3.0 V to 5.5 V, 12 kV IEC ESD Protected, Half Duplex 500 kbps RS-485 Transceiver Features: TIA/EIA RS-485 compliant over full supply range 3.0 V to 5.5 V operating voltage range on VCC 1.62 V to 5.5 V VIO logic supply option available ESD protection on the bus pins IEC 61000-4-2 ±12 kV contact discharge IEC 61000-4-2 ≥ ±12 kV air discharge HBM: ≥ ±30 kV Full hot swap support (glitch free power-up/power-down) High speed 50 Mbps data rate (ADM3065E/ADM3066E/ADM3067E/ADM3068E) Low speed 500 kbps data rate for long cables (ADM3061E/ADM3062E/ADM3063E) Full receiver short-circuit, open circuit, and bus idle fail-safe Extended temperature range up to 125°C PROFIBUS compliant at VCC ≥ 4.5 V Half duplex and full duplex models available Allows connection of up to 128 transceivers onto the bus Space-saving package options 10-lead, 3 mm × 3 mm LFCSP 8-lead and 10-lead, 3 mm × 3 mm MSOP 8-lead and 14-lead, narrow body SOIC

3.0 V to 5.5 V with VIO, 12 kV IEC ESD Protected, Half Duplex 500 kbps RS-485 Transceiver Features: TIA/EIA RS-485 compliant over full supply range 3.0 V to 5.5 V operating voltage range on VCC 1.62 V to 5.5 V VIO logic supply option available ESD protection on the bus pins IEC 61000-4-2 ±12 kV contact discharge IEC 61000-4-2 ≥ ±12 kV air discharge HBM: ≥ ±30 kV Full hot swap support (glitch free power-up/power-down) High speed 50 Mbps data rate (ADM3065E/ADM3066E/ADM3067E/ADM3068E) Low speed 500 kbps data rate for long cables (ADM3061E/ADM3062E/ADM3063E) Full receiver short-circuit, open circuit, and bus idle fail-safe Extended temperature range up to 125°C PROFIBUS compliant at VCC ≥ 4.5 V Half duplex and full duplex models available Allows connection of up to 128 transceivers onto the bus Space-saving package options 10-lead, 3 mm × 3 mm LFCSP 8-lead and 10-lead, 3 mm × 3 mm MSOP 8-lead and 14-lead, narrow body SOIC

3.0 V to 5.5 V with VIO, 12 kV IEC ESD Protected, Half Duplex 500 kbps RS-485 Transceiver Features: TIA/EIA RS-485 compliant over full supply range 3.0 V to 5.5 V operating voltage range on VCC 1.62 V to 5.5 V VIO logic supply option available ESD protection on the bus pins IEC 61000-4-2 ±12 kV contact discharge IEC 61000-4-2 ≥ ±12 kV air discharge HBM: ≥ ±30 kV Full hot swap support (glitch free power-up/power-down) High speed 50 Mbps data rate (ADM3065E/ADM3066E/ADM3067E/ADM3068E) Low speed 500 kbps data rate for long cables (ADM3061E/ADM3062E/ADM3063E) Full receiver short-circuit, open circuit, and bus idle fail-safe Extended temperature range up to 125°C PROFIBUS compliant at VCC ≥ 4.5 V Half duplex and full duplex models available Allows connection of up to 128 transceivers onto the bus Space-saving package options 10-lead, 3 mm × 3 mm LFCSP 8-lead and 10-lead, 3 mm × 3 mm MSOP 8-lead and 14-lead, narrow body SOIC

3-V, RS-232 Serial Port Driver-Receiver Features: Green Idle power-saving mode Single 2.7 V to 3.6 V power supply Operates with 3 V logic 0.1 µF to 1 µF charge pump capacitors Low EMI Low power shutdown: 20 nA Full RS-232 compliance 460 kb/s data rate One receiver active in shutdown (ADM3307E/ADM3311E/ADM3312E/ADM3315E) Two receivers active in shutdown (ADM3310E) ESD >15 kV IEC 1000-4-2 on RS-232 I/Os ESD >15 kV IEC 1000-4-2 on CMOS and RS-232 I/Os (ADM3307E) Qualified for automotive applications

Microprocessor Supervisory Circuit in 3-Lead SC70, Active-Low Open-Drain Output Features: Specified over temperature Low power consumption (17 μA) Precision voltage monitor: 2.5 V, 3 V, 3.3 V, 5 V options Reset assertion down to 1 V VCC 140 ms minimum power-on reset Open-drain RESET output

Ultralow Power Voltage Detector with Disable Input and Low Threshold Voltages Features: Ultralow power consumption with ICC = 92 nA (typical) Precision, low voltage monitoring Pretrimmed voltage monitoring threshold options 20 options from 0.5 V to 1.9 V ±1.3% threshold accuracy over full temperature range Output disable input 23 µs to 26 µs typical propagation delay Open-drain type output Power supply glitch immunity Available in a 1.46 mm × 0.96 mm WLCSP Operational temperature range: −40°C to +85°C

15.1 GHz to 32 GHz, Tunable Band-Pass Filter Features:Amplitude settling time: 200 ns typicalWideband rejection: 30 dBSingle chip implementation40-lead, 6 mm 6 mm, RoHS compliant LFCSP

2 GHz to 18 GHz, Digitally Tunable, High-Pass and Low-Pass Filter Features: Digitally tunable, multioctave, high-pass and low-pass tuning Independent 3 dB frequency control for up to 4 GHz of bandwidth Optimal wideband rejection: 35 dB Single chip replacement for discrete filter banks Compact 9 mm × 9 mm, 56-terminal LGA packageENHANCED PRODUCT FEATURES Supports defense and aerospace applications (AQEC standard Military temperature range of −55°C to +105°C Controlled manufacturing baseline One assembly and test site One fabrication site Production change notification Qualification data available on request V62/21604

5.7 kV RMS/1.5 kV RMS, Quad-Channel LVDS 2.5 Gigabit Isolator (0 Reverse Channels) Features: 5.7 kV rms and 1.5 kV rms LVDS isolators Complies with TIA/EIA-644-A LVDS signal levels Quad-channel configuration Any data rate up to 2.5 Gbps switching with low jitter 10 Gbps total bandwidth across four channels 2.15 ns typical propagation delay Typical jitter: 0.82 ps rms random, 40 ps total peak Lower power 1.8 V supplies ±8 kV IEC 61000-4-2 ESD protection across isolation barrier High common-mode transient immunity: 100 kV/μs typical Safety and regulatory approvals (28-lead SOIC_W_FP package) UL (pending): 5700 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE certificate of conformity (pending) DIN V VDE V 0884-11 (VDE V 0884-11):2017-01 VIORM = 849 VPEAK (working voltage) Enable or disable refresh (low speed output correctness check) Operating temperature range: −40°C to +125°C 28-lead, wide-body, finer pitch SOIC_W_FP package with 8.3 mm creepage and clearance or 6 mm × 6 mm LFCSP package with 1.27 mm creepage and clearance

5 kV RMS/3.75 kV RMS, Dual LVDS Gigabit Isolator (0 Reverse Channels) Features: 5 kV rms and 3.75 kV rms LVDS isolators Complies with TIA/EIA-644-A LVDS standard Multiple dual-channel configurations Any data rate up to 1.1 Gbps switching with low jitter 4 ns typical propagation delay 2.6 ps rms typical random jitter, rms 90 ps typical peak-to-peak total jitter at 1.1 Gbps 2.5 V or 3.3 V supplies −75 dBc power supply ripple rejection, phase spur level Glitch immunity ±8 kV IEC 61000-4-2 ESD protection across isolation barrier High common-mode transient immunity: >25 kV/μs Passes EN 55022 Class B radiated emissions limits with 1.1 Gbps PRBS Safety and regulatory approvals (20-lead SOIC_W package) UL (pending): 5000 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE certificate of conformity (pending) DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 424 VPEAK Fail-safe output high for open, short, and terminated input conditions (ADN4655/ADN4656) Operating temperature range: −40°C to +125°C 7.8 mm minimum creepage and clearance
