed output voltage PSRR of 88 dB at 10 kHz, 68 dB at 100 kHz, 50 dB at 1 MHz, VOUT ≤ 5 V, VIN = 7 V Input voltage range: 2.7 V to 40 V Maximum output current: 200 mA Initial accuracy: ±0.8% Accuracy over line, load, and temperature −1.2% to +1.5%, TJ = −40°C to +85°C ±1.8%, TJ = −40°C to +125°C Low dropout voltage: 200 mV (typical) at a 200 mA load, VOUT = 5 V User programmable soft start (LFCSP and SOIC only) Low quiescent current, IGND = 50 μA (typical) with no load Low shutdown current: 1.8 μA at VIN = 6 V, 3.0 μA at VIN = 40 V Stable with a small 2.2 μF ceramic output capacitor Fixed output voltage options: 1.8 V, 2.5 V, 3.3 V, 3.8 V, and 5.0 V 15 standard voltages between 1.2 V and 5.0 V are available Adjustable output from 1.2 V to VIN – VDO, output can be adjusted above initial set point Precision enable 2 mm × 2 mm, 6-lead LFCSP, 8-Lead SOIC, 5-Lead TSOT AEC-Q100 qualified for automotive applications
