Nonvolatile, I2C-Compatible 64-Position, Digital Potentiometer Features: Nonvolatile memory maintains wiper settings  64-position digital potentiometer  Compact MSOP-10 (3 mm × 4.9 mm)  I2C-compatible interface VLOGIC pin provides increased interface flexibility  End-to-end resistance 1 kΩ, 10 kΩ, 50 kΩ, 100 kΩ Resistance tolerance stored in EEPROM (0.1% accuracy) Power-on EEPROM refresh time <1 ms Software write protect command  Address Decode Pin AD0 and Address Decode Pin AD1 allow four packages per bus  100-year typical data retention at 55°C  Wide operating temperature −40°C to +85°C

Analog Comparators Ultra Fast ECL Single Comparator

The AD96685 and AD96687 are ultrafast voltage comparators. The AD96685 is a single comparator with a propagation delay of 2.5 ns, while the AD96687 is an equally fast dual comparator. Both devices exhibit a propagation delay dispersion of 50 ps, a crucial characteristic for high-speed comparators, indicating the difference in propagation delay under varying overdrive conditions.

Featuring a fast, high-precision differential input stage, these comparators maintain consistent propagation delay across a broad range of signals within the common-mode range from -2.5 V to +5 V. The outputs consist of complementary digital signals fully compatible with ECL 10 K and 10 KH logic families. These outputs provide ample drive current to directly interface with transmission lines terminated in 50 Ohms to -2 V. The inclusion of a level-sensitive latch input allows for tracking, track-hold, or sample-hold modes of operation.

Both the AD96685 and AD96687 are available in industrial temperature ranges (-25°C to +85°C) and military temperature ranges. Industrial range devices are offered in 16-pin DIP, SOIC, and 20-lead PLCC packages. Additionally, the AD96685 is available in a 10-pin TO-100 metal can.

Features and Benefits:

• Fast: 2.5 ns Propagation Delay
• Low Power: 118 mW per Comparator
• Packages: DIP, SOIC, PLCC
• Power Supplies: +5 V, –5.2 V
• Logic Compatibility: ECL
• 50 ps Delay Dispersion

Applications:

• High Speed Triggers
• High Speed Line Receivers
• Threshold Detectors
• Window Comparators
• Peak Detectors

Digital to Analog Converters - DAC MULTIPLYING DAC IC

Digital Isolators Dual-Channel Isolators with Integrated DC-to-DC Converter (1/1 Channel Directionality)

The ADuM6210 / ADuM6211 / ADuM6212 represent dual-channel digital isolators featuring isoPower, an integrated, isolated dc-to-dc converter. Leveraging Analog Devices, Inc.'s iCoupler technology, the dc-to-dc converter delivers regulated, isolated power with an adjustable range between 3.135 V and 5.25 V. These isolators accommodate input supply voltages ranging from slightly below the required output to significantly higher values, as detailed in Table 2 for popular voltage combinations and their corresponding power levels.

In low-power, isolated designs, the ADuM6210 / ADuM6211 / ADuM6212 negate the necessity for a separate, isolated dc-to-dc converter. The iCoupler chip-scale transformer technology is utilized for both isolated logic signals and the magnetic components of the dc-to-dc converter. The outcome is a compact, all-encompassing isolation solution.

isoPower employs high-frequency switching elements to transfer power through its transformer. Careful attention must be given to printed circuit board (PCB) layout to meet emissions standards. Refer to the AN-0971 Application Note for recommended board layout practices.

Features and Benefits:

• isoPower integrated, isolated dc-to-dc converter
• Regulated 3.135 V to 5.25 V output
• Up to 150 mW output power
• Dual dc-to-100 Mbps (NRZ) signal isolation channels
• Soft start power supply
• 20-lead SSOP package with 5.3 mm creepage
• Supports SPI up to 15 MHz
• High temperature operation: 105°C
• High common-mode transient immunity: >25 kV/μs
• Safety and regulatory approvals
• UL recognition

  • 3750 V rms for 1 minute per UL 1577
• CSA Component Acceptance Notice 5A
• VDE certificate of conformity

  • DIN V VDE V 0884-10 (VDE V 0884-10):2006-12
  • VIORM = 849 V peak

Applications:

• RS-232 transceivers
• Power supply start-up bias and gate drives
• Isolated sensor interfaces
• Industrial PLCs

Supervisory Circuits RESET GENERATOR I.C.

Supervisory Circuits RESET GENERATOR I.C.

LDO Voltage Regulators PADM1270ACPZ-R7DO 1.3Vo

Digital to Analog Converters - DAC 25V 12-BIT MULT DAC IC

RF Amplifier VGA, 7-20 GHz

Low Noise Amplifier Chip, 2 - 4 GHz Features: Gain Flatness: 0.2 dB Output IP3: +36 dBm Gain: 10 dB DC Supply: +6V @ 100mA 50 Ohm Matched Input/Output Die Size: 1.32 x 1.21 x 0.10 mm
